Page 1: Quick Start Guide
P-660HWP-Dx 802.11g HomePlug AV ADSL2+ Gateway Quick Start Guide Version 3.40 7/2007 Edition 1 Copyright © 2007. All rights reserved. - Page 2 Overview The P-660HWP-Dx is a gateway which combines high-speed ADSL Internet access, a built-in switch, a firewall, and HomePlug AV and high-speed wireless networking capability. The figure below shows the P-660HWP-Dx connecting devices via a firewalled DSL connection to the Internet through: •...
-
Page 3: Hardware Connections
1 Hardware Connections 1 DSL: Use the gray telephone wire to connect your P-660HWP-Dx’s DSL port to a telephone jack (or to the modem port on a splitter if you are using one). 2 ETHERNET: Use the yellow Ethernet cable to connect a computer to an ETHERNET port on the P-660HWP-Dx for initial configuration and/or Internet access. -
Page 4: Internet And Wireless Setup Wizard
1 Open a browser such as Internet Explorer and go to your favorite website. Wait while your P-660HWP-Dx tries to detect your DSL connection to your ISP. This may take a few minutes. 2 After it detects the connection, the DSL light shows green on your device and the Internet light comes on when the Internet is ready for you to use. - Page 5 4 Enter your new password to log in again. 5 Click Apply in the screen below to create a new certificate for your P-660HWP-Dx. This screen will continue to appear until you apply this option. 6 Select Go to Wizard setup in the screen below. Click Apply to access the Wizard. 3.2 Connect to the Internet Using the Wizard 1 Click INTERNET/WIRELESS SETUP.
- Page 6 • If you do not see the screen below, or your ISP has given you Internet access set- tings not available on this screen, see Troubleshooting. 3 In the next screen, select either Obtain an IP Address Automatically or Static IP Address.
- Page 7 1 Select Active and click Next to continue. It is strongly recommended that Enable OTIST is NOT selected. See the Users’ Guide for more information on OTIST. 2 Configure your wireless settings in the screen displayed. Click Next. 3 If you select either WEP or WPA-PSK security (recommended), then follow the directions to enter the appropriate key.
-
Page 8: Setting Up A Wireless Network
5 Click Finish to complete and save the wizard setup. Your Internet connection is ready for you to use. Open a browser such as Internet Explorer and navigate to a website. 4 Setting Up a Wireless Network To set up a wireless network you need at least one wireless network card/adapter. •... - Page 9 • Type the Network Password for your network. This will connect you to other Home- Plug AV devices which have the same password and allow you to configure them. HomePlugAV is the default password for ZyXEL HomePlug AV devices. • You do not need to type the Device Access Key (DAK) for the P-660HWP-Dx unless you want to change it.
-
Page 10: Troubleshooting
Troubleshooting If you cannot access the web configurator check the following. 1 Your computer may be set to use a static IP address in a different subnet from the ZyXEL device. See the User’s Guide for information on setting up your IP address. 2 If you are using Internet Explorer in Windows XP or Windows Server 2003, make sure you allow pop-up windows, JavaScript and Java permissions or set the Internet security level lower than High in Internet Explorer (in Internet Explorer, click Tools >... - Page 11 section and enter it in the IP Address field. If not, select Obtain an IP Address Automatically. Click Apply and run the Internet/Wireless Setup wizard again r If you have a DSL connection and have entered your ISP settings, but you cannot access the Internet, follow these steps.
- Page 12 If you cannot access your HomePlug AV network, try the following: 1 Make sure that the network password is the same on all of your HomePlug AV adapters and that the DAKs for your HomePlug AV devices are typed correctly. 2 Make sure that all the power line adapters you are using are HomePlug AV compliant.
- Page 13 P-660HWP-Dx Quick Start Guide...
