  • Page 1 ASUNA 9700 Elevated Performance Treadmill Workstation...

  • Page 2: Table Of Contents

    INDEX 1 - 2 IMPORTANT SAFETY INSTRUCTIONS............. ELECTRICAL GROUNDING INSRUCTIONS............. CAUTION: BEFORE AND AFTER RUNNING ON THE TREADMILL....3 - 4 RUNNING DECK LUBRICATION................ EXPLODED DIAGRAM.................... 6 - 7 PARTS LIST....................... ASSEMBLY PARTS LIST..................ASSEMBLY INSTRUCTIONS................9 - 12 MOVING & LEVELING..................13 - 14 TREADMILL OPERATION................

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Please read the following basic precautions prior to use of the treadmill: * Never operate the treadmill with the air openings blocked. * Keep air openings free of lint, hair and alike items. * Please retain this manual for future reference. WARNING 1.

  • Page 4: Electrical Grounding Insructions

    18. Do not walk or jog barefoot or without shoes. 19. Do not walk or jog in loose shoes or slippers. Athletic shoes are always recommended while using this treadmill. 20. Never walk or jog while wearing loose fitting clothing. FRONT 21.

  • Page 5: Caution: Before And After Running On The Treadmill

    CAUTION BEFORE AND AFTER RUNNING ON THE TREADMILL Before Running: 1. Read the manual first to be familiar with the digital display and other important features. 2. Before starting the treadmill, always stand on the two side rails on both sides (not on the running belt) as shown in the drawing.
  • Page 6 What to lubricate? Do not lubricate with anything other than our approved lubricant. Your treadmill comes with one 30 ml tube of silicone. You may order additional lubrication from your distributor, which comes in 200 ml silicone bottle: • 200 ml silicone in one bottle with 13.8 inch applicator •...

  • Page 7: Exploded Diagram

    Exploded Diagram 41 41 126 67 105 128 130 10 12 60 61 5 41...

  • Page 8: Parts List

    Parts List Specs. Qty No. Description Specs. No. Description Fastener OSBR-26 Bush Ø15.8 x 2.7t x 72.5L Fixing Cap Ø12 x Ø3.5 PVC Washer Ø10 x Ø21 x 2.0t Round Cushion Fastener OSBR - 22 Screw M3 x 10L TP Screw 5/32"...
  • Page 9 M8 x 25L Desktop 738 x 401 x 18t MDF Bolt M8 x 65L Meter #337 / ASUNA / Mile Center Bar 51 x 45 x 25 x 2.5t Power Cable 400mm / 2P Fixing Washer 32 x 25 x 2t...

  • Page 10: Assembly Parts List

    Assembly Parts List AI AH .............. 4+4+4 A1. Main Frame AC. Bolt Set (M8x55L) ............A2. Front Post AD. Bolt & Spacer (M8x45L) ............A3. Computer Set AE. Bolt Set (M8x15L) ................A4. Storage Box AF. Screw ........

  • Page 11: Assembly Instructions

    Assembly Instructions Step 1: First, please note the end with wire on the Front Post (No. A2) is for the right side of Main Frame (No. A1). Then ask one person to hold Front Post (No. A2) and connect the wire from Main Frame (No. A1) and Front Post (No.
  • Page 12 Step 5: Use Bolt Set (AG) to attach. Step 6: Use Screw (AF) to attach the Back Cover (No. A8) on the Storage Box (No. A4). Step 7: Use Plate (AI) and 4 Screws (AH) to attach Storage Box (No. A4) to the Desk Set (No.
  • Page 13 Step 9: This photo shows the final assembly of Computer Set (No. A3), Storage Box (No. A4) & Desk Set (No. A5). Step 10: Ask one person to hold the above final assembly of Desk Set (No. A5) on the top end of Front Post (No.

  • Page 14: Moving & Leveling

    Step 13: Then use Bolt Set (AE) to attach Right Handlebar (No. A6) on the frame of Desk Set (No. A5). Do not tighten the bolts yet. Step 14: Use Bolt & Spacer (AD) to attach Right Handlebar (No. A6) on the right side of Desk Set (No.

  • Page 15: Treadmill Operation

    Treadmill Operation Speed / Incline Range: Running Mode: 0.5 ~ 7.5 mph, Level 0 ~ 15 Climbing Mode: 0.5 ~ 3.7 mph, Level 15 ~ 40 Program: Running Mode: (1) 12 preset with Difficult Level 1 ~ 3 (2) 3 targets (Time, Distance, Calories) (3) HRR (E, M, T, A, I) (0.5 ~ 6.2 mph, Level 0~ 15) (4) Fat Climbing Mode: (1) 5 preset (2) 3 targets (Time, Distance, Calories) (3) HRR (E, M, T, A, I) (0.5 ~ 2.5 mph, Level 15~ 40) (4) Fat...

  • Page 16: How To Operate

    INCLINE window: (A) Level 0 ~ 15 for Running mode, Level 15 ~ 40 for Climbing Mode (B) Age 10 ~ 99 years old. Defaulted setting: 30 years old. (C) Difficult Level 1 ~ 3 TIME window: 00:00 ~ 99:59 SPEED window: (A) Running Mode 0.5 ~ 7.5 mph, Climbing Mode 0.5 ~ 3.7 mph (B) Weight 44 ~ 309 lbs Speed unit: KM or Mile (Defaulted setting Mile)
  • Page 17 FOR PROGRAM OPERATION: Step 1: Press Incline to choose U0, U1, U2 or U3. Step 2: Press Enter & Speed to key in gender, age, height, weight and resting heart rate (RHR). Step 3: Press Enter to confirm Step 4: Press Start to begin or press Incline or Speed to choose either...
  • Page 18 Note: 1. For HRR program operation, the user needs to wear a transmitter or hold both hands on the hand pulse sensors. This is found on the handlebars to detect heartbeat. 2. If user's heart rate is lower than set target per detection, the speed will automatically increase 0.2 mile.
  • Page 19 FAT Program Step 1: Press Incline or Speed to choose FAT program. Step 2: Press Enter and then Start to start detecting. After about 12 seconds, the computer will show the user's BMI, BMR, FAT% and BODY TYPE. Since this treadmill is not for medical use, the above data is only reference.
  • Page 20 BODY TYPE: 1~5 Petite Underweight Normal Overweight Extremely Overweight FAT % 10 ~ 20 % Normal Male 20 ~ 25 % Overweight Over 25 % Extremely Overweight 15 ~ 25 % Normal Female 25 ~ 35 % Overweight Over 35 % Extremely Overweight COOL DOWN MODE: 1.

  • Page 21: Profile For Programs

    Running Mode Preset Program Profile and Data P1 ~ P4 PROGRAM PROFILE...
  • Page 22 P1 ~ P4 PROGRAM DATA SPEED LEVEL 1 SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE Interval 1 2.0 MPH 2.0 MPH 3.0 MPH 3.0 MPH Interval 2 3.0 MPH 4.0 MPH 3.0 MPH 4.0 MPH Interval 3 3.0 MPH 6.0 MPH 6.0 MPH 5.0 MPH...
  • Page 23 P 5 ~ P 8 PROGRAM PROFILE...
  • Page 24 P5 ~ P 8 PROGRAM DATA SPEED LEVEL 1 SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE Interval 1 4.0 MPH 4.0 MPH 4.0 MPH 4.0 MPH Interval 2 4.0 MPH 4.0 MPH 4.0 MPH 4.0 MPH Interval 3 4.0 MPH 4.0 MPH 4.0 MPH 4.0 MPH...
  • Page 25 P 5 ~ P 8 PROGRAM PROFILE...
  • Page 26 P9 ~ P12 PROGRAM DATA SPEED P 1 0 P 1 1 P 1 2 LEVEL 1 SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE Interval 1 2.0 MPH 2.0 MPH 3.0 MPH 3.0 MPH Interval 2 3.0 MPH 4.0 MPH 3.0 MPH 4.0 MPH Interval 3...
  • Page 27 Climbing Mode Preset Program Profile and Data P1 ~ P5 PROGRAM PROFILE...
  • Page 28 P 1 ~ P 5 PROGRAM DATA SPEED LEVEL 1 SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE Interval 1 3.0 MPH Level 8 3.0 MPH Level 10 3.0 MPH Level 12 3.0 MPH Level 15 3.7 MPH Level 15 Interval 2 3.0 MPH...

  • Page 29: Error Code & Troubleshooting

    Error Code & Trouble Shooting E1 (Error 1): When the machine starts and the computer does not detect signal from the sensor for 7 seconds, E1 will be shown on the computer. E6 (Error 6): When the machine starts and the computer could not read the VR signal from incline motor for 6 seconds, E6 will be shown on the digital display.

  • Page 30: Aligning The Running Belt

    Aligning the Running Belt Ensure the running belt is centered on your treadmill at all times. FIGURE A Running style and Non-level surface may cause the belt to drift off center. Minor adjustments to the two bolts at the rear of the treadmill are necessary when the belt has drifted off center.

  • Page 31: Cleaning

    Cleaning Make sure the treadmill is off and unplugged from the electrical outlet . To remove dust, use a small vacuum nozzle to carefully vacuum around all visible components . To remove film or dust, use a slightly damp rag with a mild cleaning agent. Spray this onto the rag only. Becareful not to immerse any treadmill component in any liquids .

  • Page 32: Maintenance

    When and How to Maintain Your Motorized Treadmill ITEM DAILY (Before Use) DAILY (After Use) WEEKLY MONTHLY 3 MONTHS 6 MONTHS Use dry cloth to Examine if the frame Use damp cloth to wipe and clear is stable for exercise. clean.
