Thermo-chiller/Rack Mount Type
Replacement particle
fi lter element
Optional Accessories
630
mm
mm
HRR012 x 4 units
570
mm
(Typical rack dimensions)
1
Air-cooled Refrigeration Water-cooled Refrigeration
Front Access
Front Access
Maintenance
DI fi lter replacement
Optional Accessories
Discharge of the circulating fl uid
Handle
(Accessory)
Cleaning of the dustproof fi lter
21
p.
Space Saving
Space Saving
Footprint is reduced by
19-inch rack (EIA Standards
500
mm
HRS012 x 4 units
Drain pan
21
Leakage sensor detects fluid leakage.
p.
Drain pan prevents leaked fluid from been
leaked to the bottom of the product.
Drain port (Rc1/4)
Cap
53
%
by installing in the
∗1
).
1526
mm
HRR
Series
(Built-in water leakage sensor)
Water leakage sensor
Drain pan
∗1 Standards for 19-Inch Rack
EIA
Standards
(Electronic Industries Alliance)
Standards no.
EIA310-D
Height
44.5 mm (=1U)
Length
450 mm (min)
Width
483.4 mm
