  • Page 3: Preface

    Preface Preface Thank you for purchasing an Autonics product. Please familiarize yourself with the information contained in the Safety Precautions section before using this product. This user manual contains information about the product and its proper use, and should be kept in a place where it will be easy to access.

  • Page 4: User Manual Guide

    The manual's content may vary depending on changes to the product's software and other  unforeseen developments within Autonics, and is subject to change without prior notice. Upgrade notice is provided through out homepage. We contrived to describe this manual more easily and correctly. However, if there are any ...

  • Page 5: Communication Protocol

    Communication Protocol Communication Protocol MP5 Series is accepted to Modbus RTU Protocol. Users should be aware that it does not support a broadcast command. © Copyright Reserved Autonics Co., Ltd.

  • Page 6: User Manual Symbols

    Failure to follow instructions can result in serious injury or death. Failure to follow instructions can lead to a minor injury or product damage. An example of the concerned feature's use. Annotation mark. ※1 © Copyright Reserved Autonics Co., Ltd.

  • Page 7: Safety Precautions

    Keep metal chip, dust, and wire residue from flowing into the unit.  Failure to follow this instruction may result in fire or product damage. The specifications of communication manual are subject to change and some models may be discontinued without notice. © Copyright Reserved Autonics Co., Ltd.
  • Page 8 Safety Precautions viii © Copyright Reserved Autonics Co., Ltd.

  • Page 9: Table Of Contents

    2.4 Read holding registers (Func03) / Preset single registers (Func 06) / Preset multiple registers (Func 16) ......................21 2.4.1 Comparative value settings and peak value check group......21 2.4.2 Parameter 1 group ..................21 2.4.3 Parameter 2 group ..................22 2.4.4 Parameter 3 group ..................23 © Copyright Reserved Autonics Co., Ltd.

  • Page 10: Table Of Contents

    Table of Contents © Copyright Reserved Autonics Co., Ltd.

  • Page 11: Modbus Rtu Protocol

    Response (Slave)  Data Data Error check (CRC16) Slave address Function Byte count (000008 to (000010 to High 000001) 000009) 11 H 01 H 02 H CD H 01 H ## H ## H © Copyright Reserved Autonics Co., Ltd.

  • Page 12: Read Input Status (Func 02-02H)

    Response (Slave)  Data Data Error check (CRC16) Slave address Function Byte count (100008 to (100010 to High 100001) 100009) 11 H 02 H 02 H CD H 01 H ## H ## H © Copyright Reserved Autonics Co., Ltd.

  • Page 13: Read Holding Registers (Func 03-03H)

    Response (Slave)  Data Data Error check (CRC16) Slave address Function Byte count High High High 11 H 03 H 04 H 02 H 2B H 00 H 64 H ## H ## H © Copyright Reserved Autonics Co., Ltd.

  • Page 14: Read Input Registers (Func 04-04H)

    Response (Slave)  Data Data Error check (CRC16) Slave address Function Byte count High Low High High 11 H 04 H 04 H 00 H 0A H 00 H 14 H ## H ## H © Copyright Reserved Autonics Co., Ltd.

  • Page 15: Force Single Coil (Func 05-05H)

    ## H Response (Slave)  Starting address Preset data Error check (CRC16) Slave address Function High High High 11 H 05 H 00 H 00 H FF H 00 H ## H ## H © Copyright Reserved Autonics Co., Ltd.

  • Page 16: Preset Single Registers (Func 06-06H)

    ## H Response (Slave)  Starting address Preset data Error check (CRC16) Slave address Function High High High 11 H 06 H 00 H 00 H 00 H 0A H ## H ## H © Copyright Reserved Autonics Co., Ltd.

  • Page 17: Preset Multiple Registers (Func 16-10H)

    (device) connecting with external devices such as PLC, Graphic Panel, except in the case of download that presets the minimum/maximum or basic value of parameter by Input specifications in PC Loader Program © Copyright Reserved Autonics Co., Ltd.

  • Page 18: Exception Response-Error Code

    E8 H 00 H 01 H ## H ## H Response (Slave)  Error check (CRC16) Function Slave address Exception Code +80 H High 11 H 81 H 02 H ## H ## H © Copyright Reserved Autonics Co., Ltd.

  • Page 19: Modbus Mapping Table

    300109(006C) Model 5 " " (※MP5W-□9 300110(006D) Model 6 " " displayed as 300111(006E) Model 7 " " MP5W-□8) 300112(006F) Model 8 " " 300113(0070) Model 9 " " 300114(0071) Model 10 " " © Copyright Reserved Autonics Co., Ltd.
  • Page 20 UNIT 5: 999.99m 6: 9999.9m 7: 99h 59.9m 8: 999h 59m 9: 99999m 0: F1 / 1: F2 / 2: F3 / 301006(03ED) MODE Operation mode to / 14: F15 / 15: F16 301007(03EE) © Copyright Reserved Autonics Co., Ltd.

  • Page 21: Read Holding Registers (Func03) / Preset Single Registers (Func 06) / Preset Multiple Registers (Func 16)

    0.0 to 99.9 timer value 400058(0039) 03/16 AUToA Auto-zero A 400059(003A) 03/16 Auto-zero time 0.1 to 9999.9 9999.9 400060(003B) 03/16 AUToB Auto-zero B 400061(003C) 03/16 0: OFF 400062(003D) 03/06/16 R/W MEMO Memory Memory retention 1: ON © Copyright Reserved Autonics Co., Ltd.

  • Page 22: Parameter 2 Group

    Operation mode COUnB INB Setting value 1 to 99999 99999 F16 INB 400121(0078) 03/16 400122 to 400150 03/06/16 R/W Reserved ※1. In operation modes F8, F10, F14, F15, the setting range is -19999 to 99999 © Copyright Reserved Autonics Co., Ltd.

  • Page 23: Parameter 3 Group

    Series Operation mode Setting range F1, F2, F7, F9, F11, F12, F13, F16 0 to 99999 MP5Y F3, F4, F5, F6 0.01 to set time range MP5W F8, F10, F14, F15 -19999 to 99999 © Copyright Reserved Autonics Co., Ltd.
  • Page 24 2 Modbus Mapping Table © Copyright Reserved Autonics Co., Ltd. MCP-MPC1-V1.0-1801US...
