Fault Codes - ECTIVE Multiload 5 Operating Manual

Fault Codes

Should an error occur, the LEDs on the device will light up and flash
in a number of ways to identify the possible cause of the fault:
= permanently lit,
●
Power
Error Code
LED
Reverse
Polarity / Out-
put Short
Non Battery
Link
Faulty Battery
Over Voltage
Over Tempera-
ture
= flashing, — = off
☼
Stage Fault
LED LED
● — —
☼ — —
● ☼ ●
● — ●
● — ☼
Cause
Short circuit or
reverse connection
of the clips
Non battery link
Bulk charging has
timed out and
stopped after 24
hours.
The 12V battery
voltage is above
17.5V.
The 24V battery
voltage is above
35V.
Internal tempera-
ture is above 65OC
+/-5OC
57
Solution
Check clips are not
touching each other
OR Check the clips
are correctly connect-
ed to the battery.
Please choose the
right battery type for
connection.
Battery is faulty and
may need to be re-
placed.
Disconnect the charg-
er and check the
battery voltage. This
charger is suitable for
12V or 24V Batteries
only.
Turn off charger and
allow to cool.
