FCC Notice
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference
in a residential installation.
Trademarks
Trademarks are the rights of their respective owners.
Advertisement
Table of Contents
Related Manuals for BOXLIGHT XD-17k
Summary of Contents for BOXLIGHT XD-17k
-
Page 1: Fcc Notice
FCC Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to pro- vide reasonable protection against harmful interference in a residential installation. Trademarks Trademarks are the rights of their respective owners. -
Page 2: Table Of Contents
English Table of Contents Usage Notice Precautions ..................2 Introduction Product Features .................. 3 Package Overview ................4 Product Overview ................. 5 Installation Connecting the Projection Display ............8 Powering On/Off the Projection Display..........9 Adjusting the Projected Image .............. 11 User Controls Panel Control &... -
Page 3: Usage Notice
English Usage Notice Do not look into the lens. The bright light may hurt your eyes. Warning- To reduce the risk of fire or electric shock, do not expose this Warning- product to rain or moisture. Please do not open or disassemble the product as this may cause Warning- electric shock. -
Page 4: Introduction
English Introduction Product Features This product, is an XGA single chip 0.7” DLPä Projector. The outstanding features of it are listed as follows: True XGA, 1024 x 768 addressable pixels 3.3 lbs (1.5 kgs) lightweight compact design ä Single chip DLP technology SXGA compression and VGA, SVGA re-sizing 130 Watts user replaceable P-VIP lamp... -
Page 5: Package Overview
English Package Overview This projection display comes with all the items shown below. Check to make sure your unit is complete. Contact your dealer immediately if anything is missing. Projection Display Power Cord D-Sub RGB to DVI Cable RCA Audio Cable Composite Video Cable S-Video Cable DVI Signal Cable for... -
Page 6: Product Overview
English Product Overview Panel Control Enter / Lamp Volume Mute Source Resync Warning LED Temperature Warning LED Four Directional Menu Power On / Standby Select Keys (On/Off) Main Unit Elevator Button Panel Control Speaker Remote Control Receiver Focus Ring Zoom Lens Power Connector Zoom Ring Connection Ports... - Page 7 English Remote Control with Mouse Function & Laser Pointer LED Point Four Directional Select Keys Resync Power / Standby Page Down Source Laser Pointer Page Up Keystone Correction Volume ( + / - ) Zoom In / Zoom Out Mute Menu Freeze Caution: To reduce the risk of injury to the eyes, do not look directly...
- Page 8 English Enter Key Laser Pointer Caution...
-
Page 9: Installation
English Installation Connecting the Projection Display Power Cord DVI Signal Cable for HDTV/Component Digital Port RGB Port RS232 D-Sub RGB to Monitor Cable DVI Cable Composite Video Cable *DVI Signal Cable for DVI Digital Port RGB Port RCA Audio Cable S-Video Output Remote Mouse Y Cable S-Video Cable... -
Page 10: Powering On/Off The Projection Display
English Power On/Off the Projection Display Powering On the Projection Display u u u u u 1. Remove the lens cap.Œ 2. Ensure that the power cord and signal cable are securely connected. 3. The “Power/Standby” indicator will flash. And press the “Power/Standby” button again to start on your projector. - Page 11 English Powering Off the Projection Display u u u u u 1. Press the “Power/Standby” button to turn off the projector lamp. 2. After pressing the “Power/Standby” button, you will see a message “Power off the lamp?” on the on-screen display. Press the “Power/Standby” button again to confirm. Otherwise the message will disappear after 5 seconds.
-
Page 12: Adjusting The Projected Image
English Adjusting the Projected Image u u u u u Adjusting the Projector Height The projector is equipped with an elevator foot for adjusting the projector height. To raise the projector: Π1. Press the elevator button 2. Raise the projector to the desired display angle , then release the button to lock the elevator foot into position. -
Page 13: Adjusting Projection Image Size
English u u u u u Adjusting the Projector Zoom / Focus You may adjust zoom ring to zoom in / out. Rotate the zoom ring counter-clockwise to zoom in and clockwise to zoom out. To focus the image, rotate the focus ring until the image is clear. -
Page 14: User Controls
English User Controls Panel Control & Remote Control There are two ways for you to control the functions: Remote Control and Panel Control. Panel Control Remote Control Enter Key Power / Standby Refer to the “Power On/Off the Projection Display” section on page 8~9. Source Press “Source”... - Page 15 English Four Directional Select Keys When you close the cover of remote control, this key can be used as a mouse to control direction. * The above function is only enabled with the connection between computer and projector by remote mouse Y cable. When the cover of remote control is open, this key can be used for the operation for OSD display.
-
Page 16: On-Screen Display Menus
English On-Screen Display Menus How to operate The Projector has a multilingual On-Screen Display(OSD) menu that allows you to make image adjustments and change a variety of settings. In computer source, the OSD will be the “Computer OSD”. In video source, the OSD will be the “... -
Page 17: Color Temperature
English Computer mode Language Management Image-I Image-II Audio Brightness Zoom Contrast Keystone Color Temp. Image-I (Computer mode) Brightness Adjusting the brightness of the image. Press the to darken the image. Press the to lighten the image. Contrast The contrast controls the degree of difference between the lightest and darkest parts of the picture. - Page 18 English Video mode Language Management Image-I Image-II Audio Brightness Sharpness Contrast Tint Color Image-I (Video mode) Brightness Adjusting the brightness of the image. Press the to darken the image. Press the to lighten the image. Contrast The contrast controls the degree of difference between the lightest and darkest parts of the picture.
-
Page 19: Horizontal Position
English Computer mode Language Management Image-I Image-II Audio Frequency H. Position Tracking V. Position 16:9 / 4:3 Reset Image-II (Computer mode) Frequency “Frequency” is for changing the display data frequency to match the frequency of your computer’s graphic card. When you experience a vertical flickering bar, use this function to make an adjustment. -
Page 20: Keystone Correction
English Video mode Language Management Image-I Image-II Audio Keystone Color Temp. 16:9 / 4:3 Reset Image-II (Video mode) Keystone Correction Adjusts image distortion caused by tilting the projector. 416 : 9 / 4 : 3 You can select this function to fit your desired aspect ratio type. Color Temperature Adjusts the color temperature. - Page 21 English Computer / Video mode Computer / Video mode Language Management Image-I Image-II Audio Image-I Image-II Audio Language Management Volume Stereo / Mono Treble Mute Bass Audio Volume Press the to decrease the volume. Press the to increase the volume. Treble The treble setting controls the higher frequencies of your audio source.
-
Page 22: Menu Location
English Computer / Video mode Image-I Image-II Audio Language Management Menu Location Lamp Reminder Projection Lamp Reset Signal Type Component HDTV Management Menu Location Choose the Menu location on the display screen. Projection Front-Desktop The factory default setting. Rear-Desktop When you select this function, the projector reverses the image so you can project behind a translucent screen. -
Page 23: Appendices
English Appendices Troubleshooting If you are experiencing trouble with the projection display, refer to the following. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on screen. Ensure all the cables and power connections are correctly and securely connected as described in the “Installation”... - Page 24 English 4. Follow above steps 1~2. Click on the “Advanced Properties ” button. 5. Select the “Change” button under the “Monitor” tab . 6. Click on “ Show all devices ”. Then select “ Standard monitor types ” under the “...
- Page 25 English Problem : The screen is outstretched when displaying 16:9 DVD. The projector itself will automatically detect 16:9 DVD and adjust the aspect ratio by digitiza- tion to full screen with 4:3 default setting. If the projection display is still outstretched, you will also need to adjust the aspect ratio by referring to the following: Please select 4:3 aspect ratio type on your DVD player if you are playing a 16:9 DVD.
-
Page 26: Changing The Lamp
English Changing the lamp The projection display will detect the lamp life itself. It will show you a warning message “ Lamp is running out of standard lifetime. Be sure to replace the lamp as soon as possible.”. When you see this message, change the lamp as soon as possible. -
Page 27: Specifications
English Specifications Light Valve - Single Chip DLP Technology Contrast Ratio - 500:1 (Full On / Full Off) Lamp - 130W User Replaceable P-VIP Lamp Number of Pixels - 1024 pixels(H) X 768 lines(V) Displayable Color - 16.7M colors Projection Lens - F2.2~2.4 f=28.51~34.21mm with 1.2 x zoom &... -
Page 28: Compatibility Modes
English Compatibility Modes (ANALOG) (DIGITAL) Mode Resolution V.Frequency H.Frequency V.Frequency H.Frequency (Hz) (kHz) (Hz) (kHz) " " " " * compression computer image.
