Bradford White 705-B Specification Sheet

Commercial Gas Light Duty
High Input Direct Vent Water Heater

Features:

1
9001
Bradford White is ISO registered to the
9001 standard.
S T A N D A R D
1" Non-CFC foam insulation—surrounds the tank surface, saving
energy by retarding loss of heat.
Closed combustion—all air for combustion is taken directly from the
outside. The co-axial vent pipe (pipe inside a pipe) draws combustion
air in through the outer pipe (6"), and exhausts the products of
combustion through the inner pipe (4").
Co-axial—rotational venting at top of unit.
No electrical power necessary.
Piezo igniter—for ease of lighting the pilot.
Water Connections—3/4" NPT factory installed true dielectric fittings.
Extends water heater life and eases installation.
Vitraglas ® lined tank—Bradford White water heater tanks are
protected from the corrosive effects of hot water by an exclusive
ceramic porcelain-like coating. The Bradford White high silica Vitraglas
lining provides a tough interior surface for our water heater tanks.
Factory installed Hydrojet
sediment reducing device. Helps prevent sediment build up in tank.
Increases first hour delivery of hot water while minimizing temperature
build up at top of tank.
Protective magnesium anode rod—provides added protection
against corrosion for long trouble-free service.
Brass drain valve.
T&P relief valve—factory installed.
Side Tappings—for space heating purposes.
Fully automatic controls—automatic temperature selection at your
fingertips. Built-in energy cut-off switch prevents abnormally high water
temperature for extra safety. Built-in gas pressure regulation. Fast-
acting thermostat starts heat recovery cycle sooner.
NSF construction available.
Optional vent kits—allow for up to 8 foot max vertical and 8 foot max
horizontal (2.4 meters)). All DH models must be terminated horizontally.
Three year limited warranty on steel tank—heavy gauge steel
automatically formed, rolled and welded to assure a continuous seam
for glass lining.
One year limited warranty on parts.
Design certified by CSA International. (formerly AGA and CGA)
MANUFACTURED UNDER ONE OR MORE OF THE FOLLOWING U.S. PATENTS: 7,063,133 B2; 5,954,492;
5,954,492; 5,761,379; 5,943,984; 5,081,696; 5,988,117; 6,142,216; 5,199,385; 5,574,822; 5,372,185; 5,485,879;
5,277,171; (B1)5,341,770; 5,660,165; 5,596,952; 5,682,666; 4,904,428; 5,023,031; 5,000,893; 4,669,448;
4,829,983; 4,808,356; 5,115,767; 5,092,519; 5,052,346; 4,416,222; 4,628,184; 4,861,968; 4,672,919; Re.
34,534. OTHER U.S. AND FOREIGN PATENT APPLICATIONS PENDING. CURRENT CANADIAN PATENTS:
1,272,914; 1,280,043; 1,289,832; 2,045,862; 2,112,515; 2,108,186; 2,107,012; 2,092,105.5.
® Total Performance System—cold inlet
®
