12 LIST OF COMPONENTS IN ILLUSTRATIONS

Figure
1
2
3
4
5
Item Description
1 Unloading turret
2 Outfeed belt
3 Control panel
4 Flour recovery bin
5 Flour recovery bin
6 Main isolator switch
7 Electrical enclosure
8 Manual advance hub
9 Feed belt
10 Work area
11 Emergency stop button
12 General start
13 Cycle start
14 Cycle stop
15 Manual or auto proofer
16 Loaf or baguette
17 Volumetric start or stop
18 Moulder start, auto or stop
19 Outfeed belt start or stop
20 UV lamp start or stop
21 Protective panel
22 M8 screw and washer
23 Setscrew
24 Drive collar
25 17-tooth sprocket
26 Drive socket
27 Pictogram indicating an electrocution hazard
28 Bypass "option" button
