HAND HELD DRYWALL SANDER
MODEL NO: DWS180
PART NO: 3400400
OPERATION & MAINTENANCE
INSTRUCTIONS
DL1020 ISS 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWS180 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Clarke DWS180

  • Page 1 HAND HELD DRYWALL SANDER MODEL NO: DWS180 PART NO: 3400400 OPERATION & MAINTENANCE INSTRUCTIONS DL1020 ISS 1...
  • Page 2: Environmental Recycling Policy

    INTRODUCTION Thank you for purchasing this CLARKE 180mm Hand Held Drywall Sander, which is designed for drywall and ceiling sanding use only. Read all safety warnings, instructions, illustrations and specifications provided with this power tool. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
  • Page 3: Specification

    SPECIFICATION Electrical Supply 230V 50Hz 1 ph Power rating 710 Watt Fuse rating 13 Amp No Load Speed (variable) 1200 - 2500 rpm Net Weight 2.3 kg Disc Sanding Size 190 mm Sanding Discs Aluminium Oxide (P80, P100, P120, P150, P180, P240) Vibration Emissions 4.09 m/s...
  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS WARNING: READ ALL INSTRUCTIONS. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED BELOW MAY RESULT IN ELECTRIC SHOCK, FIRE AND/ OR SERIOUS INJURY. THE TERM “POWER TOOL” IN ALL WARNINGS LISTED BELOW REFERS TO YOUR HAND HELD DRYWALL SANDER. 1) WORK AREA SAFETY a.
  • Page 5 hat, or hearing protection used for appropriate conditions will reduce personal injuries. c. Prevent unintentional starting. Ensure the trigger is in the off-position before connecting to power source, picking up or carrying the tool. Carrying power tools with your finger on the trigger or energising power tools that have the switch on invites accidents.
  • Page 6: Dust Extraction

    be performed. Use of the power tool for operations different from those intended could result in a hazardous situation. 5) SERVICE a. Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.
  • Page 7: Electrical Connections

    ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. Connecting it to any other power source may cause damage.
  • Page 8: Product Overview

    PRODUCT OVERVIEW DESCRIPTION DESCRIPTION Sander Auxiliary Handle LED Light 2 x Carbon Brushes 2m Dust Extraction Hose S5 Allen Key Dust Bag 1 x P80 sanding disc 1 x P100 sanding disc 1 x P120 sanding disc 1 x P150 sanding disc 1 x P180 sanding disc 1 x P240 sanding disc Parts &...
  • Page 9: Preparation And Use

    PREPARATION AND USE FITTING A SANDING PAD 1. Ensure the sander is switched off and the plug is removed from the socket. 2. Remove the sanding disc. 3. Place the allen key in the hexagon hole in the centre of the sanding pad and rotate clockwise to remove disc 4.
  • Page 10: Dust Collection

    DUST COLLECTION 1. Ensure the sander is switched off. 2. Connect hose onto the dust extract port on the underside of the sander trigger handle. 3. Connect opposite end of hose onto dust collection bag. NOTE: The dust bag must be emptied regularly:- do not wait until it is completely full.
  • Page 11 SPEED CONTROL SETTINGS To control the speed, turn the knob located on the trigger in the direction marked. 1 = 1200 rpm 2 = 1500 rpm 3 = 1800 rpm 4 = 2100 rpm 5 = 2400 rpm Max = 2500 rpm LOCK ON FEATURE For continuous sanding: 1.
  • Page 12: Led Light

    LED LIGHT 1. Adjust light to appropriate angle 2. The light has an independent On/ Off button. REPLACING CARBON BRUSHES Both carbon brushes need replacing once either have less than 6mm length of carbon remaining. 1. Ensure the sander is switched off and the plug is removed from the socket.
  • Page 13: Trobleshooting

    Wipe the exterior with a dry cloth. Excessive Worn brushes. This problem is easily remedied but Sparking. you should consult your CLARKE dealer for parts and advice. Sander does Blown fuse in plug. Check power supply. If the fuse is...
  • Page 14: Parts Diagram

    PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 15: Parts List

    25 O20 x O10 x 5 Oil Seal 51 Auxiliary Handle 26 Armature 52 S5 Hexagon Allen Key When requesting spare parts, please quote the reference DWS180 followed by the number listed. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
