Projector Description
Projector
1.
External control panel
(see next page)
2.
Projection lens
3.
Front adjustment feet
4.
IR remote sensor
5.
Ventilation grill
6.
Kensington lock
7.
AC power cord input
8.
S-video connector
BOXLIGHT XD-15c User's Guide
9.
Video connector
10. D-sub connector
(for computer/ HDTV input)
11. Audio input
12. Rear adjustment feet
13. Lamp access door
(underneath unit)
