Operation; A) Switch On And Off; B) Vacuum; C) Empty Dust Container - TOOLCRAFT HSG-100 Operating Instructions Manual

10. Operation

a) Switch on and off

• To switch on the vacuum cleaner, push the On/Off switch (2) to ON.
• To switch off the vacuum cleaner, move the On/Off switch to OFF.

b) Vacuum

Attention! Wear a suitable mask (respirator) that covers the nose and mouth to protect against breathing
in any small particles that pass through the ventilation slots.
Attention! Do not vacuum fine particles such as drywall dust, ash, concrete dust, plaster etc.
• Fine dust may damage the product.
• Ensure that materials you vacuum are not harmful to your health.
• Do not vacuum moist or wet materials. Do not vacuum liquids.
1. Switch the vacuum on.
2. Vacuum the area. If the suction tube is blocked, remove the objects before using again.
If the motor speed increases, increase the distance between nozzle and working object/area.
Refer to 14. Troubleshooting if you notice:
- a continuous increase in motor speed, or
- reduced suction performance
3. Turn the vacuum off and remove the battery.
4. Empty the dust container.

c) Empty dust container

D
1. Switch the vacuum off and remove the battery.
2. Push the container release button (1).
3. Remove the dust container (6). See
4. Remove the filter assembly (13) from the dust container. See
- If the filter (16) appears clogged, clean it. Refer to section 12. Care and cleaning for details.
5. Empty the container over a waste bin.
6. Clean the inside of the container with a moist cloth. Let the inside dry before reassembly.
7. Insert the filter assembly into the dust container.
8. Hinge the dust container to the motor unit and close it until it locks with an audible click.
.
D1
.
D2
23
