Johnson Controls tyco TY-B Series Manual page 3

- * 4 -
1 Frame
-
2 Button
3 -
Sealing Assembly
*
6
5
4
2
53 mm
3
*
1
CROSS SECTION
SERIES TY-B (5 MM BULB) & TY-FRB (3 MM BULB) 10 MM ORIFICE
18 ± 6 mm
FACE OF
SPRINKLER
FITTING
MOUNTING
SURFACE
CLOSURE
SERIES TY-B (5 MM BULB) & TY-FRB (3 MM BULB) 10 MM ORIFICE
STYLE 70 RECESSED ESCUTCHEON, ISO 7/1-R 3/8
The Series TY-B and TY-FRB Recessed
Pendent Sprinklers must be installed
in accordance with the following
instructions.
Step A. After installing the Style
70 Mounting Plate over the sprin-
kler threads with pipe-thread sealant
applied to the pipe threads, hand-
tighten the sprinkler into the sprinkler
fitting.
5 -
Bulb:
5 mm Dia. for TY-B
6 - Deflector
3 mm Dia. for TY-FRB
8 mm
NOMINAL
MAKE-IN
WRENCH
UPRIGHT
UPRIGHT AND PENDENT SPRINKLERS
73 mm DIA.
57 mm DIA.
SERIES
TY-B or TY-FRB
FIGURE 2
Step B. Tighten the sprinkler into the
sprinkler fitting using only the W-Type
7 Recessed Sprinkler Wrench (Figure
3). With reference to Figure 1, apply the
W-Type 7 Recessed Sprinkler Wrench
to the sprinkler wrench flats.
Step C. After ceiling installation and
finishing, slide on the Style 70 Closure
over the Series TY-FRB Sprinkler and
push the Closure over the Mounting
Plate until its flange comes in contact
with the ceiling.
Compression
Screw
*
ESCUTCHEON PLATE
SEATING SURFACE
ISO
7-R 3/8
38 mm
FLATS
PENDENT
FIGURE 1
18 mm
6 mm
MOUNTING
PLATE
3,2 mm
32 mm
20 mm
*
Temperature rating is indicated on Deflector
or adjacent to orifice seat on Frame
RECESSED ESCUTCHEON
55 mm
2-7/8" (73,0 mm) DIA.
RECESSED PENDENT
WRENCH
RECESS
PUSH WRENCH
IN TO ENSURE
ENGAGEMENT
WITH SPRINKLER
WRENCHING AREA
FIGURE 3
W-TYPE 7 RECESSED
SPRINKLER WRENCH
FIGURE 4
W-TYPE 6
SPRINKLER WRENCH
TFP670
Page 3 of 4
STYLE 70
WRENCH RECESS
(USE END "A"
ONLY)
