WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in
serious injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors or
liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS:
•
Do not try to light any appliance
•
Do not touch any electrical switch; do not use any
phone in your building
•
Leave the building immediately
•
Immediately call your gas supplier from a neighbor's
phone. Follow the gas suppliers instructions
If you can not reach your gas supplier, call the fire
•
department
- Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
English and French Installatio n Manuals available thro ugh y o
lo cal d ealer o r visit o ur website at: www.archgard.com
Les m anuels d ' installatio n en anglais et en franç a is so n
d ispo nibles chez vo tre d é taillant lo cal o u en visitant no tre site
web: www.archgard.com
INSTALLER:
LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER:
RETAIN THIS MANUAL FOR FUTURE REFERENCE.
ARCHGARD FIREPLACE PRODUCTS
7116 Beatty Drive
Missio n, BC V2V 6B4 Canad a
I
ntrigue 36
INSTALLATION, OPERATION, AND
MAINTENANCE MANUAL
MODEL:
GAS FIRED DIRECT VENT FIREPLACE
S/ N 640283 AND UP
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA only) or
mobile home where not prohibited by local codes.
This appliance is only for use with the type of gas indicated
on the rating plate. This appliance is not convertible for use
with other gases, unless a certified kit is used.
ur
Gas Fireplace Energy Efficiency Rating
71.13%
Based on CSA P.4.1-15
UF0200
200- U200- 04
February 11, 2020
Advertisement
Table of Contents
Related Manuals for Ambiance Fireplaces Intrigue 36
Summary of Contents for Ambiance Fireplaces Intrigue 36
- Page 1 ntrigue 36 INSTALLATION, OPERATION, AND MAINTENANCE MANUAL UF0200 MODEL: GAS FIRED DIRECT VENT FIREPLACE S/ N 640283 AND UP This appliance may be installed in an aftermarket permanently located, manufactured home (USA only) or mobile home where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the rating plate.
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1.0 Introduction 14.0 Conversion Kit Instructions 14.1 Prepare the Fireplace 2.0 Safety Information 14.2 Pilot Conversion 3.0 Technical Information 14.3 Convert the Gas Valve 3.1 Appliance Certification 14.4 Complete the Conversion 3.2 Installation Codes 15.0 Firebox Liner Installation 3.3 Specifications 15.1 Brick Panel Installation 3.4 High Altitude Installation... -
Page 3: Introduction
General Information 1.0 Introduction Thank You and Congratulations for choosing an Ambiance Gas Fireplace! The UF0200 is one of the most advanced Direct Vent heaters available today. It is solidly designed using the latest technology and manufactured to the highest quality. It is our aim to provide you with an appliance that brings many trouble-free years of reliable service. Some of the many features of your UF0200 are: Heater Classification This fireplace is classified as a heating appliance. -
Page 4: Safety Information
General Information 2.0 Safety Information Caution FOR YOUR SAFETY - Do not install or operate your UF0200 without reading and understanding this manual. Any installation or operational deviation from this instruction manual voids the warranty and may prove hazardous. This appliance must be installed by a qualified gas installer and the installation must conform to the installation codes •... -
Page 5: Technical Information
General Information 3.0 Technical Information 3.1 Appliance Certification This appliance was listed by QAI Laboratory Inc to the following USA and Canadian gas appliance standards. - ANSI Z21.88-2017/CSA 2.33-2017 Vented Gas Fireplace Heaters - CSA-2.17-2017, Gas-Fired Appliances for Use at High Altitudes - CSA P.4.1-15 testing method for measuring annual fireplace efficiency - CSA 22.2 No.3-M1988(R2014) electrical standard The listing label is attached to the appliance on the bottom left side of the appliance. -
Page 6: Rating Plate
General Information 4.0 Rating Plate 12 ” SHEET DO NOT REMOVE THIS LABEL UF0200 MODEL: (SIT 885 Proflame) RADIATEUR VENTILE, CIRCUL LISTED VENTED GAS FIREPLACE HEATER and GAS-FIRED APPLIANCES FOR USE AT HIGH ALTITUDES. Tested to: ANSI CSA 2.17-2017, CSA P.4.1-15 e Z21.88-2017 / CSA 2.33-2017, CSA 2.17-2017, CSA P.4.1-15, and CSA 22.2 No.3-M1988 (R2014). -
Page 7: Installation Checklist
Installation 5.0 Installation Checklist This standard installation checklist is to be used by the installer in conjunction with, not instead of, the instructions contained within this installation manual. Customer: Date Installed: Install Address: Location of Fireplace: Installer: Appliance Install: (Section 9.0) IF NO, WHY NOT? Standoffs, side nailing flanges, and top nailing flange extension are installed. -
Page 8: Appliance Overview
Installation 6.0 Appliance Overview 6.1 Appliance Overview The Proflame II control board and the valve are located below the firebox, hidden by the Valve Access Cover. The rating plate is located under the firebox, on the left side. The fan is located under the firebox in the back right side. -
Page 9: Barrier Screen
Installation 6.3 Barrier Screen (UA9000 & UA9001) Note: Barrier screens are packaged separately from the fireplace. There are three options available - see Section 20 for part numbers. UA9001 includes tile finishing strips. See Section 12.3. Removal Installation To remove the screen, slide the two retainer tabs on the top of To install the screen, insert the two pins on the bottom of the the barrier screen toward the center of the screen, tilt the screen screen in the holes on the bottom of the fireplace. - Page 10 Installation Barrier Screen With Trim (UA9002) Step 1: Thread the included bolts in so that about 1/8" (3.175 Step 2: Align the brackets on the trim with the four screws. Hang mm) remains exposed. the trim on the brackets at the desired depth. 1/8"...
-
Page 11: Glass Door Installation
Installation 6.4 Glass Door Installation WARNING: Do not operate appliance with the glass front removed, cracked, or broken. Replacement of the glass should be done by a licensed or qualified service person. Do not attempt to remove the glass door when the appliance is hot. Be sure there are no fingerprints left on the glass panels during install or when cleaning as high temperatures can bake these prints on permanently. -
Page 12: Accessing The Controls
Installation 6.5 Accessing The Controls To access the control board or valve: Ensure the fireplace is off and cool. Remove the barrier screen (See Section 6.3). Rotate the valve access cover backward and lift to remove from the fireplace. Figure 6.5.01: To install the valve access cover, drop it in place. -
Page 13: Electrical Connections
Installation 7.0 Electrical Connections The UF0200 comes complete with an adjustable 6 speed fan and variable lights wired directly to the main control module. Do not cut or remove the grounding prong from the main power supply plug. CAUTION: Label all wires prior to disconnection when servicing. NOTE: This appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI / NFPA 70, or the Canadian Electrical code, CSA C22.1. -
Page 14: Fireplace Dimensions
Installation 8.0 Fireplace Dimensions Right Side View Front View 17.46cm 6.875in 9.84cm 3.875in 109.18cm 42.986in 92.54cm 60.91cm 49.85cm 85.09cm 36.434in 23.982in 33.500in 19.625in 71.12cm 28.000in 5.87cm 2.310in 15.05cm 21.30cm 5.926in 8.384in 80.65cm Left Side View 31.752in 17.46cm 90.48cm 6.875in 35.622in 7.45cm 9.84cm 2.934in... -
Page 15: Prepare The Fireplace
Installation 9.0 Prepare The Fireplace 9.1 Installation Overview NOTE This product must be installed by a qualified installer. The installer should follow the procedure best suited for each specific installation. Frame an opening for the fireplace, allowing for vent installation and type of installation (corner or flat wall application). Bend side nailing flange tabs. -
Page 16: Nailing Flange Extension
Installation 9.3 Nailing Flange Extension DETAIL A SCALE 1 : 6 Figure 9.3.01: NAME DATE DIMENSI NS A E IN INCHES T LE ANCES: D AWN F ACTI NAL 1 32 LACE DECIMAL .015 CHECKED TH EE LACE DECIMAL .005 Attaching The Nailing Flange Extension Adjusting The Top Nailing Flange MATE IAL... - Page 17 Installation Attaching The Nailing Flange Extension Heat Shield Slip the nailing flange extension heat shield over the studs located on the back of the nailing flange extension. Use the three (3) nuts included in the manual bag to secure the heat shield in place. Figure 9.3.04:...
-
Page 18: Venting Instructions
Installation 10.0 Venting Instructions WARNING: Operation of this heater when not connected to a properly installed and maintained venting system can result in carbon monoxide (CO) poisoning and possible death. The appliance must not be connected to a chimney flue serving a separate solid fuel burning appliance. - Page 19 Installation Typical Venting Configuration Flex to Roofline Rigid to Roofline Combination to Roofline Termination Termination Termination Storm Storm Storm Collar Collar Collar Flashing Flashing Flashing Flex to Rigid Adapter Rigid Rigid Venting Venting Attic Attic Attic Insulation Insulation Insulation Shield Shield Shield Firestop...
-
Page 20: Vent Run Guide
Installation 10.1 Vent Run Guide Horizontal Vent Sections rise 1/4 /ft (21mm/m) NAME DATE DIMENSI NS A E IN INCHES T LE ANCES: F ACTI NAL LACE DECIMAL 1 32 .015 D AWN TH EE LACE DECIMAL .005 MATE IAL CHECKED ALL BENDS A E ASS MED BE 90... -
Page 21: Vent Restrictor Configuration
Installation 10.2 Vent Restrictor Configuration There are two possible vent restrictor settings based on venting configuration. This fireplace is shipped with the restrictor in the Setting 1 position. Follow the chart in Section 10.1 for recommended settings. It is important to remember each installation is unique and affected by various factors including venting configuration, altitude, and climate. - Page 22 Installation 10.3 Third Party Venting Components ATTENTION NO OTHER VENTING SYSTEM OR COMPONENTS MAY BE USED. Part numbers shown are correct at the time of printing and should be confirmed with the manufacturer prior to purchase. Follow manufacturer instructions for installation of termination. Selkirk Duravent Amerivent...
-
Page 23: Third Party Venting Components
Installation Third Party Venting Components (cont'd) Selkirk Duravent Amerivent Roof Flashings 0/12 to 6/12 Pitches DVR6-AF012 4DT-AF6 46DVA-F6 4MFA & 6EMFA 4DF (0/12 to 5/12) 4DF12 (6/12 to 7/12 to 12/12 Pitches DVR6-AF712 4DT-AF12 46DVA-F12 4MFB & 6EMFB 12/12) Flat Roof DVR6-TCF 46DVA-FF Metal Roof Flashings... -
Page 24: Termination Location Clearances
Installation 10.4 Termination Location Clearances Legend: = Vent terminal = Air supply inlet = Area where terminal is not permitted Figure 10.4.01: Approved cap Approved vent pipe Figure 10.4.02:... - Page 25 Installation Canadian Installations US Installations Clearance above grade, veranda, porch, 12" (305 mm) 12" (305 mm) deck, or balcony Clearance to window or door that may be 12" (305 mm) 9" (229 mm) opened Clearance to permanently closed window• Vertical clearance to ventilated soffit 18"...
-
Page 26: Snorkel Termination Installation
Installation 10.5 Snorkel Termination Installation Follow snorkel termination manufacturer's installation instructions and local codes • The vertical rise of a snorkel termination can be used in place of a vertical vent rise. Follow the snorkel termination manufacturer's • information for installation A snorkel counts as two 90 elbows out of the total number of allowable elbows in the vent run. -
Page 27: Framing
Installation 11.0 Framing 11.1 Wall Enclosure Rough Opening IMPORTANT Framing dimensions should allow for wall covering thickness and fireplace facing materials. If using a hearth, adjust rough opening size as necessary to maintain at least minimum clearance requirements. Non–combustible facing material may be applied over (but not directly to) fireplace face. This will prevent facing material from falling off due to heat expansion. -
Page 28: Typical Corner Installation
Installation 11.2 Typical Corner Installation Dimensions shown in Figure 11.2.01 are when using 1/2" wall board. If using a facing material that is an alternative thickness, refer to the table below for appropriate dimensions. Refer to Section 9.2 and Section 9.3 for information on nailing flange settings and installation. 74.43cm 29.302in 92.68cm... -
Page 29: Ventilation Framing
Installation 11.3 Ventilation Framing Ventilation framing dimensions are based on Duravent venting components. If other third party venting components are used, refer to the installation instructions from the third party manufacturer for installation information. The following critical dimensions must be maintained regardless of venting manufacturer: Item Critical Dimensions... -
Page 30: Clearances To Combustibles
Installation 12.0 Clearances to Combustibles WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury or loss of life. WARNING: TOP NAILING FLANGE EXTENSION MUST BE ASSEMBLED AND ATTACHED TO FIREPLACE. DO NOT REMOVE. TOP NAILING FLANGE EXTENSION IS NOT LOAD BEARING 12.1 Mantel Clearances 12.000in 30.48cm... -
Page 31: Sidewall Clearances
Installation 12.2 Sidewall Clearances Maintain a minimum of 4" (10.16 mm) clearance from the side of the glass door to sidewalls or mantel supports. 10.16cm 5.08cm 4.000in 90.49cm 35.624in Figure 12.2.01 12.3 Optional Hearth Installation Any hearth extending 12" or less from the front fireplace must Never block the be constructed of non-combustible material. -
Page 32: Finishing (Ua9001)
Installation 12.3 Finishing (UA9001) Install the finishing strips using the twelve (12) 1/8" rivets included. Never place combustible material over the face of the fireplace. See Figure 12.3.02 for finishing details. DETAIL B Figure 12.3.01 SCALE 3 : 1 Sheet1 NAME SIGNED DATE... -
Page 33: Gas Connections
Installation 13.0 Gas Connections Before connecting the appliance to the gas supply line, double check that the appliance you have purchased is designed for the gas type you are using. The gas type markings are located on the rating plate (See Section 4.0 and Section 6.2) and also on the appliance’s gas valve. -
Page 34: Supplying Gas
Installation 13.2 Supplying Gas Before you begin: Ensure the fireplace is off and cool before servicing • Ensure the gas supply is turned OFF and disconnect power supply to the fireplace (including backup batteries) • Remove the barrier screen (see Section 6.3) •... -
Page 35: Conversion Kit Instructions
Installation 14.0 Conversion Kit Instructions IMPORTANT: This fireplace is Natural gas ready. If converting to LP gas, follow instructions below. WARNING: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturers instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly, a fire, explosion or productions of carbon monoxide may result, causing property damage, personal injury or loss of life. -
Page 36: Convert The Gas Valve
Installation 14.3 Convert the Gas Valve WARNING: Installation of this conversion kit must only be undertaken by a qualified and certified gas appliance installer. Verify that the following items are present in the package: Pressure regulator assembly (E) • Two (2) screws (F) •... -
Page 37: Firebox Liner Installation
Installation 15.0 Firebox Liner Installation 15.1 Brick Panel Installation The following steps highlight the procedure for installing brick panel firebox liners. Handle the panels with care as they are delicate. Inspect the panels to ensure that no damage has occurred inside the package. Please report any damage immediately to your Authorized Ambiance Dealer. - Page 38 Installation Step 5: Place the rear panel in the back of the firebox with the Step 6: Continue to hold the rear panel while placing the left or thick grout line at the top. right side panel. Figure 15.1.05: Figure 15.1.06: Step 7: Install the first panel retainer clip to hold the left or right Step 8: Install the other side panel using the remaining panel side panel in place.
-
Page 39: Reflective Glass Installation
Installation 15.2 Reflective Glass Installation The following steps highlight the procedure for installing Reflective Ceramic Glass liner. We recommend using clean cotton gloves when handling panels. Handle the panels with care. Inspect the panels to ensure that no damage has occurred inside the package. Please report any damage immediately to your Authorized Ambiance Dealer. - Page 40 Installation Step 6: Continue to hold the rear panel as you slide the left or right side panel between the two bends on the lower spacer. Slide panel between the two bends on the lower spacer. Figure 15.2.05: Figure 15.2.06: Step 7: Install the right side glass retainer using one of the screws Step 8: Install the other side panel between the two bends on removed in Step 1.
-
Page 41: Log Set Installation
Installation 16.0 Log Set Installation Failure to position the logs in accordance with the preceding diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. Never use WARNING unapproved burner media such as rock wool or similar material. The use of unapproved burner media may cause damage or injury and will void product warranty. - Page 42 Installation Step 1: Align the holes on the bottom of Log 1 with the pins at the Step 2: Carefully push Log 1 onto the pins. back of the burner. Figure 16.0.02: Figure 16.0.03: Step 3: Place a row of embers along the front of Log 1. Avoid Step 4: Place Log 2 on the pins located on the left side of the placing embers over the burner openings.
- Page 43 Installation Step 7: Align Log 7 on the pins located on the middle of the Step 8: Fill the space to the left of Log 7 with embers. Avoid blocking burner ports. burner. Figure 16.0.08: Figure 16.0.09: Step 9: Make sure the secondary air supply, including the gap Step 10: Place Log 4 on top of Log 3 and the pin located behind around the burner, is NOT blocked by embers.
- Page 44 Installation Step 13: Place Log 6 on the pin located in Log 1 and rest the front Step 14: Place embers evenly along the burner surround. Do on Log 2. not block the gap that surrounds the burner as this is a source of secondary air.
-
Page 45: Operation
Operation 17.0 Operation 17.1 Before Lighting WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Do not operate the appliance with the glass front removed, cracked or broken. Replacement of broken glass should be done by a licensed or qualified service person. -
Page 46: Lighting Instructions
Operation 17.3 Lighting Instructions 11-7/8” SHEET The following information may be found on the fireplace rating plate. See Section 6.2 for the rating plate location. FOR YOUR SAFETY READ BEFORE LIGHTING POUR VOTRE SÉ CURITÉ VEUILLEZ LIRE AVANT L’ ALLUMAGE If you do not follow these instructions exactly, a fire of explosion may result causing property WARNING: damage, personal injury or loss of life. -
Page 47: Dynamic Start Advantage
Operation 17.4 Dynamic Start Advantage This fireplace comes standard with the Dynamic Start Advantage. This new electronic ignition system is the latest in fireplace technology. It helps to create a better draft, better flame appearance, less condensation on the glass, and years of carefree operation. How the system works: When starting a solid fuel wood burning fireplace you build a fire. -
Page 48: Remote Control Operation
Operation 17.5 Remote Control Operation IMPORTANT The Proflame II Remote is an integrated part of the Proflame II System, which consists of a Proflame II Remote, to be used in conjunction with Integrated Fireplace Control (Proflame II Control Module). Figure 17.5.01 The Proflame II Remote provides for controlling the following hearth appliance functions: Main Burner ON/OFF Main Burner flame modulation (6 levels) - Page 49 Operation Remote Display Continuous Pilot on Demand Figure 17.5.02 WARNING THE REMOTE AND RECEIVER ARE RADIO FREQUENCY DEVICES. PLACING THE REMOTE IN OR NEAR METAL ENCLOSURES MAY REDUCE THE SIGNAL RANGE. Wall Mount Remote (optional) Figure 17.5.03...
- Page 50 Operation Initializing the System for Handheld / Wall Mount Remote Operation Connect IFC Control Module to AC power supply. A single “beep” will indicate the presence of power. NOTE: This will initiate Pilot Start-up in Manual Mode. The pilot will spark repeatedly and ignite if gas has been supplied to the unit. Sync the control board to the remote to turn main burner and pilot off using the steps below.
- Page 51 Operation Temperature Indication Display With the system in the OFF position, press the Thermostat Key and the Mode Key at the same time to switch between Fahrenheit (F) or Celsius (C). Verify on the LCD screen the correct designation is visible. Figure 17.5.06: This function is disabled when in SMART Thermostat Mode and does not operate in the first two minutes of operation during the Dynamic Start Advantage.
- Page 52 Operation Dimmer Control (Light) This function is used to control the variable lights. To activate this function use the Mode Key to index to the variable light icon. The intensity of the output can be adjusted through six (6) levels. Use the Up/Down Arrow Keys to adjust the output level.
- Page 53 Operation Continuous Pilot on Demand / Intermittent Pilot (CPI/IPI) Selection With the system in “OFF” position press the Mode Key to index to the CPI mode icon. Pressing the UP Arrow Key will activate the Continuous Pilot on Demand Ignition mode (CPI). Pressing the Down Arrow Key will return to IPI. A single “beep”...
- Page 54 Operation Automatic Safety Shut-Off This system will execute an automatic turn OFF command after a 24hr continuous main burner flame ignition. This allows the system to verify correct safety functions. Diagnostic Indications Information LOW BATTERY CONDITION (Less than 4V): -Battery Icon will appear on LCD remote control display. Replace batteries. Remote Control -Red LED indicator will enter a (1) blink sequence.
-
Page 55: Maintenance
Maintenance 18.0 Maintenance CAUTION: Do not conduct maintenance on the appliance while it is operating or while it is still hot. Always verify proper operation after servicing. 18.1 Cleaning and Routine Maintenance The exterior painted surfaces, glass, and metal plated trims may be cleaned with a soft, non-abrasive cloth and water or a suitable, mild, non-abrasive cleaner. -
Page 56: Servicing Under Warranty
Maintenance 18.2 Servicing Under Warranty Before servicing, read the terms and conditions of the warranty at the back of this manual. Contact the authorized Ambiance dealer where you purchased the appliance from and provide them with details of the problem, along with the initial installation information (from the front of this manual). -
Page 57: Adjusting The Primary Air
Maintenance 18.5 Adjusting the Primary Air The UF0200 includes an air shutter located under the firebox which may be used to adjust the primary air to achieve the ideal flame as shown in Figure 18.5.01. To adjust, loosen the wing nut on the air shutter and adjust as shown in Figure 18.5.02. To open the air shutter and increase air flow to the burner, slide the air shutter to the left. -
Page 58: Replacing Batteries
Maintenance 18.6 Replacing Batteries Ensure the fireplace is off and cool before servicing. Disconnect power supply to the fireplace (including backup batteries). Turn off gas supply. Remove the barrier screen (see Section 6.3). Remove the valve access cover (see Section 6.5). Remove the battery holder from the side of the control board. -
Page 59: Replacing Light Bulbs
Maintenance 18.8 Replacing Light Bulbs Caution: Always handle bulbs with cotton gloves as finger prints may reduce the life of the bulb. We recommend replacing both bulbs at the same time. Ensure the fireplace is off and cool before servicing. Disconnect power supply to the fireplace (including back- up batteries). -
Page 60: Replacing The Control Board
Maintenance 18.9 Replacing the Control Board CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. This appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical code, CSA C22.1. -
Page 61: Wiring Schematic
Maintenance 18.10 Wiring Schematic SW1 Botton(red) Sync button On/Off override jumper Figure 18.10.01... -
Page 62: Removing The Masking Plate
Maintenance 18.11 Removing the Masking Plate The masking plate located in the back of the firebox may need to be removed to install panels or to service the appliance. Use the following instructions to remove the masking plate. Before you begin: Ensure the fireplace is off and cool before servicing •... -
Page 63: Removing The Baffle
Maintenance 18.12 Removing the Ba e The baffle located in the top of the firebox may need to be removed to service the appliance. Use the following instructions to remove the baffle. Before you begin: Ensure the fireplace is off and cool before servicing •... -
Page 64: Removing The Restrictor
Maintenance 18.13 Removing the Restrictor The restrictor must be removed in high altitude locations when the venting configuration meets certain criteria (see Section 10.1). Use the following instructions to remove the restrictor. Before you begin: Ensure the fireplace is off and cool before servicing •... -
Page 65: Removing The Burner Surround
Maintenance 18.14 Removing the Burner Surround Before you begin: Ensure the fireplace is off and cool before servicing • • Ensure the gas supply is turned OFF and disconnect the power supply (including backup batteries) Remove barrier screen (see Section 6.3) •... -
Page 66: Replacing The Burner
Maintenance 18.15 Replacing the Burner Before you begin: Ensure the fireplace is off and cool before servicing • • Ensure the gas supply is turned OFF and disconnect the power supply (including backup batteries) Remove the barrier screen (see Section 6.3) •... -
Page 67: Replacing The Pilot
Maintenance 18.16 Replacing the Pilot Before you begin: Ensure the fireplace is off and cool before servicing • • Ensure the gas supply is turned OFF and disconnect the power supply (including backup batteries) Remove the barrier screen (see Section 6.3) •... -
Page 68: Replacing The Fan
Maintenance 18.17 Replacing the Fan CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. This appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical code, CSA C22.1. -
Page 69: Replacing The Light Bases
Maintenance 18.18 Replacing the Light Bases Before you begin: Ensure the fireplace is off and cool before servicing • • Ensure the gas supply is turned OFF and disconnect the power supply (including backup batteries) Remove the barrier screen (see Section 6.3) •... -
Page 70: Replacing The Valve
Maintenance 18.19 Replacing the Valve Before you begin: Ensure the fireplace is off and cool before servicing • • Ensure the gas supply is turned OFF and disconnect the power supply (including backup batteries) Remove the barrier screen (see Section 6.3) •... -
Page 71: Troubleshooting
Maintenance 18.20 Troubleshooting Issue Solution The pilot igniter won't spark. 1. Ensure the ON/OFF override jumper is installed correctly. 2. Ensure main power is ON and new batteries are installed in the remote control (3 x AAA) and backup battery pack on the control board (4 x AA). 3. -
Page 72: Frequently Asked Questions
Maintenance 19.0 Frequently Asked Questions Listed below are some frequently asked questions regarding Ambiance Gas Fireplaces. If you have questions that are not listed below, or are not answered in this manual, please contact your Authorized Ambiance Dealer. Q. Why does my glass have a condensation “fog” when the appliance is first lit? A. -
Page 73: Replacement Parts List
Maintenance 20.0 Replacement Parts List Item # Item Description Unit 200-U200-04 English Owner's Manual 200-U200F-04 French Owner's Manual URP-893-0160 Replacement Manual Package UA9000 Barrier Screen UA9001 Barrier Screen with Tile Finishing Strips Barrier Screen with 2" Decorative Trim UA9002 308-6060 SIT Proflame II Dynamic Start Advantage with Continuous Pilot on Demand 308-6022 Handheld Remote... -
Page 74: Year Limited Warranty
Warranty Ambiance Limited Warranty 10 Year Limited Warranty This Limited 10 Year Warranty will not become effective until the Warranty Registration Form has been completed and mailed to Archgard Industries, 7116 Beatty Drive, Mission, BC, Canada, V2V 6B4. This registration form must be received within 30 days of installation. Failure to do so may result in delayed warranty coverage and submission of proof of purchase will be required. -
Page 75: Lifetime Warranty
Warranty Lifetime Warranty THIS LIFETIME WARRANTY COVERAGE WILL BE EXTENDED AS DESCRIBED BELOW PROVIDED ALL WARRANTY CONDITIONS AND REQUIREMENTS ARE MET AS OUTLINED IN THE 10 YEAR LIMITED WARRANTY POLICY. LIFETIME WARRANTY COVERAGE LIFETIME WARRANTY IS EXTENDED AS FOLLOWS: Archgard Industries warranties to the original purchaser that the firebox, heat exchanger, fibre logs, pan burner and glass panel of this Ambiance Fireplace will not be defective in the material or workmanship under normal use and service as long as you own this product. - Page 76 NOTES...
- Page 77 NOTES...
- Page 78 NOTES...
- Page 79 POSTAGE WARRANTY REGISTRATION ARCHGARD INDUSTRIES LTD. 7116 BEATTY DRIVE MISSION, B.C. CANADA V2V 6B4 FOLD DOWN AT LINE FOLD DOWN AT LINE & TAPE CLOSED Model # : Date Installed: Serial #: UF0200 Name: Address: City: State/Prov: ZIP: Phone: ( _____ ) Dealer’s Name &...
