JETWAY NF695C6-3455 Series User Manual page 14

(3) JMD3 (4-pin): COM3 Header Pin9 Function Select
(4) JP1 (3-pin): MINIPCIE SLOT POWER VCC3.3V / 3VSB Select
JP1
JMD3
JMD3 COM3 Header Pin-9
→
5 3 1
6 2
4
2-4 Closed:
RING( Default);
JP1 → MPE1 Power VCC Select
1-2 Closed: MPE1 VCC=3.3V(Default);
;
2-3 Closed: MPE VCC=3VSB.
9
5 3 1
5 3 1
6 4 2 6 4 2
3-4 Closed:
4-6 Closed:
5V;
12V.
1
3
1
3
