Product Overview
The 8-stage automatic charging consists of the following
components:
1. Mode Button
2. Charging Stage LEDs
3. Power LED
4. Fault LED
5. Output VoltageMeter
6. Battery Mode LED
7. DC Leads
11
3
4
7
8
2
1
5
6
12 10
8. Power Cord
9. Cooling Fan
10. Ground Terminal
11. Mounting Flange
12. 5,0 mm Mounting Hole
