Yardworks 060-1981-4 Instruction Manual

20˝ (51 cm) brushless 3-in-1 lawn mower
Hide thumbs
Table of Contents

Advertisement

Quick Links

20˝ (51 CM) BRUSHLESS 3-IN-1 LAWN MOWER
model number 060-1981-4 | contact us: 1.866.523.5218
3026035
IMPORTANT:
Instruction
Read and follow all safety rules and operating
Manual
instructions before using this product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 060-1981-4 and is the answer not in the manual?

Questions and answers

Related Manuals for Yardworks 060-1981-4

Summary of Contents for Yardworks 060-1981-4

  • Page 1 20˝ (51 CM) BRUSHLESS 3-IN-1 LAWN MOWER model number 060-1981-4 | contact us: 1.866.523.5218 3026035 IMPORTANT: Instruction Read and follow all safety rules and operating Manual instructions before using this product.
  • Page 2 060-1981-4 | contact us: 1.866.523.5218 model no. 060-1981-4 | contact us: 1.866.523.5218...
  • Page 3 060-1981-4 | contact us: 1.866.523.5218 Introduction Safety Instructions and Symbols Product Specifications Product Diagram Assembly Operation Maintenance Storage Troubleshooting Exploded View Parts List Warranty...
  • Page 4 Congratulations on your purchase of your new Yardworks tool. It has been designed, engineered ® and manufactured to give you the best possible dependability and performance. Should you experience any problem you cannot easily remedy, please contact our Yardworks cus- ® tomer service line at 1.866.523.5218.
  • Page 5 060-1981-4 | contact us: 1.866.523.5218 READ ALL INSTRUCTIONS an indoor dry and locked-up place — out of reach of children. FOR ALL LAWN MOWERS 11) Maintain lawn mower with care — Keep 1) Avoid dangerous environments — cutting edges sharp and clean for Don’t use lawn mowers in damp or wet...
  • Page 6 060-1981-4 | contact us: 1.866.523.5218 FOR ALL BATTERY-OPERATED or modified batteries may exhibit GARDENING APPLIANCES: unpredictable behaviour resulting in fire, explosion or risk of injury. 1. Prevent unintentional starting. Ensure the switch is in the off-position before 8. Do not expose a battery pack...
  • Page 7 060-1981-4 | contact us: 1.866.523.5218 5°C/68°F ± 9°F). battery terminals together may cause burns or fire. When disposing of battery packs, d) Do not remove battery pack from its keep battery packs of different original packaging until required for electrochemical systems separate use.
  • Page 8 060-1981-4 | contact us: 1.866.523.5218 7. Do not pull machine backwards unless injury. Operation on all slopes requires extra absolutely necessary. Always look caution. If you feel uneasy on a slope, do down and behind before and while not mow it.
  • Page 9 060-1981-4 | contact us: 1.866.523.5218 other debris build-up. before starting the motor. 4. If you strike a foreign object, stop d) Never attempt to make a wheel height and inspect the machine. Repair, if adjustment while the motor is running.
  • Page 10 060-1981-4 | contact us: 1.866.523.5218 model no. 060-1981-4 | contact us: 1.866.523.5218 SAVE THESE INSTRUCTIONS 1.4 Maintenance a) Check the blade and the motor mounting Information for radiated emission bolts at frequent intervals for proper This device complies with Canadian ICES-001.
  • Page 11 060-1981-4 | contact us: 1.866.523.5218 Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product effectively and safely.
  • Page 12 060-1981-4 | contact us: 1.866.523.5218 PRODUCT SPECIFICATIONS Voltage 48 V No load speed 2800/min Deck size 20" (51 cm) Cutting width 19" (48 cm) Cutting height range 1 1/2 – 4" (3.8 – 10.2 cm) Collection capacity 50 L (1.4 Bushels)
  • Page 13 060-1981-4 | contact us: 1.866.523.5218 Switch lever Safety button Upper Handle Cable Grass collection bag Rear discharge guard Upper handle lock knob Lower handle Lower handle lock knob 10. Rear wheel 11. Battery pack cover 12. Carry handle 13.
  • Page 14 060-1981-4 | contact us: 1.866.523.5218 model no. 060-1981-4 | contact us: 1.866.523.5218 To reduce the risk of injury, user must read instruction manual Intended Use This product is intended for domestic lawn mowing. • Mowing with grass collection bag attached - Standard lawn mowing with grass collection bag attached.
  • Page 15 060-1981-4 | contact us: 1.866.523.5218 3) Rotate the lower handle lock knob into the aligned holes to lock the lower handle on the deck. (See Fig. A3, A4.) 2. ASSEMBLING THE UPPER HANDLE 1) Attach the upper handle onto the outside of the lower handle. Be sure to carefully align the holes found on the lower handle and the upper handle.
  • Page 16 060-1981-4 | contact us: 1.866.523.5218 3. GRASS COLLECTION BAG FITTING 1) Raise the rear discharge guard and hold it up, remove the mulching block if it is in the rear chute. (See Fig. C1.) 2) Raise the rear discharge guard and hold it up. Pick up the grass collection bag by the handle, and position the left and right hooks of grass collection bag onto the mower (See Fig.
  • Page 17 060-1981-4 | contact us: 1.866.523.5218 4. REMOVING / EMPTYING THE GRASS COLLECTION BAG - Removing (See Fig. D) Raise the rear discharge guard and hold it up. Lift the grass collection bag by the handle upwards a little, and then remove the grass collection bag from the rear discharge chute.
  • Page 18 060-1981-4 | contact us: 1.866.523.5218 5. ASSEMBLY OF THE SIDE DISCHARGE CHUTE NOTE: The side discharge chute is used to distribute grass clippings from the side of the mower while it is in use. To use this function, the grass collection bag is NOT required to be assembled on the lawn mower.
  • Page 19 060-1981-4 | contact us: 1.866.523.5218 6. ADJUSTING THE CUTTING HEIGHT (SEE FIG. F) NOTE: • Always try to adjust the cutting height of the lawn mower while positioned on the area of grass you plan to mow. • It is recommended to start on a higher setting and mow a trial area of lawn before deciding on the final cutting height position.
  • Page 20 060-1981-4 | contact us: 1.866.523.5218 model no. 060-1981-4 | contact us: 1.866.523.5218 1. CHARGING THE BATTERY PACK IMPORTANT NOTES FOR CHARGING BATTERY The battery in your new tool is not charged when it leaves the plant; therefore, it must be full charged before using the first time.
  • Page 21 060-1981-4 | contact us: 1.866.523.5218 CHARGING INDICATOR This charger is designed to detect some problems that can arise with battery packs. Indicator lights indicate problems (see table below). Light ON/ Flash Status Defective battery. Red on Battery Temperature Protection.
  • Page 22 060-1981-4 | contact us: 1.866.523.5218 OPERATION 1. STARTING AND STOPPING STARTING (SEE FIG. I) Depress the safety button first and pull the switch lever towards the handle, then the mower will start. STOPPING Release the switch lever to stop the mower.
  • Page 23 060-1981-4 | contact us: 1.866.523.5218 4. MOWING TIPS (Catcher Mowing + Side Discharge Mowing) NOTE: Always inspect area where mower is to be used and remove all stones, sticks, wire, metal and other debris which might be thrown by the rotating blade.
  • Page 24 060-1981-4 | contact us: 1.866.523.5218 model no. 060-1981-4 | contact us: 1.866.523.5218 Under normal conditions, the mulched grass will biodegrade quickly to provide nutrients to the lawn. Please review the following recommendations for optimum mulching performance. 1) Avoid mowing when the grass is wet from rain or dew. Wet grass may form clumps which interfere with the mulching action and reduce runtime.
  • Page 25 060-1981-4 | contact us: 1.866.523.5218 NOTE: To ensure long and reliable service, perform the following maintenance procedures regularly. Check for obvious defects such as a loose, dislodged or a damaged blade, loose fittings, and worn or damaged components. Check that the covers and guards are all undamaged and are correctly attached to mower.
  • Page 26 060-1981-4 | contact us: 1.866.523.5218 model no. 060-1981-4 | contact us: 1.866.523.5218...
  • Page 27 060-1981-4 | contact us: 1.866.523.5218 Stop the mower. Remove the battery back. Clean the exterior of the machine thoroughly using a soft brush and cloth. Do not use water, solvents or polishes. Remove all grass and debris, especially from the ventilation slots.
  • Page 28 060-1981-4 | contact us: 1.866.523.5218 The following table gives checks and actions that you can perform if your machine does not operate correctly. If these do not identify/remedy the problem, contact Yardworks at 1-866-523-5281. ® Problem Solution Release switch lever to turn mower off. Remove the battery pack. Turn Mower doesn’t run when...
  • Page 29 060-1981-4 | contact us: 1.866.523.5218...
  • Page 30 060-1981-4 | contact us: 1.866.523.5218 Item No. Description QTY. Item No. Description QTY. Battery Cover Switch Right Decoration Cover 1 Button Cap Right Housing Safety Guard Left Housing Fixed Block Motor Cabinet Rear Cover Mounting Plate Lower Handle...
  • Page 31 060-1981-4 | contact us: 1.866.523.5218 FIVE-YEAR LIMITED WARRANTY material and workmanship for a period of three hundred and sixty-five (365) days For five (5) years from the date of purchase from the date of retail purchase. within Canada, YARDWORKS CANADA ®...
  • Page 32 060-1981-4 | contact us: 1.866.523.5218 FCC Part 15 Supplier’s Declaration of Conformity Product Description: 48V 2.0A Charger Model Number: 060-1990-2 Trade Name: YARDWORKS ® This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:...
  • Page 37 20” (51 CM) BRUSHLESS 3-IN-1 LAWN MOWER Item # 060-1981-4 contact us: 1.866.523.5218 ASSEMBLY 1. OPEN THE LOWER SHORT HANDLE AND ASSEMBLE THE UPPER HANDLE. 1) Turn the lower handle lock knob out (See Fig. A1.) Open the lower handles to align the hole on the lower handle and the one of the three holes on the deck.(See Fig.
  • Page 38 20” (51 CM) BRUSHLESS 3-IN-1 LAWN MOWER Item # 060-1981-4 contact us: 1.866.523.5218 2. GRASS COLLECTION BAG FITTING 1) Raise the rear discharge guard and remove the mulching block. (See Fig. C1.) 2) Pick up the grass collection bag by the handle, and position the left and right hooks of grass collection bag onto the mower.
  • Page 39 20” (51 CM) BRUSHLESS 3-IN-1 LAWN MOWER Item # 060-1981-4 contact us: 1.866.523.5218 PREPARE 1. CHARGING PROCEDURE (See Fig. E) 1) Plug the charger (Not included) into an appropriate outlet. 2) The light will flash green when charging. When fully charged, the light will turn solid green.
  • Page 40 20” (51 CM) BRUSHLESS 3-IN-1 LAWN MOWER Item # 060-1981-4 contact us: 1.866.523.5218 3. INSTALLING THE BATTERY PACK ( SEE FIG. G) Slide the battery pack into tool’s battery port. A simple push and slight pressure will be sufficient. OPERATION STARTING (SEE FIG.
