Connect video and audio
The EnGo supports HDMI or SDI video input with embedded audio.
1. Plug the included SDI or HDMI cable into the video camera's output port.
2. Plug the SDI or HDMI cable into the video input port on the EnGo.
3. Make sure that all cables are firmly connected.
The EnGo selects the correct video input automatically. If you do not see video on the screen,
make sure that the cables are connected properly and that you are using a supported video
format.
If the video format is not detected automatically, you may need to configure the video settings.
For more information, see Configuring the transmitter on page 16.
Connect Ethernet
Using an optional Ethernet connection, you can choose to transmit using Ethernet only or
broadcast over Ethernet and cellular networks simultaneously.
If multiple networks are available, you can plug in a second Ethernet cable for additional
throughput.
1. On the side of the EnGo, plug an Ethernet cable into one of the ports.
2. Ensure that UDP port 6000 is open on the network for inbound and outbound traffic.
The Ethernet adapter is configured to obtain IP address details automatically using DHCP. For
more information, see Configuring the transmitter on page 16.
Connect IFB
IFB acts as a one-way audio communication tool from Dejero receivers to the EnGo. It enables
communication and cueing from the studio crew to the reporter in the field. The station sends a
program feed to the reporter's earpiece, which is connected to the EnGo.
You can use IFB at any time – regardless of whether the EnGo is transmitting a live stream. To
use IFB when the EnGo is not live, both the EnGo and the receiver that you are using must be
using software version 5.3 or later.
For more information on Dejero receivers, visit
guides.
Note: Connecting IFB is optional.
1. Connect your audio device (such as an earpiece, headset, or IFB amplifier input) to the XLR
connector on the included adapter.
2. Plug the adapter into the min-XLR connector on the side of the EnGo.
As soon as the EnGo is turned on, an IFB indicator appears on the right side of the screen. It
shows the following information:
I = Idle
•
• R = Receiving
11 | Dejero EnGo 260 User Guide
support.dejero.com to read the receiver user
