Ambiance Fireplaces Intrigue INT-200 Installation And Operating Manual

Intrigue direct vent gas fireplace
Hide thumbs Also See for Intrigue INT-200:
Table of Contents

Advertisement

Quick Links

INSTALLATION AND OPERATING MANUAL
English and French Installation Manuals Available Through Your Local Dealer or Visit Our Website at www.kozyheat.com
Les manuels d'installation en anglais et en français sont disponibles chez votre détaillant local ou en visitant notre site Web : www.kozyheat.com
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE
This appliance may be installed in an aftermarket permanently located,
manufactured home (USA only) or mobile home where not prohibited by local
codes.
This appliance is only for use with the type of gas indicated on the rating plate.
This appliance is not convertible for use with other gases, unless a certified kit is
used.
WARNING: If the information in these instructions is not followed exactly, a
fire or explosion may result, causing property damage, personal injury or loss
of life.
Do not store or use gasoline or other flammable vapors and liquids in the
—
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
◙ Do not light any appliance.
◙ Do not touch any electrical switch: do not use any phone in your building.
◙ Immediately call gas supplier from a neighbors phone. Follow the gas
supplier instructions.
◙ If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
WARNING
HOT GLASS WILL CAUSE BURNS.
DO NOT TOUCH GLASS UNTIL COOLED.
NEVER ALLOW CHILDREN TO TOUCH GLASS.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
Direct Vent Gas Fireplace
Model: #INT-200
.
Report No. 216-S-35b-6.5
JUNE 2012 INT-REV-05
