IT-PMC-1200
2-ports 10/100M Media Converter
(SM & MM)
1
Introduction:
The Media Converter complies with IEEE802.3, IEEE802.3u,
IEEE802.3x Standards. It is designed to convert data signal between
10/100 Base-TX and 100Base-FX fast Ethernet. It supports
10/100Base-TX and 100Base-FX applications. The data signal
converted by such high performance media converter can be
transmitted up to 120Km maximum by fiber-optical cable. The
Converter is equipped one optic port and two RJ45 Jacks and one
external power supply receptacle. Four LED indicators are built -in
for easy diagnosing and monitoring the status of. It can be
configured automatically for Full Duplex or Half Duplex operation.
Packing List:
IT-PMC-1200 is shipped with following items.
1. IT-PMC-1200×1
2. 5VDC power adapter ×1(Media converter/5VDC)
3. User manual ×1
Advertisement
Table of Contents
Related Manuals for Intellisystem IT-PMC-1200
Summary of Contents for Intellisystem IT-PMC-1200
- Page 1 It can be configured automatically for Full Duplex or Half Duplex operation. Packing List: IT-PMC-1200 is shipped with following items. 1. IT-PMC-1200×1 2. 5VDC power adapter ×1(Media converter/5VDC) 3. User manual ×1...
-
Page 2: Pinout Configuration
6. Can insert to 2U 19", 14 slots Rack (power external) Pinout Configuration: Power IT-PMC-1200 adopt the power supply input is 5VDC external. Ethernet (RJ45), Optical fiber interface Optical fiber interface: Optic fiber interface need use in pairs, OUT port is fiber send side, connect another long-range light of interface fiber receive end IN;... - Page 3 show: A-A, B-B, can also mark another: A1-A2, B1-B2), in order to use. NOTE: SC, ST or FC, for optic fiber interface, SM is look the same to MM for form. For example, IT-PMC-1200SM/SC, the optic fiber interface (SC) is look the same to IT-PMC-1200MM/SC. Ethernet interface: 2-port Ethernet (RJ45) interface supports MDI/MDI-X auto negotiation, can use straight-through cable connect PC or server,...
- Page 4 MDI-X — — 4、5、7、8 Note： “TX±”Transfer data±， “RX±”Receive data±， “—”None。 MDI: RJ45 MDI-X: RJ45 (RX+) (TX+) (RX-) (TX-) (TX+) (RX+) (TX-) (RX-)
-
Page 5: Led Indications
LED indications: STATE INDICATION no link FX-ACT BRIGHT link is ok (Fiber Link Port) FLASH TX or RX activity no link BRIGHT link is ok TP1-ADD FAST transmitting receiving (Ethernet Port1) FLASH 100Mbps SLOW transmitting receiving FLASH 10Mbps no POWER POWER BRIGHT POWER is ok... -
Page 6: Installation
Operating temp:-10°C to 65°C Storage temperature: -20 to 70°C Operating humidity: 5% to 95 %( no condensation) Warranty: 5 years Approvals: FCC, CE, RoHS approvals Applications: Extending 10/100M Ethernet data distance Installation: IT-PMC-1200 provides DIN-rail and wall mounting two types of installation. - Page 7 Wall mounting installation...
-
Page 8: Troubleshooting Instructions
DIN-Rail Installation Troubleshooting instructions: 1. Make sure the power is connected and turned on. 2. Make sure the converter Ethernet and fiber optic cables are connected properly. 3. Check the connections according to the connection diagram. 4. Check the LED Indication status and identify possible problems from the Indication LED table above. -
Page 9: Common Problems
5. W henever there is a fault, you can contact our technical support after you identify the problem and the alarm. Common Problems: 1. PWR power supply indicator lamp not lighting Cause: 1. Power supply not properly connected 2. Protector tube damaged 3. - Page 10 Solution: 1. Check Ethernet (RJ45) line is link or not. 2. Check Ethernet (RJ45) port is loose. 3. Check the rate of selected media converter 4. Check the rate of Network. 5. Returned to the manufacturer for repair. 4. Network packet loss Solution: 1.
