- Page 1 KSZ 10B Current Probe Calibrator Instruction Manual...
- Page 2 (including damages for loss of profits, loss of business, loss of use or data, interruption of business and the like), even if PMK GmbH has been advised of the possibility of such damages arising from any defect or error in this manual or product.
- Page 3 WEEE/ RoHS Directives KSZ10B (EC conformity marking) This electronic product is classified within the WEEE/ RoHS* category list as monitoring and control equipment (category 9). Category 9 products are exempted from the restrictions under the scope of the RoHS directive. Your help and efforts are required to protect and keep clean our environment.
- Page 4 Safety Information To avoid personal injury and to prevent fire or damage to this product or products connected to it, review and comply with the following safety precautions. Be aware that if you use this instrument in a manner not specified the protection this product provides may be impaired.
- Page 5 KSZ10B Functionality: The functionality of the KSZ 10B is described by the simplyfied diagram ( Fig. 1). By a fast noninductive switching transistor a pulsed current is generated from a condensator bank through an exact resistor. The value of the pulsed current is determined by the value U1 and the value of resistance R1.
- Page 6 Current Probe Calibrator front view KSZ10B 1. "Ip (A)" rotary switch from 0.1 A up to 10 A 2. "TEST" trigger switch and indicator LED 3. "200 V" LED 4. Contact Bar for Clamp or Hall device 5. Trigger Output 6.
- Page 7 Follow the general instructions on how to use this instrument for further information. 1. Turn on the KSZ 10B by pressing the switch at the backplate. Notice that the LED "PWR" at the front of the calibrator is lit.
- Page 8 Scope of Delivery KSZ10B The following items are included in the scope of delivery. Please check the delivery for completness. If any item is missing, send a message to our service department and we will send you the item immediately. Item Qty.
