TFP670
Page 4 of 4
P/N 57 – XXX – X – XXX
580 UPRIGHT 5 mm Bulb
581 PENDENT 5 mm Bulb
380 UPRIGHT 3 mm Bulb
381 PENDENT 3 mm Bulb
SERIES TY-B (5 MM BULB) & TY-FRB (3 MM BULB) 10 MM ORIFICE
Care and
Maintenance
The TYCO Series TY-B and TY-FRB
must be maintained and serviced in
accordance with this section.
NOTICE
Before closing a fire protection system
main control valve for maintenance work
on the fire protection system that it con-
trols, obtain permission to shut down
the affected fire protection system
from the proper authorities and notify
all personnel who may be affected by
this action.
Absence of an escutcheon, which is
used to cover a clearance hole, can
delay the time to sprinkler operation in
a fire situation.
Sprinklers that are found to be leaking
or exhibiting visible signs of corrosion
must be replaced.
Automatic sprinklers must never be
painted, plated, coated or other-
wise altered after leaving the factory.
Modified sprinklers must be replaced.
1400 Pennbrook Parkway, Lansdale, PA 19446 | Telephone +1-215-362-0700
© 2018 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision date and are subject to change without notice.
NATIONAL FIRE PROTECTION ASSOCIATION and NFPA are registered trademarks of National Fire Protection Association;
TEFLON is a registered trademark of DuPont
SPRINKLER
SIN
TY2108 1 NATURAL BRASS
PURE WHITE (RAL9010)*
TY2208 3
POLYESTER
SIGNAL WHITE (RAL9003)
TY2109 4
POLYESTER
TY2209 9 CHROME PLATED
* Eastern Hemisphere sales only
TABLE B
UPRIGHT AND PENDENT SPRINKLERS
PART NUMBER SELECTION
Sprinklers that have been exposed to
corrosive products of combustion, but
have not operated, should be replaced
if they cannot be completely cleaned
by wiping the sprinkler with a cloth or
by brushing it with a soft bristle brush.
Care must be exercised to avoid
damage to the sprinklers before,
during, and after installation. Sprin-
klers damaged by dropping, striking,
wrench twist/slippage, or the like, must
be replaced. Also, replace any sprinkler
that has a cracked bulb or that has lost
liquid from its bulb. Refer to the Instal-
lation section for additional information.
The owner is responsible for the inspec-
tion, testing, and maintenance of their
fire protection system and devices in
compliance with this document, as well
as with the applicable standards of the
NATIONAL FIRE PROTECTION ASSO-
CIATION (e.g., NFPA 25), in addition to
the standards of any other authorities
having jurisdiction. Contact the install-
ing contractor or sprinkler manufac-
turer regarding any questions.
Automatic sprinkler systems are rec-
ommended to be inspected, tested,
and maintained by a qualified Inspec-
tion Service in accordance with local
requirements and/or national codes.
FINISH
135
155
175
200
286
360
Limited
Warranty
For warranty terms and conditions, visit
www.tyco-fire.com.
Ordering
Procedure
Contact your local distributor for avail-
ability. When placing an order, indicate
the full product name and part number
(P/N).
Sprinkler Assemblies
Specify: (SIN), Series (TY-B or TY-FRB),
(Standard or Quick Response), 10 mm
Orifice, (temperature rating), (Pendent
or Upright) Sprinkler with (finish),
P/N (from Table B)
Recessed Escutcheon
Specify: Style 70 Recessed Escutch-
eon with (specify*) finish, P/N (specify*)
* Refer to Technical Data Sheet TFP770
Sprinkler Wrench
Specify: W-Type 6 Sprinkler Wrench,
P/N 56-000-6-387
Specify: W-Type 7 Sprinkler Wrench,
P/N 56-850-4-001
TEMPERATURE
RATINGS
135°F (57°C)
155°F (68°C)
175°F (79°C)
200°F (93°C)
286°F (141°C)
360°F (182°C)
(5 mm Bulb Only)
