TFP620
Page 8 of 8
RECESSED
CEILING
SPACE
INSTALLATION NOTE:
INSTALL VERTICAL AND
HORIZONTAL MODEL
WS SPRINKLERS
TYPICAL
CEILING SPACES.
WINDOW
DO NOT PLACE BLINDS,
COVERING
CURTAINS OR OTHER
WINDOW COVERINGS
BETWEEN SPRINKLER
MODEL WS PENDENT VERTICAL SIDEWALL SPRINKLER
RECESSED CEILING TYPICAL INSTALLATION
WRENCH RECESS
(USE END "A" FOR
MODEL WS)
FIGURE 4
W-TYPE 20 SPRINKLER
WRENCH
1400 Pennbrook Parkway, Lansdale, PA 19446 | Telephone +1-215-362-0700
© 2018 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision date and are subject to change without notice.
NATIONAL FIRE PROTECTION ASSOCIATION and NFPA are registered trademarks of National Fire Protection Association;
TEFLON is a registered trademark of DuPont
PLUS WS CERAMIC GLASS
BY TGP, ALL COMBUSTIBLE
INTO RECESSED
KEPT 2" (50,8 mm) MINIMUM
FROM SPRINKLERED FACE
OF GLAZING. THIS MAY BE
AND GLAZING
NONOPERABLE
GLASS WINDOW
FIGURE 3E
Limited
Warranty
For warranty terms and conditions, visit
www.tyco-fire.com.
BUILDING
STRUCTURE
WINDOW
FRAME
FOR GLASS TYPES
OTHER THAN FIRELITE
MATERIALS SHALL BE
DONE THROUGH USE OF
MINIMUM 3'-0" (0,9 m)
PONY WALL
MODEL WS SPRINKLER
SHOWN ON ONE SIDE OF
GLAZING FOR CLARITY
Ordering
Procedure
Contact your local distributor for avail-
ability. When placing an order, indicate
the full product name and Part Number
(P/N).
Model WS HSW Window Sprinkler
with NPT Thread
Specify: Model WS Specific Appli-
cation Window Sprinkler TY3388,
Horizontal Sidewall, with (specify) tem-
perature rating, (specify) finish, and
P/N (specify):
155 °F (68 °C)
Natural Brass . . . . . . . . . . . . . . . . 50-305-1-155
Signal White (RAL9003)
Polyester . . . . . . . . . . . . . . . . . . . . 50-305-4-155
Jet Black (RAL9005)
Polyester . . . . . . . . . . . . . . . . . . . . 50-305-5-155
Chrome Plated . . . . . . . . . . . . . . . 50-305-9-155
200 °F (93 °C)
Natural Brass . . . . . . . . . . . . . . . . 50-305-1-200
Signal White (RAL9003)
Polyester . . . . . . . . . . . . . . . . . . . . 50-305-4-200
Jet Black (RAL9005)
Polyester . . . . . . . . . . . . . . . . . . . . 50-305-5-200
Chrome Plated . . . . . . . . . . . . . . . 50-305-9-200
Model WS Pendent Vertical
Sidewall Window Sprinkler
with NPT Thread
Specify: Model WS Specific Application
Window Sprinkler TY3488, Pendent
Vertical Sidewall, with (specify) tem-
perature rating, (specify) finish, and
P/N (specify):
155 °F (68 °C)
Natural Brass . . . . . . . . . . . . . . . . 50-304-1-155
Signal White (RAL9003)
Polyester . . . . . . . . . . . . . . . . . . . . 50-304-4-155
Jet Black (RAL9005)
Polyester . . . . . . . . . . . . . . . . . . . . 50-304-5-155
Chrome Plated . . . . . . . . . . . . . . . 50-304-9-155
200 °F (93 °C)
Natural Brass . . . . . . . . . . . . . . . . 50-304-1-200
Signal White (RAL9003)
Polyester . . . . . . . . . . . . . . . . . . . . 50-304-4-200
Jet Black (RAL9005)
Polyester . . . . . . . . . . . . . . . . . . . . 50-304-5-200
Chrome Plated . . . . . . . . . . . . . . . 50-304-9-200
Sprinkler Wrench
Specify: W-Type 20 Sprinkler Wrench,
P/N 56-000-1-106
