Filmcity FC-A7RS-KIT Assembly Manual

A7r ii camera cage kit

Hide thumbs Also See for FC-A7RS-KIT:

Download this manual

A7R II Camera Cage kit

(FC-A7RS-KIT)

A s s e m b l y M a n u a l

What's In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

Camera cage

Top Handle

Rod Adapter

Sliding base plate

Cable clamp

2x150mm female rods

2x150mm male rods

MB-600 Matte Box

DP 500 Follow Focus

No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright

statutes or in writing by the Publisher.

Page 1 A7R II Camera Cage kit (FC-A7RS-KIT) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
Page 2 Matte Box Setup  Insert french flag to the top of Matte Box and tighten it with screws. In the same way, insert side flags into the slots provided on both sides and secure them with screws. NOTE: If the french flag remains loose even after tightening the knob, then slightly tighten the allen bolt as shown.
Page 3 Camera Cage Setup  Attach the quick release plate of your tripod head with sliding base plate and tighten it with the help of screw driver. Now mount the sliding base plate on fluid head and secure it properly with the help of knob.
Page 4  Mount the top handle to the Cage as shown in the photo, tighten the knob to secure. NOTE: You can mount handle at different positions – front / back / side. To do this, loosen the screw with the help of screw driver and set the position as per your requirement, make sure to properly secure it.
