5.0

Specifications and Features

5.1

Enclosure Models

The finish of all enclosures is painted semi-gloss off white. For enclosure dimensions see 4.0
DIP Switch Settings
Table 4 Enclosure Model Descriptions
Modle
Material
Number
BB-1001D/R
18 GA. CRS
BB-1002D/R
18 GA. CRS
BB-1003D/R
16 GA. CRS
BB-1008D/R
16 GA. CRS
Door is 14 GA
BB-1012D/R
16 GA. CRS
Door is 14 GA
5.2

Module Models

5.2.1 RAX-LCD Remote FX-2000 Shared Display LCD Annunciator

24V DC nominal, range of 20 to 39V DC.
Interconnects via one ribbon cable (or wiring) to the FX-2000 Fire Alarm Panel or to
previous RAX-LCD.
Provides exact functions as the FX-2000 main display.
Standby: 100 mA Max., All LEDs ON: 150 mA Max.

5.2.2 RAX-1048TZDS Adder Annunciator Chassis (48 Display Points)

Interconnect via one ribbon cable from RAX-LCD or to previous RAX-1048TZDS or IPS-
2424DS to the next RAX-1048TZDS or IPS-2424DS.
Annunciation of up to 48 additional points.
Standby: 15 mA Max., All LEDs ON: 100 mA Max.
Description
Backbox for one annunciator chassis with keylock door
Backbox for one annunciator chassis with keylock door
Backbox for one annunciator chassis with keylock door
Backbox for one annunciator chassis with keylock door
Backbox for one annunciator chassis with keylock door
7
