- Page 1 COMPACTE Electric Boilers TECHNICAL MANUAL PO Box 11 Ashton Under Lyne OL6 7TR +44. (0) 161 621 5960 Fax +44. (0) 161 621 5966 info@atlantic2000.co.uk www.atlanticboilers.com...
-
Page 3: Table Of Contents
POWER ELECTRIC DIAGRAM…………………….……………………………….………8 STARTING THE BOILER…… ……..……………………………..9 ……………………………………… INSTALLATION……………………………………………………………………………….10 SERVICING…………………………………………………………………………………….11 THE COMMISSIONING OF THE COMPACTE……………………………………………27 THE GUARANTEE ON THE COMPACTE………………………………………………….32 PO Box 11 Ashton Under Lyne OL6 7TR +44. (0) 161 621 5960 Fax +44. (0) 161 621 5966 info@atlantic2000.co.uk www.atlanticboilers.com... -
Page 4: Description
DESCRIPTION The “Compacte” electric boilers have been designed for any heating system (maximum working pressure 4 Bars) 1. Control Panel 2. Ventilation 3. Flow 4. Boiler sensors pocket 5. Immersion Heaters 6. Insulation 7. Return 8. Power (Main) 9. Electrical components 10. -
Page 5: Schematic
SCHEMATIC 1) Conventional Pipework 2) Weather compensated Pipework 3) Weather compensated pipework Radiators or under-floor heating... - Page 6 4) Heating and hot water pipework Radiators expansion pressure relief auto air vessel valve vent pressure & isolating ball valve temperature relief pump valve Fill loop non return 3 port valve valve NB: Boiler pump flow should be 5% superior to the sum of heating and DHW primary pump...
-
Page 7: Command Electric Diagram
COMMAND ELECTRIC DIAGRAM 415 Volts 3Phases supply Sensor Controller 415/240 Power Lockout Step 2 Green Lockout Step 1 Yellow S1: Power Switch S2: Controller Switch Earth : Green/Yellow 4mm² Wires 0 to 6 : Red 1mm² Wire 9 : Black 1mm² Other wires : Brown 1mm²... -
Page 8: Power Electric Diagram
POWER ELECTRIC DIAGRAM Fuses: F1-F2-F3: Industrial cylinder cartridge (8,5 * 31,5) • • F1: 1A type AM F2: 1A type AM F3: 1A type gG F6-F7: Industrial cylinder cartridge (22 * 58) 415V. 3 ph 36 kW 48 kW 60 W 72 kW 50 A 50 A... -
Page 9: Starting The Boiler
STARTING THE BOILER • Check that the system is filled with water • Purge the system • An automatic air vent is required on the flow from the boiler • Power the boiler • Switch the boiler on • Set the two regulation stages •... - Page 10 First Start: 3 minutes confirmation A. Press the (2) key SET1 for 5 seconds, the (6) light shine B. Adjust the settings with (3) and (4) keys C. Validate by pressing the (2) key set1, the indicator (1) is flashing the new stage 1 setting is stored, the (6) light switched off (after a few seconds the real temperature is shown on the display) D.
-
Page 11: Installation
INSTALLATION The electric boiler “compacte” should be installed in a louvered plantroom in order to ensure an ambient temperature below 30ºC and relative humidity between 30 and 80%. The boiler should not be used in a corrosive atmosphere or in an external position. -
Page 12: Servicing
SERVICING Loss of water velocity through the boiler can lead to temperature rise • Consider a sediment vessel on the return to capture sediment deposit • Blocking immersion heaters irrigation can destroy them NOTE : The immersion heaters can be destroyed by blockage of the water flow It is essential that a periodical cleaning is carried out on the main heat exchanger and the sensors. - Page 13 THE COMMISSIONING OF THE ATLANTIC COMPACTE All Atlantic boilers and water heaters are thoroughly tested for mechanical, electrical and combustion performance at the factory The prime object of the site commissioning of the boiler(s) is, subject to installed conditions, to match the optimum combustion performance results reached at the factory and to ensure the boiler(s) is/are installed according to the conditions of guarantee.
- Page 14 THE GUARANTEE ON THE ATLANTIC COMPACTE This guarantee is to the purchaser of the boiler(s) who is deemed to be the installer. If the boiler(s) is (are) purchased by the eventual user who then arranges to install the boiler(s), the eventual user is deemed to be the installer. The details of the guarantee are given to assist the installer in obtaining effective action within the guarantee and they are in addition to the installer’s legal rights under the relevant statutory enactments for the time...
