2.0

Installation Instructions

Table 1 Backboxes
Backbox
Height H (in.)
BB-1001D/R
BB-1002D/R
BB-1003D/R
BB-1008D/R
BB-1012D/R
BACKBOX CAN BE MOUNTED
WITH STANDARD 4" X 4"
ELECTRICAL BOXES
Figure 1
The RAX-1048TZDS is supplied with the NP-681 Blank Laser Printable Label Sheet.
i
Note:
2
Width (in.)
9.0"
12.75"
18.0"
12.75"
26.5"
12.75"
33.0"
22.5"
45.0"
22.5"
BB-1001D/R BACKBOX IS SHOWN
ANNUNCIATOR CHASSIS
Mechanical Assembly Diagram
The RAX-1048TZDS displays Initiating circuit status and trouble indication.
Indicating and relay circuits are not remotely displayed. For more details, see the
fire alarm control panel manual that the annunciator is connected to.
Mounting A (in.)
Mounting B (in.)
9.95"
9.95"
9.95"
20.9"
20.9"
GB-1001RAX GUARD BRACKET
7.5"
16.5"
24.9"
35.2"
52.0"
BACKBOX
WALL
DOOR
#6-32
HEXNUTS
