TFP540
Page 8 of 8
*
P/N
Pendent with
40
Flush Escutcheon
Pendent with
41
Recessed Escutcheon
Pendent with
42
Extended Escutcheon
Pendent without
43
Escutcheon
Notes:
1. Escutcheon Finish applies to sprinklers with escutcheons.
2. 286°F (141°C) temperature rating applies to non-recessed sprin-
kler assemblies.
3. Dry-Type Sprinklers are furnished based upon "Order Length"
as measured per Figures 2 to 5, as applicable, and for each indi-
vidual sprinkler where it is to be installed. After the measurement
is taken, round it to the nearest 1/4 in. increment.
*
Use Prefix "I" for ISO 7-R 1 Connection
(for example, I-61-431-1-372).
Limited
Warranty
For warranty terms and conditions, visit
www.tyco-fire.com.
Ordering
Procedure
Contact your local distributor for avail-
ability. When placing an order, indi-
cate the full product name, including
description and Part Number (P/N).
Dry-Type Sprinkler
When ordering Series DS-2 Dry-Type
Sprinklers, 11.2K Pendent, Extended
Coverage, Light and Ordinary Hazard,
specify the following information:
• SIN TY5238
1400 Pennbrook Parkway, Lansdale, PA 19446 | Telephone +1-215-362-0700
© 2020 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision date and are subject to change without notice.
NATIONAL FIRE PROTECTION ASSOCIATION and NFPA are registered trademarks of National Fire Protection Association;
TEFLON is a registered trademark of DuPont
61 – XXX – X – XXX
SIN
TY5238
(Figure 2)
TY5238
(Figure 3)
TY5238
(Figure 4)
TY5238
(Figure 5)
SERIES DS-2 EXTENDED COVERAGE DRY-TYPE SPRINKLERS
PART NUMBER SELECTION
• Order Length:
Dry-Type Sprinklers are furnished
based upon Order Length as mea-
sured from the face of the ceiling to
the face of the sprinkler fitting, see
Figures 2 to 5. After the measure-
ment is taken, round it to the nearest
1/4 in. increment.
• Inlet Connections:
1 In. NPT
(Standard)
• ISO 7-R 1
(For information on ISO Inlet Thread
Connections, contact your Johnson
Controls Sales Representative.)
• Temperature Rating
• Sprinkler Finish
• Escutcheon Type and Finish, as
applicable
• Part Number from Table E
SPRINKLER
FINISH
CHROME
0
PLATED
NATURAL
1
BRASS
SIGNAL WHITE
4
(RAL9003)
POLYESTER
NATURAL
5
BRASS
CHROME
9
PLATED
TEMPERATURE
RATING
(2)
0
135°F (57°C)
1
155°F (68°C)
2
175°F (79°C)
3
200°F (93°C)
4
286°F (141°C)
TABLE E
ESCUTCHEON
FINISH(1)
SIGNAL WHITE
(RAL9003)
POLYESTER
SIGNAL WHITE
(RAL9003)
POLYESTER
SIGNAL WHITE
(RAL9003)
POLYESTER
BRASS
PLATED
CHROME
PLATED
ORDER
LENGTH
(3)
055
5.50 in.
082
8.25 in.
180
18.00 in.
187
18.75 in.
372
37.25 in.
480
48.00 in.
Sprinkler Wrench
Specify W-Type 17 Sprinkler Wrench,
P/N 56-010-4-118
Sprinkler Boot
Specify Model DSB-2 Dry Sprinkler
Boot, P/N 63-000-0-002
This P/N includes one (1) Boot, two
(2) Strap Ties, and 1/3 oz of Adhesive
(a sufficient quantity for installing one
boot).
