- Page 1 225MM LONG REACH DRYWALL SANDER (230V) MODEL NO: DWS225LR 230V PART NO: 3400404 OPERATION & MAINTENANCE INSTRUCTIONS DL1020 ISS 1...
-
Page 2: Environmental Recycling Policy
INTRODUCTION Thank you for purchasing this CLARKE 225mm 230v Long Reach Drywall Sander. Read all safety warnings, instructions, illustrations and specifications provided with this power tool. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Specification
SPECIFICATION Electrical Supply 230V 50Hz 1 ph Power rating 750 Watt Fuse rating 13 Amp No Load Speed (variable) 800 - 1750 rpm Net Weight 4.1 kg Disc Sanding Size 225 mm Sanding Discs Aluminium Oxide (P80, P100, P120, P150, P180, P240) IP Rating IP20... -
Page 4: Safety Precautions
SAFETY PRECAUTIONS WARNING: READ ALL INSTRUCTIONS. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED BELOW MAY RESULT IN ELECTRIC SHOCK, FIRE AND/ OR SERIOUS INJURY. THE TERM “POWER TOOL” IN ALL WARNINGS LISTED BELOW REFERS TO YOUR LONG REACH DRYWALL SANDER. 1) WORK AREA SAFETY a. - Page 5 b. Use personal protective equipment. ALWAYS wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries. c. Prevent unintentional starting. Ensure the trigger is in the off-position before connecting to power source, picking up or carrying the tool.
-
Page 6: Dust Extraction
be performed. Use of the power tool for operations different from those intended could result in a hazardous situation. 5) SERVICE a. Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. -
Page 7: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. Connecting it to any other power source may cause damage. -
Page 8: Product Overview
PRODUCT OVERVIEW DESCRIPTION DESCRIPTION Main Sander Body Spring Extension Handle 2 x Carbon Brushes Dust Bag Allen Key Dust Extraction Hose 1 x P80 sanding disc 1 x P100 sanding disc 1 x P120 sanding disc 1 x P150 sanding disc 1 x P180 sanding disc 1 x P240 sanding disc Storage Bag... -
Page 9: Preparation And Use
PREPARATION AND USE FITTING A SANDING PAD 1. Ensure the sander is switched off and the plug is removed from the socket. 2. Remove the sanding disc. 3. Place the allen key in the hexagon hole in the centre of the sanding pad and rotate clockwise to remove pad 4. -
Page 10: Dust Collection
4. Attach hose to extension handle via twist & lock grommet and turn clockwise to lock into place. 5. Attach dust bag to hose via twist & lock grommet and turn clockwise to lock into place. DUST COLLECTION 1. Ensure the sander is switched off. 2. -
Page 11: Speed Control
• Allow to get up to speed before working gently across the workpiece until smooth. 7. Release the trigger. • Wait until the motor has stopped fully before putting the sander down. LOCK ON FEATURE For continuous sanding: 1. Squeeze the trigger and then press the LOCK ON button. •... -
Page 12: Replacing Carbon Brushes
SANDING HIGH LEVEL & CEILINGS The spring aids in the stability and positioning of the sander head when sanding high level or ceilings 1. Attached extension handle, dust hose and bag. 2. Attach spring to the front and rear spring eyelets as shown. REPLACING CARBON BRUSHES Both carbon brushes need replacing once either have less than 6mm... -
Page 13: Maintenance
Sander does Check to ensure the fuse If the fuse is sound or blows not operate in the plug is sound. repeatedly, consult your CLARKE when dealer. switched on. Dust is not The dust bag is full or the Remove and empty the bag, also extracted. - Page 14 REPLACEMENT DISCS & ACCESSORIES REPLACEMENT DISCS GRIT SIZE PART NUMBER GRIT SIZE PART NUMBER P60 (Pack of 5) 6502146 P150 (Pack of 5) 6502149 P80 (Pack of 5) 6502147 P180 (Pack of 5) 6502150 P120 (Pack of 5) 6502148 P240 9Pack of 5) 6502151 ACCESSORIES 6 1/2”...
-
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 16 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
