Installation and Maintenance
Part Number: E2K-402-0313, Rev. A
Release: Mar 2013
Manual E796 2000 M2CP
READ THIS MANUAL COMPLETELY
When communicating with BETTIS for replacement parts or for technical questions, we MUST have
actuator nameplate information, including Job, Serial, and Model numbers. This allows us to check
records of BETTIS equipment furnished.
When ordering parts, specify repair part by BETTIS part number and description from drawings
furnished with actuator.
BETTIS Parts Department Fax (281) 261-3834
