Job Aid: Installing the upgrade memory kit in the
G450 / G430 Media Gateway
!
Important:
Always check the Avaya Support Website for Product Support Notices at
Important:
http://support.avaya.com
Support Notices.
This Job Aid describes the steps required to install the upgrade memory kit components in the
Avaya G450 and Avaya G430 media gateways.
The upgrade memory kit enables increasing the number of announcement files on the gateway
from 256 to 1024, by storing them on a removable compact flash. This also increases the total
amount of announcement time from 45 minutes to four hours. Since the announcements are
played from RAM, you must also increase RAM. The upgrade memory kit consists of:
1 GB compact flash memory card
●
Two RAM cards. Use the RAM card applicable to your gateway, as detailed below.
●
The following sections describe the steps required to install or remove the upgrade memory kit
components in the Avaya G450 and Avaya G430:
Ordering equipment
●
Inserting or replacing a RAM card
●
Inserting or removing a compact flash memory card
●
Ordering equipment
When ordering the upgrade memory kit, quote the following comcode:
Table 1: Upgrade memory kit comcode for customer and services ordering
Product
Upgrade memory kit
and select Communication Manager > Product
Comcode
700457013
03-603203 Issue 1 May 2009
1
Advertisement
Table of Contents
Related Manuals for Avaya 700457013
Summary of Contents for Avaya 700457013
- Page 1 Job Aid: Installing the upgrade memory kit in the G450 / G430 Media Gateway Important: Always check the Avaya Support Website for Product Support Notices at Important: http://support.avaya.com and select Communication Manager > Product Support Notices. This Job Aid describes the steps required to install the upgrade memory kit components in the Avaya G450 and Avaya G430 media gateways.
- Page 2 Job Aid: Installing the upgrade memory kit in the G450 / G430 Media Gateway Inserting or replacing a RAM card The following sections provide instructions for: Inserting or replacing a RAM card in the G450 ● Replacing a RAM card in the G430 ●...
-
Page 3: Removing The G450 Main Board
Inserting or replacing a RAM card Removing the G450 main board ELECTROSTATIC ALERT: Hold the module only by its edges to avoid damage from static electricity. Do not ELECTROSTATIC ALERT: touch the top or bottom of the circuit board. If possible, wear a wrist-strap and use an anti-static bag. - Page 4 Job Aid: Installing the upgrade memory kit in the G450 / G430 Media Gateway Figure 2: Inserting a RAM card in a G450 1.x Note: To remove a RAM card, open the latches on both sides of the RAM slot housing Note: the RAM card.
- Page 5 Inserting or replacing a RAM card 3. Pull out the 256 RAM card. Important: Make sure to remove the 256 RAM card. Failure to do so may result in continuous Important: resets. 4. Insert the 512 RAM card provided in the kit into the RAM slot, and push in all the way. Do not use too much force.
- Page 6 Job Aid: Installing the upgrade memory kit in the G450 / G430 Media Gateway Reinserting the G450 main board 1. Verify that the latches on both sides of the main board are open. 2. Insert the main board into the slot. 3.
-
Page 7: Removing The G430 Cover
Inserting or replacing a RAM card Replacing a RAM card in the G430 The G430 has a single RAM slot housing a 256 MB RAM card. If you wish to support an increased number of announcement files, you must upgrade the G430 memory by replacing the 256 MB RAM card with a 512 MB RAM card. - Page 8 Job Aid: Installing the upgrade memory kit in the G450 / G430 Media Gateway Figure 4: Removing the G430 cover screw from the top of the device Figure notes: 1. G430 top cover screw Figure 5: Removing G430 cover screws from the right side Figure notes: 1.
- Page 9 Inserting or replacing a RAM card Replacing the G430 RAM card ELECTROSTATIC ALERT: Hold the module only by its edges to avoid damage from static electricity. Do not ELECTROSTATIC ALERT: touch the top or bottom of the circuit board. If possible, wear a wrist-strap and use an anti-static bag.
-
Page 10: Replacing The G430 Cover
For example, when the G430 is working properly, sample output includes: MAINBOARD BOARD --------------- Type : G430 mainboard Description : Avaya Inc., G430 Media Gateway Serial Number : 08IS26191011 HW Vintage HW Suffix FW Version : 29.22.50... -
Page 11: Inserting A Compact Flash Memory Card
Inserting or removing a compact flash memory card Inserting or removing a compact flash memory card The G450 and G430 support hot insertion and removal of a compact flash memory card without power drop, provided the compact flash is not in use when you remove it. Inserting a compact flash memory card 1. -
Page 12: Replacing A Compact Flash Memory Card While Retaining The Current Announcements
Job Aid: Installing the upgrade memory kit in the G450 / G430 Media Gateway Replacing a compact flash memory card while retaining the current announcements. You ● may wish to do this because the current compact flash memory card failed, or you want to have two copies of the announcement files, or you want to use a faster compact flash card. -
Page 13: Downgrading From A Compact Flash To Internal Flash Memory
Inserting or removing a compact flash memory card Downgrading from a compact flash to internal flash memory You can downgrade from using up to 1024 announcements on a compact flash to using up to 256 announcements on the internal flash. WARNING: The internal flash can only store up to 256 announcement files, totaling no more WARNING:... - Page 14 Job Aid: Installing the upgrade memory kit in the G450 / G430 Media Gateway 14 Job Aid: Installing the upgrade memory kit in the G450 / G430 Media Gateway...
