ARCHGARD FIREPLACE PRODUCTS
7116 Beatty Drive
Mission, BC V2V 6B4 Canada
INSTALLATION, OPERATION, AND
MAINTENANCE MANUAL
Inspiration 34
MODEL: UF0600
GAS FIRED DIRECT VENT
FIREPLACE INSERT
S/N 630562 AND UP
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA only) or
mobile home where not prohibited by local codes.
This appliance is only for use with the type of gas indicated
on the rating plate. This appliance is not convertible for use
with other gases, unless a certified kit is used.
Gas Fireplace Energy Efficiency Rating
71.93%
Based on CSA P.4.1-15
UF0610
200-0600-07
November 13, 2019
