MODEL: UVRS100BL-300 LB. WEIGHT CAP.
READ ALL INSTRUCTIONS AND THE ADDITIONAL LIST OF WARNINGS BEFORE USING THE
NOTE: Failure to read instructions before use could result in injury or death.
CONTENTS: SEE FIG. 1
1 – BACKREST FRAME WITH 2 CUSHIONS
1 – SEAT FRAME WITH 2 CUSHIONS
1 – SEATBELT STRAP W/ 2 MALE BUCKLES
4 – 5/16" QUICK PINS
2 – ARMRESTS
1 – HARDWARE PACKET
2 – LEG ASSEMBLIES W/ MOUNTING
BRACKETS
HARDWARE PACKET INCLUDES:
4 – 5/16" X 2 1/2" BOLTS
4 – 5/16" X 1" BOLTS
4 – 5/16" FENDER WASHERS
8 – 5/16" X 1 3/4" BOLTS
2 – 5/16" X 2" BOLTS
14 – 5/16" LOCKNUTS
24 – 5/16" FLAT WASHERS
2 – FEMALE SEAT BELT BUCKLES
2 – SAFETY ATTACHING STRAPS W/THUMB
RELEASE BUCKLES
THE RUMBLE SEAT
RUMBLE SEAT
Instructions for Installation and Use:
FIG. 1
**NOTE**PLEASE REMOVE ALL PARTS
FROM BOX AND CHECK THE PARTS
AGAINST THE CONTENTS LIST BEFORE
BEGINNING ASSEMBLY. ANY MISSING
OR DAMAGED PARTS NEED TO BE
REPORTED TO GREAT DAY, INC.
PAGE 1 OF 4
PAGE 2 OF 4
Advertisement
Table of Contents
Related Manuals for Great day UVRS100BL
Summary of Contents for Great day UVRS100BL
- Page 1 PAGE 1 OF 4 THE RUMBLE SEAT MODEL: UVRS100BL-300 LB. WEIGHT CAP. READ ALL INSTRUCTIONS AND THE ADDITIONAL LIST OF WARNINGS BEFORE USING THE RUMBLE SEAT NOTE: Failure to read instructions before use could result in injury or death. Instructions for Installation and Use: CONTENTS: SEE FIG.
- Page 2 PAGE 2 OF 4 STEP 1: SEE FIG. 2- ATTACH LEG ASSEMBLIES TO THE BOTTOM OF THE SEAT FRAME USING 4-5/16” x 1 3/4” BOLTS, 8-FLAT WASHERS & 4-LOCK NUTS. **NOTE**THERE ARE 4 DIFFERENT LEG ASSEMBLY POSITIONS (2 ON SEAT FRAME & 2 ON LEG ASSEMBLIES) TO ENSURE PROPER LEVEL POSITIONING IN THE BED OF YOUR PARTICULAR UTV.
- Page 3 PAGE 3 OF 4 STEP 5: SEE FIG.6 PLACE FULLY ASSEMBLED RUMBLE SEAT INTO THE CARGO AREA OF UTV WITH RUMBLE SEAT BACKREST AGAINST THE CAB OF UTV. **NOTE**THE RUMBLE SEAT IS INTENDED TO FACE THE REAR OF THE UTV WITH BACKREST AS CLOSE TO THE ROLL BARS AS POSSIBLE.
- Page 4 DO NOT EXCEED THE 300 LB. WEIGHT CAPACITY (TOTAL WEIGHT OF BOTH PASSENGERS) OF THE RUMBLE SEAT. For more information about this or other products, contact us at: Great Day, Inc. 604 Kimbrough Dr. * Tallulah, LA 71282 * (866) 649-1918 * www.greatdayinc.com...
