BOXLIGHT XD-15c User's Guide

4. Control Menu

Language
OSD
OSD Time
Auto Off
Reset
Lamp Hour

5. PIP Menu

These functions are valid only when the input mode is PC and the PIP source is Video or
S-Video.
PIP Source
PIP Size
PIP Position
H Position
V Position
More Options
Brightness
Contrast
Color
Tint
Sharpness
System
Operation
18
Language sets the OSD to display in one of 7 languages.
Use 3 / 4 key to select the languages: English, French, Ger-
man, Italian, Spanish, Simplified Chinese and Traditional Chi-
nese.
Selects a desired OSD position.
Sets the length of time the OSD will remain active after the last
time you pressed the button. The range is from 5 to 60 sec-
onds in 5-second increments.
Sets the length of time to shut off the system when no input is
detected.
Returns all settings to the time of manufacturing.
Shows lamp usage time.
Selects the source for the PIP.
Uses 3 / 4 key to scroll through the 4 alternatives: Off,
Small, Medium, Large.
Selects a desired position for the PIP.
Adjusts the horizontal position of the PIP image.
Adjusts the vertical position of the PIP image.
Uses 3 / 4 key to select more PIP functions including Bright-
ness, Contrast, Color, Tint, Sharpness and System.
Adjusts the brightness of the PIP image.
Adjusts the degree of difference between dark and light for the
PIP image.
Increases or decreases the color range (R, G, B) of the image.
Adjusts the image to make it appear more red or blue.
Adjusts the image to make it appear sharper or softer
Selects PIP image systems: Auto, NTSC, PAL, SECAM
