Zoom ADSL X3 User Manual page 9

The modem's ETHERNET connector is at the back of the
modem.
3 3 3 3
Plug the included X3 power cube into a power strip or wall
outlet, and then into the modem's power (PWR) jack.
Important!
Only use the power cube shipped with the X3. Other power
cubes may damage your hardware.
4 4 4 4
Turn the modem on by using the ON/OFF button at the
back of the modem.
The PWR light on the front panel of the modem should
become steady on, and the LINK light should blink once. If
the PWR light does not turn on, make sure there is power at
the wall outlet or power strip where you plugged in the power
cube and that you have pushed the X3's ON/OFF button to
turn it on.
5 5 5 5
Turn the computer on.
Chapter 1: Installation Instructions 9
