15.5. Tool Rotation/Reciprocating knife fuses

Fuse Location
Procedure
1. Fuses are available from beneath the Toolhead cover.
2. Remove fuse F9 or F10 and check with ohm - meter. If blown, replace with a new identical fuse.
3. Insert main power cable into the wall socket and turn main power ON.
Fuse Details
Name
F9
F10
F10

15.6. Chiller fuse, Hyfra (blue top)

Fuse
T 2A 250V 1 1/4 x 1/4 in (6,3 x 32 mm)
T 2A 250V 1 1/4 x 1/4 in (6,3 x 32 mm)
T 4A 250V 1 1/4 x 1/4 in (6,3 x 32 mm) (FoamHead)
