Specifications
Charger Type
Input Voltage
Input Power
Output Voltage
Output Current
Min. Star Voltage
Back Drain
Current Fuse Rating
Desulphation
Soft Start
Bulk
Absorption
Battery Test
Recondition
Float
Pulse
Efficiency
Thermal Protection
Cooling Fan
Ambient Temperature
Over Voltage Protection
Deep Cycle
Types of Batteries
Dimensions (L×W×H)
Weight
Multiload 12
332 W
12 V DC
12 A
2 V
4 mA
250 V AC, T3,15 A
Charge Control
Pulse charge up to 11 V
Half of the rated set current up to 12,5 V
12 A up to
14,1 V (GEL)
14,4 V (AGM)
14,7 V (WET)
14,7 V (CALCIUM)
Constant voltage until
current drops to 1,8 A
Monitors voltage for 90 seconds
Constant current (1,8
A) for 30 minutes or
for 4 hours limited to:
14,1 V (GEL), 14,4 V
(AGM), 16 V (WET)
16 V (CALCIUM)
13,7 V – also with pulse feature
12,6 V – 14,1 V, 12-2 A (GEL)
12,6 V – 14,4 V, 12-2 A (AGM)
12,6 V – 14,7 V, 12-2 A (WET)
12,6 V – 14,7 V, 12-2 A (Ca)
Automatic temperature controlled
-20 °C to 50 °C, output power is reduced
automatically at high temperatures
The 12V charger will automaticallyp rotection if the
voltage is higher than 17.5 V
Battery Range
12 – 150 Ah
Most types of lead acid batteries including Calcium, GEL and AGM
197 x 116 x 62 mm
1,1 kg
46
Multiload 15
8 stage automatic
220 – 240 V~, 50/60 Hz
415 W
12 V DC
15 A
2 V
4 mA
250 V AC, T3,15 A
15 A up to
14,1 V (GEL)
14,4 V (AGM)
14,7 V (WET)
14,7 V (CALCIUM)
Constant voltage until
current drops to
2,25 A
Constant current (2,25
A) for 30 minutes or
for 4 hours limited to:
14,1 V (GEL), 14,4 V
(AGM), 16 V (WET)
16 V (CALCIUM)
12,6 V – 14,1 V, 15-2 A (GEL)
12,6 V – 14,4 V, 15-2 A (AGM)
12,6 V – 14,7 V, 15-2 A (WET)
12,6 V – 14,7 V, 15-2 A (Ca)
ca. 85 %
65 °C +/- 5 °C
20 – 240 Ah
217 x 116 x 62 mm
1,28 kg
Multiload 20
554 W
12 V DC
20 A
2 V
4 mA
250 V AC, T3,15 A
20 A up to
14,1 V (GEL)
14,4 V (AGM)
14,7 V (WET)
14,7 V (CALCIUM)
Constant voltage until
current drops to 3 A
Constant current (3 A)
for 30 minutes or for 4
hours limited to:
14,1 V (GEL), 14,4 V
(AGM), 16 V (WET)
16 V (CALCIUM)
12,6 V – 14,1 V, 20-2 A (GEL)
12,6 V – 14,4 V, 20-2 A (AGM)
12,6 V – 14,7 V, 20-2 A (WET)
12,6 V – 14,7 V, 20-2 A (Ca)
40 – 400 Ah
217 x 116 x 62 mm
1,28 kg
