NetAtlas
(NetAtlas Workgroup)
Ethernet Switch

Support Notes

Version 1.00
March 2006

Advertisement

loading

  Also See for ZyXEL Communications 1

  Related Manuals for ZyXEL Communications 1

  Summary of Contents for ZyXEL Communications 1

  • Page 1: Support Notes

    NetAtlas (NetAtlas Workgroup) Ethernet Switch Support Notes Version 1.00 March 2006...
  • Page 2 How to easily manage and monitor network devices across networks becomes more and more important in network management. Figure 1 presents main elements of the system architecture. Element Management System (EMS), NetAtlas provides a centralized remote management platform and acts as SNMPc manager to perform network configuration, system management, event/alarm management, performance management and security for all ZyXEL’s...
  • Page 3 NetAtlas Support Notes Installation of Netatlas workgroup 1. Double click the installation file located on the Netatlas CD. 2. Read the license information, if you agree with the license, click “yes” to continue. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 4 NetAtlas Support Notes At this time, if SNMPc does not exist in your PC, the Netatlas installation program will install SNMPc for you. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 5 NetAtlas Support Notes All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 6 NetAtlas Support Notes 3. Choose “Server” and then click “Next” 4. Choose the location that you want to install Netatlas, then click “Next” All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 7 5. Netatlas comes with a feature called “Auto Discovery”, if you are not going to use this “Auto Discovery” at this time, check the box “Start with Discovery off”. Then click “Next” All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 8 6. Here it shows the default program folder that Netatlas is going to install. Click “Next” to continue. At this moment, the installation of SNMPc is completed. 7. If PostgreSQL does not exist in your PC, the Netatlas installation program will also install it for you. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 9 NetAtlas Support Notes 8. Please select Postgresql Install Path. Then click “Next” 9. It is NOT recommend changing the default account/password here. Just click “Apply” to continue. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 10 10. When the installation of PostgreSQL is done, it will pop up the following message. 11. When everything is set, the installation program will start to install Netatlas Workgroup. Finally, click “finish” to complete the whole installation process. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 11 Menu Shortcut Bar: The buttons execute common commands ♦ Device Panel: This is a graphical device display. ♦ Device List Panel: View devices in a tree structure. The colors of the device All contents copyright (c) 2006 ZyXEL Communications Corporation. NetAtlas Support Notes...
  • Page 12 Green is working and Rd is no response from the device. ♦ System message Panel: View the alarm Status and port status of the selected switch. Figure 3 Overview of EMS All contents copyright (c) 2006 ZyXEL Communications Corporation. NetAtlas Support Notes...
  • Page 13 In the following example, we will illustrate how to get started with SNMPc and Netatlas with adding a new device. Follow the procedures from Step 1 to Step 11. Step 1: In the edit button bar shown in the Figure 4 where you may select the icon to insert a new element.
  • Page 14 Step 4: In the map object properties, select Access tab to set the parameters of Read Access Mode to SNMP V2c shown in Figure 6. Change the value of Read Access Mode to SNMP V2c. Figure 6 Read Access mode All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 15 Figure 7 Read/Write Access Mode Step 6: In the map object properties, select Access tab to set the parameters of Read community to public as shown in Figure 8. Figure 8 Read Community All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 16 In the map object propeies, select Access tab to set the parameters of Read community to public in Figure 9. Change the value of Read//write Community to Public. Figure 9 Read/write Community All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 17 OSPF-MIB.mib zyxel-ES3124.mib zyxel-ES3124PWR.mib zyxel-ES2024A.mib zyxel-GS2024.mib zyxel-GS4024.mib zyxel-GS4012F.mib zyxel-ES2108.mib zyxel-ES2108G.mib Step 8: In the Selection tool menu, Click ES-2108 to manage the device. Figure 10 Device Selection All contents copyright (c) 2006 ZyXEL Communications Corporation. NetAtlas Support Notes...
  • Page 18 Step 10: In the EMS mapping, it display a logical hierarchy for the device. In the device list, you may see the devices are added in the Rootmap shown in Figure 12. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 19 NetAtlas Support Notes Figure 12 Rootmap Step 11: Click the ES-2108 to configure the device shown in Figure 13. Figure 13 Device mapping All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 20 In this section, we will give an example to illustrate how to use EMS to create a VLAN2 in GS-4024. Here are the procedures. Step 1: In the device panel list shown in Figure 12, right-click Configuration, Switch Configuration and then Switch Setup tab as shown in Figure 12 and Figure 13.
  • Page 21 After the VLAN type selection, a pop-up window indicates that you have finished the configuration. Then after we have defined the VLAN type to be the 802.1Q, go back to click the Configuration and then VLAN configuration in Figure 15. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 22 Click the New button to create a new VLAN ID in Figure 16. Figure 16 Creating a new VLAN ID Selecting Egress ports and defines them to be tagged or untagged in Figure 17 Figure 17 Selecting the ports All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 23 NetAtlas Support Notes For more information, reference the user guide of NetAtlas. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 24: Troubleshooting

    • Make sure that the computer you have installed the EMS on, is connected to the network where the switch is located. • Make sure your computer’s Ethernet card is working properly. • If the problem still persists, uninstall and re-install the EMS software. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 25 Database Trend Reporting SNMPc Online 2005 advanced reporting engine Live / Standby Backup Server Option Device Support All contents copyright (c) 2006 ZyXEL Communications Corporation. Netatlas Enterprise Distributed Architecture(Client-Server) Yes(concurrent 10 users) OBDC support (SNMPc) Up to 25,000 Network Devices...
