TFP670
Page 2 of 4
TYPE
UPRIGHT
(TY2108)
PENDENT
(TY2208)
RECESSED
PENDENT
(TY2208)
UPRIGHT
(TY2109)
PENDENT
(TY2209)
RECESSED
PENDENT
(TY2209)
NOTES:
1. Approved by the Loss Prevention Certification Board (LPCB Ref. No. 094a/05 & 007k/03) as Standard Response.
2. Approved by the Loss Prevention Certification Board (LPCB Ref. No. 007k/04) as Quick Response.
3. Approved by the Loss Prevention Certification Board (LPCB Ref. No. 007k/04) as Unclassified Response.
4. VdS Approved
For details, contact Johnson Controls, Enschede, The Netherlands, Tel. 31-53-428-4444/Fax 31-53-428-3377.
***Frame and deflector only.
N/A: Not Available
Installation
The TYCO Series TY-B and TY-FRB
Sprinklers must be installed in accor-
dance with this section.
General Instructions
Do not install any bulb-type sprinkler
if the bulb is cracked or there is a loss
of liquid from the bulb. With the sprin-
kler held horizontally, a small air bubble
should be present. The diameter of the
air bubble is approximately 1/16 in.
(1,6 mm) for the 135°F (57°C) to 3/32 in.
(2,4 mm) for the 360°F (182°C) tempera-
ture ratings.
BULB LIQUID
TEMPERATURE
COLOR
5 mm Bulb
135°F (57°C) Orange
155°F (68°C) Red
175°F (79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue
360°F (182°C) Mauve
135°F (57°C) Orange
155°F (68°C) Red
175°F (79°C) Yellow
200°F (93°C) Green
3 mm Bulb
135°F (57°C) Orange
155°F (68°C) Red
175°F (79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue
135°F (57°C) Orange
155°F (68°C) Red
175°F (79°C) Yellow
200°F (93°C) Green
LABORATORY APPROVALS
Do not attempt to compensate for
insufficient adjustment in the Escutch-
eon Plate by under- or over-tightening
the sprinkler. Re-adjust the position of
the sprinkler fitting to suit.
A leak-tight ISO 7-R 3/8 sprinkler joint
should be obtained by applying a
minimum to maximum torque of 8 to 16
N∙m. Higher levels of torque can distort
the sprinkler Inlet with consequent
leakage or impairment of the sprinkler.
The Series TY-B and TY-FRB Pendent
and Upright Sprinklers must be
installed in accordance with the fol-
lowing instructions.
Step 1. Pendent sprinklers are to be
installed in the pendent position, and
upright sprinklers are to be installed in
the upright position.
SPRINKLER FINISH
NATURAL
BRASS
TABLE A
CHROME
POLYESTER***
PLATED
1, 4
1
2, 4
3
Step 2. With pipe-thread sealant
applied to the pipe threads, hand-
tighten the sprinkler into the sprinkler
fitting.
Step 3. Tighten the sprinkler into the
sprinkler fitting using only the W-Type 6
Sprinkler Wrench (Figure 4). With refer-
ence to Figure 1, the W-Type 6 Sprinkler
Wrench is to be applied to the sprinkler
wrench flats.
