Chassis-Earthing

The chassis earthing lug should be connected to an earting point
which will depend on where the battery charger is installed.
In a vehicle:
Connect the chassis ground lug to the chassis of the vehicle.
In a boat:
Connect to the boat's grounding systems.
At a fixed location:
Connect to earth.
1,2 m grounding rod
Step 3: Connect to 220-240-V Mains Power
Connect the battery charger to the 220-240V AC mains powered
socket and turn on the mains power.
Step 4: Charge
During the charge process, the CHARGING and FULLY CHARGED
LED will flash various patterns. This is normal and indicates the
various charge stages. Refer to "How can I know what stage the
battery charger is in" in the FAQ section of this manual.
