Writing data to PROFINET slaves: this command allows to write the data to a specific PROFINET slave.
Request:
Response:
(*) The number of PROFINET slave depends on the order with which they are defined in the "PROFINET Access" section of SW67B84.
Note:
It is possible to write up to 512 bytes with a single command.
Note:
It is possible to use TCP and UDP for sending the commands. It is necessary to use the ports defined in the section "Set
Communication" of SW67B84.
ADFweb.com Srl – IT31010 – Mareno – Treviso
Byte Number Description
1 'W' (0x57)
2 '.' (0x2E)
3÷5 PROFINET slave to read (000÷009) (decimal) (*)
6 '.' (0x2E)
7÷9 Starting output byte to write (decimal)
10 '.' (0x2E)
11÷13 Number of bytes to write (decimal)
14 '=' (0x3D)
15÷n+15 Data to write (hex)
*n=number of bytes defined in bytes 11-12-13 of the command
Byte Number Description
1 'D' (0x44)
2 ':' (0x3A)
3÷n+2 Output byte of PROFINET (two chars for each byte)
*n=number of Input bytes of the slave
