- Page 1 USER’S GUIDE BOXLIGHT XD-16n...
- Page 2 DLP PROJECTOR USER’S GUIDE Thank you for purchasing the projector. Please read this user’s guide to ensure correct use of the device. Save this user’s guide for future reference. OUTLINE This projector can display various computer signals and NTSC/ PAL/ SECAM/ HDTV video signals.
- Page 3 Copyright Copyright © 2003. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this company.
-
Page 4: Table Of Contents
Table of Contents Introduction ......1 Safety Instructions ..........1 FCC Statement . - Page 5 Specifications ......23 Projector Specifications ......... . 23 Timing Chart .
-
Page 6: Introduction
INTRODUCTION Caution TO PREVENT SHOCK, DO NOT OPEN THE CABINET. NO USER –SER- VICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. PLEASE READ THIS USER’S GUIDE BEFORE YOU OPER- ATE YOUR PROJECTOR. SAVE THIS USER’S GUIDE FOR FUTURE REF- ERENCE . -
Page 7: Fcc Statement
Caution • Do not look straight at the projector lens during operation. The intense light beam may damage your eyes. • In some countries, the line voltage is NOT stable. This projector is designed to operate safely within a bandwidth of 100 to 240 volts, but could fail if power cuts or surges of + 10 volts occur. -
Page 8: Shipping Contents
Shipping Contents The Projector is shipped with the cables required for connection to standard PC or laptop computers. Carefully unpack and verify that you have all the items shown below. If any of these items are missing, please contact your place of purchase. -
Page 9: Projector Components
Projector Components Projector PC/ HD (YP connector USB MOUSE connector VIDEO connector S-VIDEO connector IR remote sensor AC power cord inlet Kensington lock External control panel Zoom and focus "External Control Panel" on (see adjustments page 5 for more detailed information) Ventilation grill IR remote sensor Adjuster foot... -
Page 10: External Control Panel
External Control Panel Power indicator Lamp indicator ADJUST POWER SOURCE AUTO Power indicator Lamp Indicator The indicator lights green for normal The Lamp Indicator will light when the operation. If there is a problem, the lamp needs service, cooling or projector will flash green LED or replacement. -
Page 11: Adjuster
Adjuster The projector is equipped with a quick-release adjuster foot. Push the release button to adjust the position of the adjuster foot. Lift the projector up and press the adjuster button to release the adjuster. The adjuster will drop into position and lock into place. Note: The adjuster can only bear the weight of the projector itself . -
Page 12: Remote Control Description
Remote Control Description The remote control sensors are located in the front and back of the projector. The distance between the sensor and the remote control should not exceed 9 meters (29ft). POWER MENU Press to display the OSD menu system, or SOURCE to go back to the main menu and to leave the... - Page 13 MOUSE DRAG When using the remote control as a mouse, choose your desired item and press MOUSE DRAG. Drag it to wherever you want on the projection image and press MOUSE LEFT to release the item. STILL Makes the projection image still.
-
Page 14: Installing Or Replacing Batteries ("Aa" Type)
Installing or Replacing Batteries (“AA” type) Position the lid Install batteries Press and open over the as indicated by the battery compartment the diagram compartment lid and snap it back inside the and pull it away into place. compartment. from the remote. Caution Avoid excessive heat and humidity. -
Page 15: Installation
INSTALLATION Display Size The image size is determined by the position of the zoom adjustment and the distance from the screen. The table below shows the image diagonal dimension for given distances. The effective display size is 26 to 228 inches diagonally. L Projection Distance •... -
Page 16: Connecting To Various Equipment
Connecting to Various Equipment HDTV description The projector is capable of displaying various High Definition TV display modes. Some of these sources are: • Digital-VHS (D-VHS) player • DVD player • Satellite Dish HDTV receiver • DTV tuners Most of these sources will provide an analog component video output, a standard VGA output, or a YP (default) format. -
Page 17: Operation
OPERATION Start Up Plug the power cord into a wall socket. The power and source LEDs will light momentarily and the fans will start and then stop. Then the source LED will go out and the power LED will turn orange. (110V) (220V) Press POWER to turn on the projector. -
Page 18: Digital Keystone Correction
Digital Keystone Correction Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom. To correct this, press KEYSTONE / (hot key) on the remote control, and then adjust the sliding bar labeled Keystone, as needed. -
Page 19: Source Selection
Source Selection When several input sources are connected, press SOURCE on the projector or the remote control to step through the available sources. Menu System Press Menu for the main menu, and then press Joystick to select a sub-menu. Press ENTER again to select items in the sub-menu. Main VIDEO POSITION... -
Page 20: Video Menu
1. VIDEO Menu FUNCTION DESCRIPTION Adjusts the degree of difference between dark and light in the image. Contrast Adjusts the brightness of the image. Brightness Increases or decreases the color range of the image. Color *This function is not available when the input mode is PC. Adjusts the image to make it appear more red or green. -
Page 21: Position Menu
2. POSITION Menu FUNCTION DESCRIPTION Adjusts the horizontal position of the projected image. Horizontal Adjusts the vertical positon of the projected image. Vertical Corrects any keystoning of the image. Keystone Activates the Zoom function. Refer to the Remote Control Zoom Description on page 8 for more information on this feature. -
Page 22: Special Menu
3. SPECIAL Menu FUNCTION DESCRIPTION Language sets the language for the OSD control menus. Use the Joystick to select the desired language from among Language English, French, German, Italian, Spanish, Korean, Simpli- fied Chinese and Traditional Chinese. Projects images when the Default projector is 180 degrees horizontally rotated. -
Page 23: Tracking Menu
4. TRACKING Menu This sub-menu only works in PC mode. FUNCTION DESCRIPTION Automatically determines the best picture settings for Auto Tracking the current PC input. Clock Adjust the image size. Adjust to eliminate flicker. Phase DLP Personal Projector... -
Page 24: Shutdown
Shutdown Press POWER and a warning message will appear. To turn off the projector, press POWER again. The projection lamp will shut off and the fan will continue to run for approximately 90 seconds, during which the LED will flash. * After the projector is turned off, there is a 90-second cooling period before the projector can be re-started. -
Page 25: Maintenance
MAINTENANCE Lamp Information Use and Replacement of the Lamp The average lamp life is 1500 hours. When the Power Indicator lights up red and the Lamp Indicator lights up orange suggesting lamp replacement, please install a new lamp or consult your dealer. An old lamp could cause a malfunction in the projector and may even explode. -
Page 26: Operating Information
Operating Information The Power and Lamp LEDs will light in different color combinations when there is a problem with the projector. Use the chart below to troubleshoot problems with the projector. State LEDs Display Description Operation Status LED Projector is in Normal State. Normal Green Lamp Time <... -
Page 27: Troubleshooting
TROUBLESHOOTING Common Problems & Solutions PROBLEMS TRY THESE SOLUTIONS • Make sure the power cord is inserted properly into the AC adapter socket. • Make sure the power cord is inserted properly into the NO POWER power outlet. • Wait 90 seconds after the projector is turned off before turning the projector back on. -
Page 28: Specifications
SPECIFICATIONS Projector Specifications Technical Specifications Note: All specifications are subject to change without notice. General Product name Personal Projector Optical Display system 1-CHIP DMD Lens F/Number F/2.4 Lamp 150W NSH lamp Electrical Power supply AC100 ~ 240V, 3A, 50/60 Hz (Automatic) Power consumption 250 W (Max) Mechanical... -
Page 29: Timing Chart
Timing Chart Resolution H Sync (kHz) V Sync (Hz) Remark 640x350 31.5 70.1 640x400 37.9 85.1 VESA 720x400 31.5 70.0 720x400 37.9 85.1 VESA 640x480 31.5 60.0 VESA 640x480 35.0 66.7 Macintosh 640x480 37.9 72.8 VESA 640x480 43.3 85.0 VESA 800x600 35.2 56.3... -
Page 30: Dimensions
DIMENSIONS Unit: mm DLP Personal Projector... -
Page 31: Limited Warranty
(iii) the model and serial number of the Product. When sending your unit in for repair, please ship your unit in its original packing material or a Boxlight approved ATA Shipping Case, or have a professional packaging company pack the unit. Please insure your shipment for its full value. -
Page 32: Limitation Of Liability
LIMITATION OF LIABILITY IT IS UNDERSTOOD AND AGREED THAT BOXLIGHT’S LIABILITY WHETHER IN CONTRACT, IN TORT, UNDER ANY WARRANTY, IN NEGLIGENCE OR OTHERWISE SHALL NOT EXCEED THE RETURN OF THE AMOUNT OF THE PURCHASE PRICE PAID BY PURCHASER AND UNDER NO CIRCUMSTANCES SHALL BOXLIGHT BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOST PROFITS, LOST REVENUES OR LOST SAVINGS. - Page 33 Boxlight 19332 Powder Hill Place Poulsbo, WA 98370-7407 USA www.boxlight.com USA and Canada 800-762-5757 International 360-779-7901 Part No.: 49.J7801.011 DOC: E0305A-ProXD16n...
