(including damages for loss of profits, loss of business, loss of use or data, interruption of business and the like), even if PMK has been advised of the possibility of such damages arising from any defect or error in this manual or product.
FireFly ® Instruction Manual Compliance Information ® The FireFly probing system complies with the following relevant union harmonization legislation, safety and environmental standards. Only professionals and qualified personnel should use this product. Serious injury or death may occur as result of incorrect usage of this product. Probe ...
FireFly ® Instruction Manual IEC Pollution Degrees Definitions and Examples: Overview of measurement categories according to IEC 61010-01 O = No Measurement Category (Other circuits that are not directly connected to mains) Pollution Degree 1 No POLLUTION or only dry, non conductive POLLUTION. NOTE: The POLLUTION has no influence.
FireFly ® Instruction Manual Safety and Handling Information The probe head, tip cables and accessories are NOT for hand-held use. The overall safety of any measurement setup incorporating this probe is the responsibility of the user. The probe head is optically-isolated, galvanically isolated, from the measuring system and earth ground.
Use ONLY the PMK recommended 18650 batteries, in the probe head. If using a battery with a built in USB charge port, connect the appropriate USB cable and connect to a USB port on the oscilloscope, wall wart or PC.
FireFly ® Instruction Manual Clearance Requirements The probing system can be used for very high common mode voltages. Observe all pre-cautions and information from the manual when using this product. See also Specifications and Derating curves in this manual. Maintain at least 1m (40in) safe clearance of the probe head, tip cable and tip cable accessories in all directions when connected to an energized circuit.
The software is free of charge, and included with PMK’s 2ch and 4ch power supplies PS-02 and PS-03, which are required to power the probe. The PS- 02 and PS-03 power supplies all have a USB interface and are available with optional LAN interface.
FireFly ® Instruction Manual Specifications The probe head and tip cables are not for handheld use. Observe adequate spacing between probe head components and earth ground. The probe can be used without probe tip. Warm up time 20minutes. Read the safety instructions before first use. This product is not rated for CAT II, III or IV. Do not exceed the specifications.
FireFly ® Instruction Manual Electrical Specifications (Continued) Common Mode 1 MHz 100 MHz 200 MHz 500 MHz 1 GHz Rejection Ratio SMA Input > 180 dB 173 dB 105 dB 95 dB 90 dB 80 dB FF-MMCX-1V > 180 dB FF-MMCX-10V >...
FireFly ® Instruction Manual Environmental Specifications Parameter Specification 0 ⁰C to +50 ⁰C Temperature Operating Probe Head & Range Interface Box -40 ⁰C to +85 ⁰C Tip Cables & Adapters -20 ⁰C to +71 ⁰C Non-Operating Probe Head & Interface Box -40 ⁰C to +85 ⁰C Tip Cables &...
FireFly ® Instruction Manual Typical Frequency Response The typical frequency response is coming soon. Typical Differential Input Impedance Note that the maximum input voltage rating of the probe decreases as the frequency of the applied signal increases. ® Typical Differential Input Impedance FireFly Series...
FireFly ® Instruction Manual User Interface Interface Box Controls & Indicators Probe Status Indicator Auto-Zero Button Probe Head Battery Level Indicators Bottom Battery Level Indicator Probe Head Power ON/OFF Button Probe Status Indicator Indicator Status Action/Information READY Green Successful powered up and probe head is on and warmed Probe Head (Solid) up.
Set the oscilloscope’s attenuation scale factor to the tip cable's attenuation. 2) Connect the PMK Power Supply, model 2ch PS2, 4ch PS3 or battery pack AP-01, to the power ® connector on the FireFly Interface Box using a PMK Probe Connection Cable.
FireFly ® Instruction Manual Indicator on the interface box to turn green, which means the probe is now ready to make a measurement. 5) If a probe holder is being used, use non-conducting probe holders only and connect the probe head to the probe holder by aligning the attachment interface and then rotating it 90°...
Not all required items are included in the scope of delivery of the base probe FireFly FF-1500. See Ordering Information to configure your individual probing solution and select a required PMK power supply. The following accessories are included in the scope of delivery.
FireFly ® Instruction Manual Ordering Information Step 1: Select Base Probe ® FF-1500 FireFly optical isolated probe, 1.5GHz, >180dB, 2m fiber cable (2 batteries & 2footer included, required power supply to be ordered separately) Step 2: Select Probe Tip Cables The probe tip cables are interchangeable without requiring any tools.
Page 20
3D positioner with steel base, 200 mm span width and FireFly probe holder, max 10kV Step 5: Select Power Supply The power supply pin assignment is different from other power supplies. Use only original PMK power supplies with PMK probes. 889-09V-PS2 PS-02 (2 channels, with USB interface for remote control)
