  • Page 1 Optical Zoom Conference Cam User Manual...
  • Page 2 1.Notice To avoid damage from stress, violent vibration, soaking during transportation, storage and installation. Take care of each components of camera during installation, and install camera at where is affordable enough, to avoid drop or scratches of camera case.Handle the camera parts gently, do not squeeze the camera units hard.
  • Page 3 4.Quick Start Interface definition RS-485 DC 12V 1.IR 2.USB 3.RS-232 4.RS-485 5.DC12V nterface diagram High Speed USB HD Video interfare keyboard control DC 12V Output AC 220V Input RS-485 DC 12V...
  • Page 4 Installation instructions (1) Surface Installation Put the camera on the desk flat, and make sure the camera in level. If want to put the camera on oblique surface, please make sure the angle of inclination less than 15 degree for ensure camera pan and tilt working in normal operation.
  • Page 5 5. Remote control button description (1)Remote Control Launch Window (2)【POWER】Standby Button, pressing it, camera goes into Standby Mode; pressing again, camera goes Power ON. (3)【P/T Reset 】(Not applicable for this model) (4)【CAMERA SELECT】Choose the camera number that needed to control, to correspond the dial-up code on the back of camera CAMERA SELECT (5)【POSITION】Preset position setup keys, include 【PRESET】and 【RESET】...
  • Page 6 3.Camera Focusing Mode Control 【AUTO】Switch the focus mode to AUTO 【MANUAL】Switch the focus mode to MANUAL NEAR 【FAR】Far focus manually AUTO MANUAL 【NEAR】Near focus manually FOCUS FOCUS 4.Camera Zoom Control Press any one of the 4 【ZOOM】 to make the zoom functioning. ZOOM ZOOM SLOW...
  • Page 7 PS: RS-422/485 and RS232 Pins distribution 1.Control Interface (1)RS485 Interface Distribution PIN NUM FUNCTION DTR IN+(connect to RS-485) DSR IN+(connect to RS-485) (2)RS-232 Interface Distribution 1.N.C. VISCA RS-232 IN 2.N.C. 3.TXD 4.GND 5.RXD 6.N.C. 7.N.C. 8.N.C. VISCA RS-232 OUT 1.N.C. 2.N.C.
