X9DRW-3LN4F+
X9DRW-3TF+
USER'S MANUAL
Revision 1.0c

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUPERO X9DRW-3LN4F+ and is the answer not in the manual?

Questions and answers

Related Manuals for Supermicro SUPERO X9DRW-3LN4F+

Summary of Contents for Supermicro SUPERO X9DRW-3LN4F+

  • Page 1 X9DRW-3LN4F+ X9DRW-3TF+ USER’S MANUAL Revision 1.0c...
  • Page 2 This product, including software and docu- mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.
  • Page 3 Technology, Digital Media Interface (DMI), PCI-E Gen. 3.0, and up to 1866 MHz DDR3 memory. These features greatly enhance system performance for 1U/2U servers. This motherboard is ideal for high-end server platforms. Please refer to our Website (http://www.supermicro.com) for processor and memory support updates. Manual Organization Chapter 1 provides quick installation instructions.
  • Page 4 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Conventions Used in the Manual Pay special attention to the following symbols for proper system installation: Warning: Critical information given to avoid damage to the components or injury to yourself. Note: Additional information given to differentiate between models or to provide instructions for proper system setup.
  • Page 5 Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 6: Table Of Contents

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Table of Contents Preface Chapter 1 Overview Overview ......................1-1 Processor and Chipset Overview..............1-11 Special Features ................... 1-12 PC Health Monitoring ..................1-12 ACPI Features ....................1-13 Power Supply ....................1-13 Super I/O ....................... 1-14 Advanced Power Management ..............1-14 Intel Intelligent Power Node Manager (NM) ..........
  • Page 7 Table of Contents Universal Serial Bus (USB) ..............2-19 Serial Ports ....................2-20 Video Connection ..................2-20 Ethernet Ports ..................2-21 Unit Identifier Switch ................2-22 Front Control Panel ..................2-23 Front Control Panel Pin Definitions............... 2-24 NMI Button ....................2-24 Power LED ....................
  • Page 8 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual GLAN LEDs ....................2-40 IPMI Dedicated LAN LEDs ............... 2-40 Onboard Power LED ................2-41 Rear UID LED ..................2-41 BMC Heartbeat LED ................2-42 2-10 Serial ATA Connections ................. 2-43 Serial ATA Ports..................2-43 SAS Ports ....................2-43 Chapter 3 Troubleshooting Troubleshooting Procedures ................

  • Page 9: Chapter 1 Overview

    Checklist Congratulations on purchasing your computer motherboard from an acknowledged leader in the industry. Supermicro boards are designed with the utmost attention to detail to provide you with the highest standards in quality and performance. Please check that the following items have all been included with your motherboard.
  • Page 10 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Motherboard Image Note: All graphics shown in this manual were based upon the latest PCB Revision available at the time of publishing of the manual. The motherboard you've received may or may not look exactly the same as the graphics shown in this manual.
  • Page 11 Note 2: For the latest CPU/Memory updates, please refer to our website at http://www.supermicro.com/products/motherboard/ for details. Note 3: Changing BMC log-in information is recommended during initial system power-on. The default username is ADMIN and password is ADMIN. For BMC best practices, please refer to: http://www.supermicro. com/products/nfo/files/IPMI/Best_Practices_BMC_Security.pdf...
  • Page 12 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual X9DRW-3LN4F+/3TF+ Quick Reference LAN3 LAN1 LAN4 LAN2 VGA1 COM1 JUIDB1 KB/MOUSE USB0/1 Buzzer IPMI_LAN CTRL 1 SXB1B CTRL 2 X9DRW-3LN4F+ Rev. 1.20 CPU2 CLOSE 1st LEM2 CTRL OPEN 1st BATTERY CPLD JBAT1 JBT1 Clock CPU1 Intel CLOSE 1st JPW2 OPEN 1st...
  • Page 13 Chapter 2: Overview X9DRW-3LN4F+/3TF+ Jumpers Jumper Description Default Setting JBT1 Clear CMOS See Chapter 2 C1/JI SMB to PCI-E Slots Pins 2-3 (Normal) JPB1 BMC Enable Pins 1-2 (Enabled) JPG1 VGA Enable Pins 1-2 (Enabled) JPL1 LAN1/LAN2 Enable Pins 1-2 (Enabled) JPL2 LAN3/LAN4 Enable Pins 1-2 (Enabled)
  • Page 14 24-pin and the 8-pin power connectors to your power supply for adequate power delivery to your system. The 4-pin power connector is optional; however, Supermicro recommends that this connector also be plugged in for optimal power delivery.
  • Page 15 240-pin 4-channel memory in 24 DIMM slots. Note 1: 1866 MHz memory speed is dependent on Intel E5-2600v2 CPUs. Note 2: For the latest memory updates, please refer to the Tested Memory List posted on our website (http://www.supermicro.com/products/ motherboard). • Virtualization: VT-x, VT-d, and VT-c •...
  • Page 16 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual I/O Devices SATA Connections • SATA Ports Six (6) SATA Ports Two (2) SATA 3.0 Four (4) SATA 2.0 • RAID RAID 0, 1, 5, 10 • C606 PCH SAS Controller • SAS Ports 0~3, 4~7 •...
  • Page 17 Note 2: Changing BMC log-in information is recommended during initial system power-on. The default username is ADMIN and password is ADMIN. For BMC best practices, please refer to: http://www.supermicro. com/products/nfo/files/IPMI/Best_Practices_BMC_Security.pdf Note 3: Changing BMC log-in information is recommended during initial system power-on.
  • Page 18 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Powerville / Twinville L3 / L4 TO UIO PE3 PE2 CPU REAR LEFT UIO RIGHT UIO U7C1 Socket 01 PROCESSOR E5-2600(v2) CPU0/PE2 CPU1/PE3 Series Processor U7C1 CPU0/PE3 CPU1/PE2 U6H1 CPU FRONT U6H1 Socket 00 PROCESSOR E5-2600(v2) Series Processor AT25321 TO UIO...

  • Page 19: Processor And Chipset Overview

    Chapter 2: Overview Processor and Chipset Overview Built upon the functionality and the capabilities of the Intel E5-2600(v2) Series Processors (Socket R LGA 2011) and the C606 chipset, the X9DRW-3LN4F+/3TF+ motherboard provides the performance and feature sets required for dual_proces- sor-based HPC/Cluster/Database servers.

  • Page 20: Special Features

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Special Features Recovery from AC Power Loss The Basic I/O System (BIOS) provides a setting that determines how the system will respond when AC power is lost and then restored to the system. You can choose for the system to remain powered off (in which case you must press the power switch to turn it back on), or for it to automatically return to the power-on state.

  • Page 21: Acpi Features

    24-pin and the 8-pin power connectors to your power supply for adequate power delivery to your system. The 4-pin power connector is optional; however, Supermicro recommends that this connector also be plugged in for optimal power delivery.

  • Page 22: Super I/O

    • Use a power supply that supports PMBus 1.1 or 1.2. • Install the NMView software in your system. NMView is optional and can be purchased from Supermicro. Intel Intelligent Power Node Manager (NM) ® The Intel Intelligent Power Node Manager (IPNM) provides your system with ®...

  • Page 23: Management Engine (Me)

    Chapter 2: Overview Management Engine (ME) The Management Engine, which is an ARC controller embedded in the PCH, pro- vides Server Platform Services (SPS) to your system. The services provided by SPS are different from those provided by the ME on client platforms. Overview of the Nuvoton WPCM450 Controller The Nuvoton WPCM450R Controller, a Baseboard Management Controller (BMC), supports 2D/VGA-compatible Graphic Cores with PCI interface, creating multi-media...
  • Page 24 • RMCP+ protocol supported Note 1: For more information on IPMI configuration, please refer to the IPMI User's Guide posted on our website at http://www.supermicro.com/ support/manuals/. Note 2: The term "IPMI controller" and the term "BMC controller" can be used interchangeably in this section.

  • Page 25: Chapter 2 Installation

    The following statements are industry-standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assis- tance. Only certified technicians should attempt to install or configure components.
  • Page 26 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant. Jeter les piles usagées conformément aux instructions du fabricant. ¡Advertencia! Existe peligro de explosión si la batería se reemplaza de manera incorrecta.

  • Page 27: Product Disposal

    Chapter 2: Installation Product Disposal Warning! Ultimate disposal of this product should be handled according to all national laws and regulations. 製品の廃棄 この製品を廃棄処分する場合、 国の関係する全ての法律 ・ 条例に従い処理する必要が あります。 警告 本产品的废弃处理应根据所有国家的法律和规章进行。 警告 本產品的廢棄處理應根據所有國家的法律和規章進行。 Warnung Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen.

  • Page 28: Static-Sensitive Devices

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual ‫القىانين واللىائح الىطنية‬ ‫جميع‬ ‫وفقا ل‬ ‫ينبغي التعامل معه‬ ‫هذا المنتج‬ ‫من‬ ‫التخلص النهائي‬ ‫عند‬ 경고! 이 제품은 해당 국가의 관련 법규 및 규정에 따라 폐기되어야 합니다. Waarschuwing De uiteindelijke verwijdering van dit product dient te geschieden in overeenstemming met alle nationale wetten en reglementen.

  • Page 29: Processor And Heatsink Installation

    When you have one CPU, be sure to install the CPU in Socket 1 first. • Refer to the Supermicro website for CPU support and updates. Installing the LGA2011 Processor 1. There are two load levers on the LGA2011 socket. To open the socket cover, first press and release the load lever labeled 'Open 1st'.
  • Page 30 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual 2. Press the second load lever labeled 'Close 1st' to release the load plate that covers the CPU socket from its locking position. Pull lever away from Press down on Load the the socket Lever labeled 'Close 1st' 3.
  • Page 31 Chapter 2: Installation 1. Use your index fingers to loosen the lever and open the load plate. 2. Use your thumb and index finger to hold the CPU on its edges. Align the CPU keys, which are semi-circle cutouts, against the socket keys. Socket Keys CPU Keys 3.
  • Page 32 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual 4. With the CPU inside the socket, inspect the four corners of the CPU to make sure that the CPU is properly installed. 5. Close the load plate with the CPU inside the socket. Lock the lever labeled 'Close 1st' first, then lock the lever labeled 'Open 1st' second.

  • Page 33: Installing A Passive Cpu Heatsink

    Chapter 2: Installation Installing a Passive CPU Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU die -- the re- quired amount has already been applied. 2. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the Motherboard's and the Heatsink Bracket under- neath.

  • Page 34: Removing The Heatsink

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Removing the Heatsink Warning: We do not recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the heatsink, please follow the instructions below to uninstall the heatsink to prevent damage done to the CPU or the CPU socket. 1.

  • Page 35: Installing And Removing The Memory Modules

    Chapter 2: Installation Installing and Removing the Memory Modules Note: Check Supermicro's website for recommended memory modules. CAUTION Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Installing & Removing DIMMs 1. Insert the desired number of DIMMs into the memory slots, starting with P1-DIMMA1.
  • Page 36 Non-ECC DDR3 800/1066/1333/1600/1866 MHz of 240-pin 4-channel memory in 24 DIMM slots. Note: For the latest memory updates, please refer to the Tested Memory List posted on our website (http://www.supermicro.com/products/mother- board). Processor & Memory Module Population Configuration For memory to work properly, follow the tables below for memory installation.
  • Page 37 1600 1866 1866 Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory List posted on our website at http://www.supermicro.com/support/resources/mem.cfm. Populating RDIMM (ECC) Memory Modules Intel E5-2600(v2) Series Processor RDIMM Memory Support Ranks Memory Capacity...
  • Page 38 1333, 1333 1333 Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory List posted on our website at http://www.supermicro.com/support/resources/mem.cfm. Populating RDIMM (ECC) Memory Modules Intel E5-2600 Series Processor RDIMM Memory Support Ranks Memory Capacity...
  • Page 39 1066 1066 (QDP) Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory List posted on our website at http://www.supermicro.com/support/resources/mem.cfm. Intel E5-2600 Series Processor LRDIMM Memory Support Ranks Memory Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and DIMM Per...

  • Page 40: Motherboard Installation

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Motherboard Installation All motherboards have standard mounting holes to fit different types of chassis. Make sure that the locations of all the mounting holes for both motherboard and chassis match. Although a chassis may have both plastic and metal mounting fas- teners, metal ones are highly recommended because they ground the motherboard to the chassis.

  • Page 41: Installing The Motherboard

    Chapter 2: Installation Installing the Motherboard 1. Install the I/O shield into the chassis. 2. Locate the mounting holes on the motherboard. 3. Locate the matching mounting holes on the chassis. Align the mounting holes on the motherboard with the mounting holes on the chassis. 4.

  • Page 42: Control Panel Connectors And I/O Ports

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Control Panel Connectors and I/O Ports The I/O ports are color coded in conformance with the PC 99 specification. See the picture below for the colors and locations of the various I/O ports. Back Panel Connectors and I/O Ports LAN4 LAN3 LAN1...

  • Page 43: Atx Ps/2 Keyboard And Mouse Ports

    Chapter 2: Installation ATX PS/2 Keyboard and Mouse PS/2 Keyboard/Mouse Pin Ports Definitions PS2 Keyboard PS2 Mouse The ATX PS/2 keyboard and PS/2 Pin# Definition Pin# Definition mouse are located next to the Back KB Data Mouse Data Panel USB Ports 0/1 and the IPMI No Connection No Connection LAN port on the motherboard.

  • Page 44: Serial Ports

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Serial Ports Serial COM) Ports Pin Definitions Two COM connections (COM1 & Pin # Definition Pin # Definition COM2) are located on the motherboard. COM1 is located on the Backplane I/O panel. COM2, located close to USB 4/5 Connectors, is used to provide front ac- cess support.

  • Page 45: Ethernet Ports

    Chapter 2: Installation Ethernet Ports LAN Ports Pin Definition Two Gigabit Ethernet ports (LAN1/2) Pin# Definition and two 10G_bit LAN ports (LAN3/4) P2V5SB SGND are located on the I/O backplane on TD0+ Act LED the motherboard to provide inter- TD0- P3V3SB net connections.

  • Page 46: Unit Identifier Switch

    3.3V erboard. For more informa- Reset Reset Button Ground tion on IPMI, please refer Power Button Ground to the IPMI User's Guide posted on our website @ http://www.supermicro.com. 1. UID Switch LAN4 LAN3 LAN2 LAN1 VGA1 COM1 JUIDB1 KB/MOUSE USB0/1 Buzzer 2.

  • Page 47: Front Control Panel

    These connectors are designed specifically for use with Supermicro's server chassis. See the figure below for the descriptions of the various control panel buttons and LED indicators. Refer to the following section for descriptions and pin definitions.

  • Page 48: Front Control Panel Pin Definitions

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Front Control Panel Pin Definitions NMI Button NMI Button Pin Definitions (JF1) The non-maskable interrupt button Pin# Definition header is located on pins 19 and 20 Control of JF1. Refer to the table on the right Ground for pin definitions. Power LED Power LED Pin Definitions (JF1) The Power LED connection is located...

  • Page 49: Hdd Led

    Chapter 2: Installation HDD LED HDD LED Pin Definitions (JF1) The HDD LED connection is located Pin# Definition on pins 13 and 14 of JF1. Attach a ID_UID_ cable here to indicate HDD activ- SW_3.3V/3.3V SB ity. See the table on the right for pin HDD Active definitions.

  • Page 50: Overheat (Oh)/Fan Fail/Pwr Fail/Uid Led

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Overheat (OH)/Fan Fail/PWR Fail/ OH/Fan Fail/ PWR Fail/Blue_UID UID LED LED Pin Definitions (JF1) Pin# Definition Connect an LED cable to pins 7 and Red_LED-Cathode/OH/Fan Fail/ 8 of Front Control Panel to use the Power Fail5.5V.SB Overheat/Fan Fail/Power Fail and Blue_UID LED UID LED connections.

  • Page 51: Reset Button

    Chapter 2: Installation Reset Button Reset Button Pin Definitions (JF1) The Reset Button connection is located Pin# Definition on pins 3 and 4 of JF1. Attach it to a Reset hardware reset switch on the computer Ground case. Refer to the table on the right for pin definitions.

  • Page 52: Connecting Cables

    8-pin power connectors to your power supply for Pin Definitions Pin Definitions adequate power delivery to your system. The 4-pin Pins Definition Pins Definition power connector is optional; however, Supermicro Ground 1~ 4 Ground recommends that this connector also be plugged in +12V 5 ~8 +12V for optimal power delivery.

  • Page 53: Fan Headers

    Chapter 2: Installation Fan Headers Fan Header Pin Definitions This motherboard has six system/CPU Pin# Definition fan headers (Fan 1~Fan 5, Fan A1) on Ground the motherboard. All these 4-pin fans +12V headers are backward compatible with Tachometer the traditional 3-pin fans. However, fan Pulse Width Modu- speed control is available for 4-pin fans lation (PWM)

  • Page 54: Internal Speaker

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Internal Speaker Internal Buzzer (SP1) Pin Definition The Internal Speaker, located at SP1, Pin# Definitions can be used to provide audible indica- Pin 1 Pos. (+) Beep In tions for various beep codes. See the Pin 2 Neg.

  • Page 55: Tpm Header/Port 80

    Chapter 2: Installation TPM Header/Port 80 TPM/Port 80 Header Pin Definitions A Trusted Platform Module/Port 80 Pin # Definition Pin # Definition header is located at JTPM1 to provide LCLK TPM support and Port 80 connection. LFRAME# <(KEY)> Use this header to enhance system LRESET# +5V (X) performance and data security.

  • Page 56: Power Smb (I 2 C) Connector

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Power SMB (I C) Connector PWR SMB Pin Definitions Power System Management Bus (I Pin# Definition Connector (JPI C1) monitors power Clock supply, fan and system temperatures. Data See the table on the right for pin PWR Fail definitions.

  • Page 57: T-Sgpio 1/2 Headers

    Chapter 2: Installation T-SGPIO 1/2 Headers T-SGPIO Pin Definitions Two SGPIO (Serial-Link General Pin# Definition Definition Purpose Input/Output) headers are lo- cated at J17, J18 on the motherboard. Ground Data These headers support Serial_Link Load Ground interface for onboard SATA connec- Clock tions.

  • Page 58: 10G_Lan3/Lan4 Led Indicators (X9Drw-3Ln4F+ Only)

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual 10G_LAN3/LAN4 LED Indicators (X9DRW-3LN4F+ Only) 10G_LAN Ports 3/4 LED Indicators (JF2) Pin Definitions The NIC (Network Interface Controller) Pin# Definition Definition LED connections for 10G_LAN port 3 are LAN4 Activity LAN4 Link located on pins 3 and 4 of JF2, and the LAN3 Activity LAN3 Link LED connections for 10G_LAN port 4 is on...

  • Page 59: Jumper Settings

    Chapter 2: Installation Jumper Settings Explanation of Jumpers Connector Pins To modify the operation of the motherboard, jumpers can be used to choose between optional settings. Jumpers create shorts be- Jumper tween two pins to change the function of the connector.

  • Page 60: Cmos Clear

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual CMOS Clear JBT1 is used to clear CMOS. Instead of pins, this "jumper" consists of contact pads to prevent accidental clearing of CMOS. To clear CMOS, use a metal object such as a small screwdriver to touch both pads at the same time to short the connection. Always remove the AC power cord from the system before clearing CMOS.

  • Page 61: Vga Enable

    Chapter 2: Installation VGA Enable VGA Enable Jumper Settings Jumper JPG1 allows the user to enable Jumper Setting Definition the onboard VGA connector. The default Enabled (Default) setting is 1-2 to enable the connection. Disabled See the table on the right for jumper settings.

  • Page 62: Management Engine (Me) Recovery

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Management Engine (ME) Recovery ME Recovery Jumper Settings Use Jumper JPME1 to select ME Firm- Jumper Setting Definition ware Recovery mode, which will limit Normal (Default) resource allocation for essential system ME Recovery operation only in order to maintain nor- mal power operation and management.
  • Page 63 Chapter 2: Installation C Bus to PCI-Exp. Slots C to PCI-Exp Jumper Settings Jumpers JI C1 and JI C2 allow you Jumper Setting Definition to connect the System Management Closed Enabled Bus (I C) to PCI-Express slots. The Open Disabled (Default) default setting is Open to disable the connection.

  • Page 64: Onboard Led Indicators

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Onboard LED Indicators Link LED Act LED GLAN LEDs The LAN 1/2 and 3/4 ports are located on Rear View (when facing the rear side of the chassis) the IO Backplane. Please note that LAN3/ GLAN Activity Indicator (Left) LAN4 support 10GLAN connections on the LED Settings X9DRW-3TF+, and support 1 GLAN for the...

  • Page 65: Onboard Power Led

    Chapter 2: Installation Onboard Power LED Onboard PWR LED Indicator (LE1) LED Settings An Onboard Power LED is located at LE1 LED Color Status on the motherboard. When this LED is on, System Off (PWR cable not connected) the system is on. Be sure to turn off the Green System On system and unplug the power cord before...

  • Page 66: Bmc Heartbeat Led

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual BMC Heartbeat LED BMC Heartbeat LED Status A BMC Heartbeat LED is located at LEM2 Color/State Definition on the motherboard. When LEM2 is blink- Green: BMC: Normal ing, BMC functions normally. See the Blinking table on the right for more information. LAN4 LAN3 LAN1...

  • Page 67: 2-10 Serial Ata Connections

    Intel PCH C606 Controller. See the table on the right for pin definitions. Note: For more information on SATA HostRAID configuration, please refer to the Intel SATA HostRAID User's Guide posted on our website @ http:// www.supermicro.com. A. I-SATA0 LAN4 LAN3...
  • Page 68 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Notes 2-44...

  • Page 69: Chapter 3 Troubleshooting

    Chapter 3: Troubleshooting Chapter 3 Troubleshooting Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the ‘Technical Support Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter. Note: Always disconnect the power cord before adding, changing or installing any hardware components.
  • Page 70 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual No Video 1. If the power is on, but you have no video, remove all the add-on cards and cables. 2. Use the speaker to determine if any beep codes exist. Refer to Appendix A for details on beep codes. System Boot Failure If the system does not display POST or does not respond after the power is turned on, check the following:...
  • Page 71 2. Memory support: Make sure that the memory modules are supported by test- ing the modules using memtest86 or a similar utility. Note: Refer to the product page on our website http://www.supermicro. com for memory and CPU support and updates.
  • Page 72 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual within the normal range. Also check the front panel Overheat LED, and make sure that the Overheat LED is not on. 5. Adequate power supply: Make sure that the power supply provides adequate power to the system. Make sure that all power connectors are connected. Please refer to our website for more information on minimum power require- ment.

  • Page 73: Technical Support Procedures

    Technical Support Procedures Before contacting Technical Support, please take the following steps. Also, please note that as a motherboard manufacturer, Supermicro also sells motherboards through its channels, so it is best to first check with your distributor or reseller for troubleshooting services.

  • Page 74: Battery Removal And Installation

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Battery Removal and Installation Battery Removal To remove the onboard battery, follow the steps below: 1. Power off your system and unplug your power cable. 2. Locate the onboard battery as shown below. 3. Using a tool such as a pen or a small screwdriver, push the battery lock out- wards to unlock it.

  • Page 75: Frequently Asked Questions

    Note : The SPI BIOS chip used on this motherboard cannot be removed. Send your motherboard back to our RMA Department at Supermicro for repair. For BIOS Recovery instructions, please refer to the AMI BIOS Recovery Instructions posted at http://www.supermicro.com.

  • Page 76: Returning Merchandise For Service

    Shipping and handling charges will be applied for all orders that must be mailed when service is complete. For faster service, you can also request a RMA authorization online (http://www.supermicro.com/RmaForm/). This warranty only covers normal consumer use and does not cover damages in- curred in shipping or from failure due to the alternation, misuse, abuse or improper maintenance of products.

  • Page 77: Chapter 4 Bios

    Chapter 4: AMI BIOS Chapter 4 BIOS Introduction This chapter describes the AMI BIOS Setup utility for the X9DRW-3LN4F+/3TF+. It also provides the instructions on how to navigate the AMI BIOS Setup utility screens. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated. Starting BIOS Setup Utility To enter the AMI BIOS Setup utility screens, press the <Del>...

  • Page 78: Main Setup

    <Delete> at the appropriate time during system boot. Note: For AMI UEFI BIOS Recovery, please refer to the UEFI BIOS Re- covery User Guide posted @http://www.supermicro.com/support/manuals/. Starting the Setup Utility Normally, the only visible Power-On Self-Test (POST) routine is the memory test.
  • Page 79 This item displays the system date in Day MM/DD/YY format (e.g. Wed 10/12/2011). System Time This item displays the system time in HH:MM:SS format (e.g. 15:32:52). Supermicro X9DRW-3LN4F+/X9DRW-3TF+ Version This item displays the SMC version of the BIOS ROM used in this system.

  • Page 80: 4-3 Advanced Setup Configurations

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual 4-3 Advanced Setup Configurations Use the arrow keys to select Advanced and press <Enter> to access the following submenu items. Boot Features Quiet Boot This feature allows the user to select bootup screen display between POST mes- sages and the OEM logo. Select Disabled to display the POST messages. Select Enabled to display the OEM logo instead of the normal POST messages.
  • Page 81 Chapter 4: AMI BIOS Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Enabled, the ROM BIOS of the host adaptors will "capture" Interrupt 19 at bootup and allow the drives that are attached to these host adaptors to function as bootable disks.
  • Page 82 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual • CPU Stepping • Maximum CPU Speed • Minimum CPU Speed • Processor Cores • Intel HT (Hyper-Threading) Technology • Intel VT-x Technology • Intel SMX Technology • L1 Data Cache • L1 Code Cache • L2 Cache •...
  • Page 83 Chapter 4: AMI BIOS Active Processor Cores Set to Enabled to use a processor's second core and above. (Please refer to Intel's website for more information.) The options are All, 1, 2, 4 and 6. Limit CPUID Maximum This feature allows the user to set the maximum CPU ID value. Enable this function to boot the legacy operating systems that cannot support processors with extended CPUID functions.
  • Page 84 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Intel® Virtualization Technology (Available when supported by the CPU) Select Enabled to support Intel Virtualization Technology, which will allow one platform to run multiple operating systems and applications in independent parti- tions, creating multiple "virtual" systems in one physical computer. The options are Enabled and Disabled.
  • Page 85 Chapter 4: AMI BIOS CPU C6 Report (Available when Power Technology is set to Custom) Select Enabled to allow the BIOS to report the CPU C6 State (ACPI C3) to the operating system. During the CPU C6 State, the power to all cache is turned off.
  • Page 86 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Short Duration Power Limit This item displays the time period during which short duration power is main- tained. The default setting is 0. Chipset Configuration North Bridge This feature allows the user to configure the settings for the Intel North Bridge. Integrated IO Configuration Intel VT-d Select Enabled to enable Intel Virtualization Technology support for Direct I/O...
  • Page 87 Chapter 4: AMI BIOS IIO 2 PCIe Port Bifurcation Control This submenu configures the following IO PCIe Port Bifurcation Control settings for IIO 2 PCIe ports to determine how the available PCI-Express lanes to be distributed between the PCI-Exp. Root Ports. IOU2-PCIe Port This feature allows the user to set the bus speed between the IOU2 and the PCI-Exp port.
  • Page 88 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Current Memory Speed This item displays the current memory speed. Mirroring This item displays if memory mirroring is supported by the motherboard. Memory mirroring creates a duplicate copy of the data stored in the memory to enhance data security.
  • Page 89 Chapter 4: AMI BIOS Patrol Scrub Patrol Scrubbing is a process that allows the CPU to correct correctable memory errors detected on a memory module and send the correction to the requestor (the original source). When this item is set to Enabled, the IO hub will read and write back one cache line every 16K cycles, if there is no delay caused by internal processing.
  • Page 90 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Stepping: This item displays the status of the PCH stepping. USB Devices: This item displays the USB devices detected by the BIOS. All USB Devices This feature enables all USB ports/devices. The options are Disabled and Enabled. (If set to Enabled, EHCI Controller 1 and Controller 2 will appear.) EHCI Controller 1/EHCI Controller 2 (Available when All USB Devices is set to Enabled)
  • Page 91 Chapter 4: AMI BIOS SATA Mode Use this feature to configure SATA mode for a selected SATA port. The options are Disabled, IDE Mode, AHCI Mode and RAID Mode. The following are displayed depending on your selection: IDE Mode The following items are displayed when IDE Mode is selected: Serial-ATA (SATA) Controller 0~1 Use this feature to activate or deactivate the SATA controller, and set the compatibility mode.
  • Page 92 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual SCU (Storage Control Unit) Configuration Storage Controller Unit Select Enabled to enable PCH SCU storage devices. The options are Disabled and Enabled. OnChip SCU Option ROM Select Enabled to support the onboard SCU Option ROM to boot up the system via a storage device.
  • Page 93 Chapter 4: AMI BIOS Maximum Payload Select Auto to allow the system BIOS to automatically set the maximum payload value for a PCI-E device to enhance system performance. The options are Auto, 128 Bytes and 256 Bytes. Maximum Read Request Select Auto to allow the system BIOS to automatically set the maximum Read Request size for a PCI-E device to enhance system performance.
  • Page 94 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Serial Port 1 Configuration Serial Port Select Enabled to enable a serial port specified by the user. The options are En- abled and Disabled. Device Settings This item displays the settings of Serial Port 1. Change Settings Use this feature to set the optimal Platform Environment Control Interface (PECI) setting for a serial port specified.
  • Page 95 Chapter 4: AMI BIOS Serial Port Console Redirection COM 1/COM 2 These two submenus allow the user to configure the following Console Redirection settings for a COM Port specified by the user. Console Redirection Select Enabled to use a COM Port selected by the user for Console Redirection. The options are Enabled and Disabled.
  • Page 96 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Stop Bits A stop bit indicates the end of a serial data packet. Select 1 Stop Bit for standard serial data communication. Select 2 Stop Bits if slower devices are used. The options are 1 and 2. Flow Control This feature allows the user to set the flow control for Console Redirection to prevent data loss caused by buffer overflow.
  • Page 97 Chapter 4: AMI BIOS Console Redirection Settings  This feature allows the user to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user. Out-of-Band Management Port The feature selects a serial port used by the Microsoft Windows Emergency Management Services (EMS) to communicate with a remote server.
  • Page 98 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual ACPI Sleep State Use this feature to select the ACPI State when the system is in sleep mode. Select S1 (CPU_Stop_Clock) to erase all CPU caches and stop executing instructions. Power to the CPU(s) and RAM is maintained, but RAM is refreshed. Select Sus- pend Disabled to use power-reduced mode.
  • Page 99 Chapter 4: AMI BIOS TPM Active Status This item displays the status of TPM Support to indicate if TPM is currently ac- tive or deactivated. TPM Owner Status This item displays the status of TPM Ownership. Intel TXT (LT-SX) Configuration Intel TXT (LT-SX) Hardware Support This feature indicates if the following hardware components support the Intel Trusted Execution Technology.
  • Page 100 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual iSCSI Initiator Name This item displays the name of the iSCSI Initiator, which is a unique name used in the world. The name must use IQN format. The following actions can also be performed: • Add an Attempt •...

  • Page 101: Event Logs

    Chapter 4: AMI BIOS • PCI Device ID • PCI Bus:Device:Function • Link Status • Factory MAC Address • Alternate MAC Address Event Logs Use this feature to configure Event Log settings. Change SMBIOS Event Log Settings  This feature allows the user to configure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging...
  • Page 102 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Runtime Error Logging Support Select Enabled to support Runtime Error Logging. The options are Enabled and Disabled. Memory Correctable Error Threshold This feature allows the user to enter the threshold value for correctable memory errors. The default setting is 10. PCI Error Logging Support Select Enabled to support error event logging for PCI slots.

  • Page 103: Ipmi

    Chapter 4: AMI BIOS View System Event Log This item allows the user to view the event in the system event log. Select this item and press <Enter> to view the status of an event in the log. Date/Time/Error Code/Severity IPMI Use this feature to configure Intelligent Platform Management Interface (IPMI) settings.
  • Page 104 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Erasing Settings Erase SEL Select Yes, On next reset to erase all system event logs upon next system reboot. Select Yes, On every reset to erase all system event logs upon each system reboot. Select No to keep all system event logs after each system reboot. The options are No, Yes, On next reset, and Yes, On every reset.

  • Page 105: Boot

    Chapter 4: AMI BIOS Subnet Mask This item displays the sub-network that this computer belongs to. The value of each three-digit number separated by dots should not exceed 255. Station MAC Address This item displays the Station MAC address for this computer. Mac addresses are 6 two-digit hexadecimal numbers.

  • Page 106: Security

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual USB Device BBS Priorities, Network Device BBS Priorities, Hard Disk Drives Use these options to set the order of the legacy network, USB, and Hard Disk Drive devices detected by the motherboard. Add New Boot Option This feature allows the user to add a new EFI (Extensible Firmware Interface) boot option to the boot order.

  • Page 107: Save & Exit

    Chapter 4: AMI BIOS Save & Exit This submenu allows the user to configure the Save and Exit settings for the system. Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system configuration, and reboot the computer. Select Discard Changes and Exit, and press <Enter>.
  • Page 108 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Discard Changes Select this feature and press <Enter> to discard all the changes and return to the BIOS setup. When the dialog box appears, asking you if you want to load previ- ous values, click Yes to load the values previous saved, or click No to keep the changes you've made so far.

  • Page 109: Appendix A Bios Error Beep Codes

    Appendix A: BIOS POST Error Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed at each system boot, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue to boot.
  • Page 110 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Notes...

  • Page 111: Appendix B Software Installation Instructions

    To install these programs, click the icons to the right of these items. Note: To install the Windows OS, please refer to the instructions posted on our Website at http://www.supermicro.com/support/manuals/. Driver/Tool Installation Display Screen Note 1: Click the icons showing a hand writing on the paper to view the readme files for each item.

  • Page 112: Configuring Superdoctor® Iii

    X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Note 3: Changing BMC log-in information is recommended during initial system power-on. The default username is ADMIN and password is ADMIN. For BMC best practices, please refer to: http://www.supermicro. com/products/nfo/files/IPMI/Best_Practices_BMC_Security.pdf B-2 Configuring SuperDoctor III The SuperDoctor® III program is a Web-based management tool that supports remote management capability.
  • Page 113 Appendix B: Software Installation Instructions SuperDoctor® III Interface Display Screen-II (Remote Control) Note: The SDIII utility and the user guide can be downloaded from our website at: http://www.supermicro.com/products/accessories/software/ SuperDoctorIII.cfm. For Linux, we will still recommend that you use SuperDoctor II.
  • Page 114 X9DRW-3LN4F+/3TF+ Motherboard User’s Manual Notes...
  • Page 115 (Disclaimer Continued) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.
