Annual Inspections

Maintenance Checklist

Annual Maintenance
Checklist
After the PureWave SMS-250 system is commissioned and the unit is online, inspection
and maintenance should be scheduled for the PCS on an annual basis to ensure the
proper operation of the system. Schedules for maintenance should be reviewed by the
customer based upon the given site conditions and, if required, the frequency of the
recommended maintenance should increase to ensure the reliability of their PureWave
SMS-250 system.
The following checklist provides the PureWave SMS-250 PCS inspection activities that
are to be performed on an annual basis. The amount of dust and dirt accumulated in
the units varies from site to site. Therefore, the customer should review schedules for
maintenance based on the given site conditions and, if required, the frequency of the
recommended maintenance may increase to ensure the reliability of the PureWave
SMS-250.
S&C Electric Company has extended service agreements and spare parts kits avail-
able for the PCS. Please contact S&C Electric Company – Global Support Monitoring
Center at (888) 762-1100.
The PCS requires a minimal amount of maintenance to help ensure high system reli-
ability and efficiency. The following checklist can be used as a reference to assist in
properly maintaining the unit(s).
Make sure the PCS is de-energized before performing maintenance on the equipment .
Taking this necessary step will minimize serious injury or even death . Proper personal
protective equipment (PPE) must be used .
Preparation
Review the steps in this checklist to prepare the proper tools that will be needed to
complete these maintenance tasks.
Communicate with S&C Electric Company to identify any additional tasks that are
expected to be accomplished during the annual maintenance visit.
Coordinate with the site facilitator to obtain keys for the padlocks (if applicable) to
unlock the door to the PCS enclosure(s).
Required Tools
Shop vacuum
Rags or paper towels
General purpose cleaner (e.g. Simple Green)
New CompactFlash Card for replacement (old card should be returned to
S&C Electric Company)
Ratchet wrench
11-mm socket
15-mm socket
.5-M (20-inch) socket wrench extension
13-mm socket
7-mm socket
5.5-mm socket
3/8-inch socket
Slot driver
#1 Phillips
#2 Phillips
3-mm hex wrench
8-mm hex wrench
White lithium grease (door grease)
DANGER
S&C Instruction Sheet 659-520

Maintenance

43
