- Page 2 Front Top Rail Left Side Panel Fixed Shelf Back Top Rail Back Bottom Rail Back Panel Right Side Panel Top Panel Bottom Panel Right Door Support Plate Left Door Drawer Side Panel Drawer Bottom Panel Drawer Front Panel Drawer Back Panel...
- Page 3 Cam Bolt Ø6*42mm Wood Dowel Ø8*30mm Cam Lock Ø15*12mm Round Head Bolt Long Screw Ø4*57mm Ø5/32"*19mm Knob Ø29*27mm Short Screw Ø3.5*25mm Magnet L70*H12mm Screw Ø3*15mm Drawer Stopper Ø29*27mm Screw Ø3*12mm Wall Anchor Ø8*38mm F X 1 G X 1 Note: It is not recommended to use power tools during assembly. You may use power tools to assist in mounting the safety strap kit to the wall.
- Page 4 Attach Knob (D) to Doors (10 & 11) using Round Head Bolt (E) . Attach Magnet (H) exactly as shown. Attach Magnet (H) exactly as shown Fix Cam Bolt (B) to Side Panels (1 & 7) ,Bottom Panel (8) and Top Panel (9),as shown . Attach Drawer Stopper (J) exactly as shown.
- Page 5 Set Drawer Front Panel (13), Drawer Side Panels (14) , Drawer Bottom Panel (15) and Drawer Back Panel (16) into place using Short Screw (G) . Attach Knob(D) to Drawer Front Panel (13) using Round Head Bolt (E) . Attach Rail (2 & 5 & 6) and shelf (3) to Right Side Panel (7) using Wood Dowel (C) and Cam Lock (A) .
- Page 6 Set Top Panel (9) into place using Cam Lock (A) . Place Top Panel (9) to the ground and insert Back Panel (4) into cabinet . Note:Insert Back Panel exactly as shown.
- Page 7 Set Bottom Panel (8) into place using Cam Lock (A) . Set Doors (10 & 11) into place .
- Page 8 Hold the Support Plate (12) in the desired location of the wall unit. This plate will be about 2-1/2” lower than the top of the wall unit. Making sure the Support Plate (12) is level, use a pencil to mark the anchor locations using the Support Plate (12) screw holes as a guide. We recommend using a leveler to make sure the Support Plate (12) is oriented correctly.
- Page 9 Insert drawer into cabinet .
