Table Of Contents - SMC Networks HRR Series Manual

Thermo-chiller/Rack Mount Type
How to Order
Air-cooled Refrigeration
Water-cooled Refrigeration
Specifications
Air-cooled Refrigeration
Water-cooled Refrigeration
Cooling Capacity ...................................................... p. 12
Heating Capacity ..................................................... p. 13
Pump Capacity ........................................................ p. 13
Required Facility Water Flow Rate .......................... p. 13
Dimensions
Air-cooled Refrigeration
Water-cooled Refrigeration
Operation Display Panel .......................................... p. 16
Alarm ....................................................................... p. 16
Communication Functions ....................................... p. 17
C O N T E N T S
HRR
................................ p. 9
................................ p. 9
................................ p. 10
................................ p. 11
................................ p. 14
................................ p. 15
Series
HRR
Options
With Electric Conductivity Control Function,
Applicable to DI Water Piping .................................. p. 19
Applicable to DI Water Piping .................................. p. 19
High-Pressure Pump Mounted ................................ p. 20
Optional Accessories
q Concentration Meter ............................................ p. 21
w Particle Filter Element for Replacement .............. p. 21
e DI Filter Replacement Cartridge .......................... p. 21
Cooling Capacity Calculation
Required Cooling Capacity Calculation ................... p. 22
Precautions on Cooling Capacity Calculation .......... p. 23
Circulating Fluid Typical Physical Property Values ... p. 23
Specific Product Precautions ........................................ p. 24
