- Page 1 BOXLIGHT XD-15c User’s Guide...
- Page 2 Copyright Copyright © 2002 by BOXLIGHT Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of BOXLIGHT Corporation.
-
Page 3: Table Of Contents
Projector Description ........ - Page 4 Projector Specifications ........26...
-
Page 5: Introduction
OPERATE YOUR PROJECTOR. SAVE THIS USER’S GUIDE FOR FUTURE REFERENCE . Safety Instructions Read this user’s guide before you operate your projector and save it for future reference. The lamp becomes extremely hot during operation. Allow the projector to cool for approximately 45 minutes prior to removing the lamp assembly for replacement. -
Page 6: Warranty
120 days and the accessories after one year. Boxlight does not warrant that the Product will meet the specific requirements of the first person or entity that purchases the Product for personal or business use. Boxlight's liability for the breach of the foregoing limited warranty is limited to the repair or replacement of the Product or refund of the purchase price of the Product, at Boxlight's sole option. -
Page 7: Limitation Of Liability
LIMITATION OF LIABILITY IT IS UNDERSTOOD AND AGREED THAT BOXLIGHT'S LIABILITY WHETHER IN CONTRACT, IN TORT, UNDER ANY WARRANTY, IN NEGLIGENCE OR OTHER- WISE SHALL NOT EXCEED THE RETURN OF THE AMOUNT OF THE PURCHASE PRICE PAID BY PURCHASER AND UNDER NO CIRCUMSTANCES SHALL BOXLIGHT BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOST PROFITS, LOST REVENUES OR LOST SAVINGS. -
Page 8: Shipping Contents
The projector is shipped with the cables required for connection to standard PC or laptop computers. Carefully unpack and verify that you have all the items shown below. If any of these items are missing, please contact BOXLIGHT. Optional Accessories... -
Page 9: Projector Description
Front adjustment feet IR remote sensor Ventilation grill Kensington lock AC power cord input S-video connector BOXLIGHT XD-15c User’s Guide Video connector 10. D-sub connector (for computer/ HDTV input) 11. Audio input 12. Rear adjustment feet 13. Lamp access door... -
Page 10: External Control Panel
The Status Indicator will blink or light up when the lamp needs service, cooling or replacement. See “Lamp Information” on page 20 for more detailed information. • When the projector is on, Back-lit Power will blink during warm-up and turn to solid green to indicate the projector is ready for use. •... -
Page 11: Adjuster
Adjuster The projector is equipped with a quick-release adjuster foot and button for adjusting its tilt angle. Lift the projector up and press the adjuster button to release the adjuster. The adjuster will drop into position and be locked. Projector Features The projector integrates high performance optical engine projection and user-friendly design to deliver high reliability and ease of use. -
Page 12: Remote Control Description
BOXLIGHT XD-15c User’s Guide Remote Control Description Remote Control Features The remote control sensors are located in the front/ back of the projector. The distance between the sensor and the remote control should not exceed 6 meters (20 feet). Introduction... - Page 13 BOXLIGHT XD-15c User’s Guide FREEZE The image can be frozen when FREEZE is pressed. A “Pause” icon will appear in the lower right corner of the screen for three seconds. To release the freeze function, press the FREEZE button, RETURN button or SOURCE button (when the input source is switched over during display) again.
-
Page 14: Installing Or Replacing Batteries
BOXLIGHT XD-15c User’s Guide Installing or Replacing Batteries • Push and slide the battery compartment lid in the direction shown. • Install batteries as indicated by the diagram inside the compartment. • Position the lid over the compartment and snap it back into place. -
Page 15: Installation
INSTALLATION Screen Size Place the projector at the required distance from the screen according to the desired picture size (see the table below). Screen Size (Max.) Diagonal A. Width (cm/in) (cm/in) 77/30.4 61.8/24 154/60.8 123.65/49 232/91.2 185.3/73 309/121.5 247.0/97 386/151.9 308.7/122... -
Page 16: Operation
BOXLIGHT XD-15c User’s Guide OPERATION Start Up Plug the power cord into a wall socket. Press POWER for 1 second. • The back-lit POWER key blinks green and stays green when the power is turned (When the power is turned off, there is a 60-second cooling period before the projector can be re-started.) -
Page 17: Digital Keystone Correction
In some cases, you may have to optimize the picture quality manually. To do this, press the AUTO key on the control panel of the projector or on the remote control. Within 3 seconds, the built-in Intelligent Auto Adjustment function will re-adjust to the best picture quality. -
Page 18: Source Selection
BOXLIGHT XD-15c User’s Guide Source Selection When several input sources are available, press the SOURCE key to make a selection from the control panel of the projector or the remote control. Projector Auto Menu System Press Menu for the main menu and press again to select items in the sub-menu. -
Page 19: Display Menu
BOXLIGHT XD-15c User’s Guide 1. Display Menu Corrects any keystoning of the image. Keystone Adjusts the brightness of the image. Brightness Adjusts the degree of difference between darkness and lightness of the image. Contrast Adjusts to avoid the occurrence of flicker. -
Page 20: Image Menu
BOXLIGHT XD-15c User’s Guide 2. Image Menu Auto resize H-position V-position Color Temp. Information Ratio System Sharpness Color Tint Operation Makes the best fit of the image to the screen, Adjusts the horizontal position of the projected image. Adjusts the vertical positon of the projected image. -
Page 21: Source Menu
Rear screen projection Ceiling - mounted and rear screen projection Selects sources between PC, Video, S-Video, and YPbPr. Source Adjusts the volume level. Volume Adjusts the treble level. Treble Adjusts the bass level. Bass Mute BOXLIGHT XD-15c User’s Guide Operation 17... -
Page 22: Control Menu
BOXLIGHT XD-15c User’s Guide 4. Control Menu Language OSD Time Auto Off Reset Lamp Hour 5. PIP Menu These functions are valid only when the input mode is PC and the PIP source is Video or S-Video. PIP Source PIP Size... -
Page 23: Shutdown
Shutdown Press POWER and a warning message will prompt up. To turn off the projector, Press POWER again. The fan will continue to run for approximately 60 seconds. Disconnect the power cord from the wall socket. Caution Please do not unplug the power cord before POWER is shut down or dur- ing the 60-second cooling process. -
Page 24: Maintenance
The LAMP indicator will light up if the lamp becomes too hot. Turn off the power and let the projector cool for 45 minutes. If the LAMP indicator is still red when turning the power on, please contact BOXLIGHT Technical Sup- port at 1-800-762-5757 or +1-360-779-7901. - Page 25 If you touch the optical parts inside, this could cause color unevenness. Replace the lamp with a new one. Insert it into the projector, and tighten the screws firmly. Loose screws may cause a bad connection, which may result in malfunction.
-
Page 26: Resetting Lamp Hours
BOXLIGHT XD-15c User’s Guide Caution To reduce the risk of severe burns, allow the projector to cool for at least 45 minutes before replacing the lamp. To reduce the risk of injuries to fingers and damage to internal components, use caution when removing lamp glass that has shattered into sharp pieces. -
Page 27: Service Information
Spare lamp module Ordering Parts or Getting Information For product information, product assistance, service information, or to order accessories, please contact BOXLIGHT Corporation at 1-800-762-5757 or +1-360- 779-7901 or visit the web site at www.boxlight.com. BOXLIGHT XD-15c User’s Guide Maintenance 23... -
Page 28: Troubleshooting
Use the Keystone correction key on the control panel of the projector or the remote control unit. Select the correct video system. Adjust brightness, contrast, or saturation. Press Auto on the control panel of the projector or the remote control unit to get better picture quality. Adjust the focus. -
Page 29: Status Messages
CHANGE THE LAMP! Description Projector is searching for input. Projector has identified the input signal and is running the auto image adjustment function. Input signal frequency exceeds the projector’s range. The lamp has been in operation for 1400 hours. Lamp replace- ment is recommended. -
Page 30: Specifications
BOXLIGHT XD-15c User’s Guide SPECIFICATIONS Projector Specifications Technical Specifications Note: All specifications are subject to change without notice. General Product name Model name Optical Display system Lens F/Number Lamp Electrical Power supply Power consumption Mechanical Dimensions Operating Temperature range Weight... -
Page 31: Timing Chart
37.9 31.5 37.9 31.5 37.9 35.0 43.3 35.2 37.9 46.9 48.1 53.7 49.7 48.4 56.5 60.0 68.7 64.0 BOXLIGHT XD-15c User’s Guide Remark 70.1 85.1 VESA 70.0 85.1 VESA 60.0 VESA 72.8 VESA 66.7 Macintosh 85.0 VESA 56.3 VESA 60.3 VESA 75.0... -
Page 32: Dimensions
BOXLIGHT XD-15c User’s Guide DIMENSIONS 220mm 175 mm 52mm Dimensions...
