Headers
Header
FP
F_USB1/ F_USB2/
F_USB3
COM1
COM2
COM3-6
LAN1_LED
LAN2_LED
PS2KBMS
FP_AUDIO
GPIO
SMBUS
FP_BUZZ
INVERTER
EDP
LVDS
Name
Front Panel Header
(PWR LED/ HDD LED/
Power Button /Reset)
USB 2.0 Header
RS232 Serial Port Header
RS232 Serial Port Header
RS232 Serial Port Combo Block
LAN Activity LED Header
LAN Activity LED Header
PS2 keyboard & Mouse
Front Panel Audio Header
GPIO Port Header
SMBUS Header
Buzzer Header
LVDS INVERTER Header
EDP Wafer
LVDS Header
7
Description
9-pin Block
9-pin Block
9-pin Block
9-pin Block
36-pin Block
2-pin Block
2-pin Block
6-pin Block
9-pin Block
10-pin Block
5-pin Block
2-pin Block
8-pin Block
40-pin Block
32-pin Block
