4) TECHNICAL DATA

- Traction gear
Irreversible Worm Screw reduction gear
Toothed belt with rubber tracks
Driving pulley
Backstand mechanical system
Idle wheels for the transfer on floor
- Performances
Running direction
Speed (upwards/downwards)
Capacity
Rated load
Geometrical features of the stair
- Environmental conditions
Temperature
Humidity
- Overall dimensions
Machine body
Steering-bar
- Weight
Machine body
Steering-bar
- Electrical installation
D.c. Motor Brushless
Electrical input
Battery charger on machine
Sealed battery with gelatinous electrolyte
Battery recharge time
Fuse
- Controls
Timed start push button (Forward/backward)
Emergency stop push button
- Signals
Battery charge display
Gravity gradient visual signal
Ratio 1/50
HTD-8M
z=40
n° 4 wheels on ball bearings
Forward/Backward
5 m/min.
1 person with wheelchair
130 kg
See Fig. 8
0° ÷ +45°C
max. 90%
See Fig. 7
See Fig. 7
kg 37
kg 10
24V
25 A
230V a.c. 50 Hz, 24V d.c. 3A
2x12 V 12 Ah
8 hours when the battery is totally exhausted
40 A
Delay of 1 seconds
